NAM-10-221

OPEN FRAME & ENCLOSED NAM A C F I LT E R Features • • • • • Low leakage current type. Single Phase 250Vac. Selectable leakage current. Quick and easy push down terminal. Din rail installation type (Option). Specifications INPUT Voltage Test voltage (Terminal-mounting plate) Isolation resistance (Terminal-mounting plate) 250Vac/250Vdc, 1 phase 2.5kVac (cutoff current = 20mA), 1 minute at room temperature and humidity. 500Vdc, 100MW minute at room temperature and humidity. Ordering Information NAM (1) -10 (2) -000 (3) _ (4) OUTPUT Current Leakage current Voltage drop See table. 5mA/10mA max (125/250Vac, 60Hz) 1.0V max 1.Model name 2.Rated current 3. Line to ground capacitor code 4. Options D: Din rail installation type CODE 04 06 10 16 20 30 CURRENT 4A 6A 10A 16A 20A 30A ENVIRONMENTAL Safety agency approval Temperature Operating temperature Storage temperature Humidity Vibration Impact -25°C to 85°C (Refer to derating ). -40°C to 85°C (Refer to derating curve). -40°C to 85°C 20% to 95% RH (Non-condensing) 10 to 55Hz, 19.6m/s2 (2G), 3min. Period, 1 hour each X, Y and Z axis. 196.1m/s2 (20G), 11ms once each X, Y and Z axis. CODE 000 101 221 LEAKAGE CURRENT(INPUT 125/250V 60HZ) 5MA / 10MA max 12.5MA / 25MA max 25MA / 50MA max 37.5MA / 75MA max LINE TO GROUND CAPACITOR(NOMINAL VALUE) Not Provided 100pF 220pF 330pF STANDARDS Safety UL1283, CSA C 22.2 No. 8 (C-UL), DIN EN133200 VDE0565 Teil3-1, ENEC (At only AC input). 331 471 50MA / 100MA max 470pF When the line to ground capacitor code is different, the attenuation characteristic is different. 142
