TAC-16-683

OPEN FRAME & ENCLOSED TAC A C F I LT E R Features • • • • Ultra high attenuation type of common mode noise from 150kHz to 1MHz. Three Phase 500Vac. Quick and easy push down terminal. Din rail installation type (Option). Specification INPUT Voltage Test voltage (Terminal-mounting plate) Isolation resistance (Terminal-mounting plate) 500Vac, 3 phase 2kVac (cutoff current = 100mA), 1 minute at room temperature and humidity. 500Vdc, 100MW minute at room temperature and humidity. Ordering Information TAC (1) -10 (2) -683 (3) _ (4) OUTPUT Current Leakage current Voltage drop See table. 2.5mA/5.0mA max (125/250Vac, 60Hz) 1.5V max (TAC-04, TAC-06) 1.0V max (TAC-10, TAC-20, TAC-30) 1. Model name 2. Rated current 3. Line to ground capacitor code 4. Options D: Din rail installation type. CODE 06 10 16 20 30 CURRENT 6A 10A 16A 20A 30A ENVIRONMENTAL Safety agency approval Temperature Operating temperature Storage temperature Humidity Vibration Impact -40°C to 85°C (Refer to derating curve). -40°C to 85°C 20% to 95% RH (Non-condensing) 10 to 55Hz, 19.6m/s2 (2G), 3min. Period, 1 hour each X, Y and Z axis. 196.1m/s2 (20G), 11ms once each X, Y and Z axis. -25°C to 85°C (Refer to derating curve). CODE 683 LEAKAGE CURRENT(INPUT 125/250V 60HZ) 2.5mA / 5.0mA max LINE TO GROUND CAPACITOR(NOMINAL VALUE) 68000pF STANDARDS Safety UL1283, CSA C 22.2 No. 8 (C-UL), DIN EN133200 VDE0565 Teil3-1, ENEC. Your dependable power partner – www.powerbox.com.au 145
