VI-BTD-CW

VI 200 50-200W PCB MOUNTING COMPONENTS MODULES Features • • • • • • • Inputs: 10 to 400VDC Output, 1 to 95VDC UL, CSA, TÜV, VDE, BABT, CF 80–90% efficiency (typical) ZCS power architecture Low noise FM control Booster versions available for expanded power Specifications INPUT Input voltage OUTPUT PRODUCT GRADE Output voltage Output power Set point accuracy Low–high trim voltage Output ripple pk-pk Load regulation Line regulation OVP set point Current limit setting E, C, I, M See table See table 0.5% 50%–110% 1% 0.05% 0.05% 115%–135% 105%–125% See table Selection Table A = INPUT VOLTAGE B = OUTPUT VOLTAGE Nominal Range Notes 0= 12V 10–20V (1) Z = 2V 2 = 15V 1= 24V 21–32V (6) Y = 3.3V N = 18.5V W= 24V 18–36V (4) 0 = 5V 3 = 24V 2= 36V 21–56V (3) X = 5.2V L = 28V 3= 48V 42–60V (6) W = 5.5V J = 36V N= 48V 36–76V (6) V = 5.8V K = 40V 4= 72V 55–100V (6) T = 6.5V 4 = 48V T= 110V 66–160V (4) R = 7.5V H = 52V 5= 150V 100–200V (5) M = 10V F = 72V 6= 300V 200–400V (6) 1 = 12V D = 85V 7= 150/300V 100–375V (2) P = 13.8V B = 95V C = PRODUCT GRADE D = OUTPUT POWER/CURRENT V out ≥5V V out 5V Outputs 75W 100W 100W 150W 200W 200W 1,000,000 hrs 80%–90% 3750V rms 85°C 95°C Yes, C, I, M grades STANDARDS AND APPROVALS Safety C-Tick MECHANICAL Dimensions PCB mounting 117x61x12.7mm Yes Selection Table Guide VI - 2 [a] [b] - [c] [d] VI - B [a] [b] - [c] [d] Booster Note: For RoHS version replace VI with VE. Mechanical Drawings See page 230 Your dependable power partner – www.powerbox.com.au 229 MODULES 230 Mechanical Drawings F U L L A N D J U N I O R S I Z E D M E C H A N I C A L S P E C I F I C AT I O N S JUNIOR SIZED MODULES FULL SIZED MODULES
