704-15K36_11

05021 Only One Name Means ProTek’Tion™ 704-15K36 - 704-15K36T HIGH POWER AIRCRAFT/ VEHCILE DC BUS VOLTAGE SUPPRESSOR DESCRIPTIOn The 704-15K36 and 704-15K36T are 15 kilowatt silicon transient voltage suppressors (TVS) designed for use primarily in 28 Volt aircraft applications in accordance with MIL-STD-704 and MIL-STD-19500. These assemblies typically operate with a minimum source impedance of 0.25 Ohms. These devices have a peak pulse power rating of 15,000 Watts for a 1 ms waveshape and therefore can be used in applications where induced lightning on rural or remote transmission lines present a hazard to electronic circuitry. The 704-15K36 is designed for high current short peak pulse transient applications, where as the 704-15K36T is designed for extended peak pulse transients greater than 1 millisecond. 704 PACKAGE This series can be screened upon request for military requirements in accordance with MIL-PRF-19500 (applicable tests). 704T PACKAGE FEATURES • • • • Meets MIL-STD-704 15 kilowatts Peak Pulse Power per Line (tp = 10/1000µs) Each Device 100% Tested 28 Volt Power Supply Protection APPLICATIOnS • DC Power Supply Protection • MIL-STD-704 Power Bus Protection MECHAnICAL CHARACTERISTICS • • • • • • Molded Plastic Case 704-15K36 Approximate Weight: 38 grams 704-15K36T Approximate Weight: 65 grams Flammability Rating UL 94V-0 Military Screening Available Upon Request for IAW MIL-PRF-19500 Standard Screening Available Upon Request: H1 - Submodule Screening (Test Plans 05231 & 05232) H2 - Submodule & Module Screening (Test Plan 05233) H3 - Submodule & Module Screening with Group B & C Lot Testing (Test Plans 05234 & 05235) A Warranty Disclaimer is required for the purchase of this part. Contact Customer Service for more information. 05021.R11 4/11 Page 1 www.protekdevices.com 05021 Only One Name Means ProTek’Tion™ 704-15K36 - 704-15K36T TyPICAL DEVICE CHARACTERISTICS MAXIMUM RATInGS @ 25°C Unless Otherwise Specified PARAMETER Peak Pulse Power (tp = 10/1000) - See Figure 1 Operating Temperature Storage Temperature Steady State Power Dissipation @ 50°C Forward Surge Rating @ 25°C 1/120 seconds SyMBOL PPP TL TSTG TA FI VALUE 15 -55 to 150 -55 to 150 10.0 300 UnITS kilowatts °C °C Watts Amps ELECTRICAL CHARACTERISTICS PER LInE @ 25°C Unless Otherwise Specified PART nUMBER RATED STAnD-OFF VOLTAGE MInIMUM BREAKDOWn VOLTAGE @10mA V(BR) VOLTS 36 36 MAXIMUM CLAMPInG VOLTAGE (Fig. 2) @ I PPM VC VOLTS 53 53 MAXIMUM LEAKAGE CURREnT @V WM ID µA 100 500 MAXIMUM PEAK PULSE CURREnT (Fig. 2) IPPM AMPS 300 300 MAXIMUM FORWARD VOLTAGE @100A, 8.3ms VF VOLTS DC 3.0 15.0 VWM VOLTS 704-15K36 704-15K36T 31.5 31.5 05021.R11 4/11 Page 2 www.protekdevices.com 05021 Only One Name Means ProTek’Tion™ 704-15K36 - 704-15K36T TyPICAL DEVICE CHARACTERISTICS FIGURE 1 PEAK PULSE POWER VS PULSE TIME 1,000 PPP - Peak Pulse Power - kilowatts 100 10 15kW 10/1000µs Waveform 704-15K36T 704-15K36 1 1 10 100 1,000 td - Pulse Duration - µs 10,000 100,000 1M FIGURE 2 PULSE WAVEFORM tf IPP - Peak Pulse Current - % of IPP 100 100 FIGURE 3 POWER DERATInG CURVE TEST WAVEFORM PARAMETERS tf = 10µs td = 1000µs Peak Pulse Power 10/1000µs 80 % Of Rated Power Peak Value IPP td = t/(IPP/2) 50 60 40 20 e 0 0 1 -t 2 t - Time - ms 3 0 0 25 50 75 100 125 150 TL - Lead Temperature - °C 05021.R11 4/11 Page 3 www.protekdevices.com 05021 Only One Name Means ProTek’Tion™ 704-15K36 - 704-15K36T PACKAGE InFORMATIOn 704 OUTLInE DIMEnSIOnS DIM A B C D E F G H I J K L nOTES 8.76 13.51 0.66 11.94 2.41 7.70 9.40 MILLIMETERS MIn 49.28 43.92 2.79 18.29 InCHES MIn 1.97 1.73 0.11 0.72 MAX 51.56 44.96 3.56 19.81 MAX 2.03 1.77 0.14 0.78 3.18 DIA 10.29 15.04 0.71 13.46 2.92 8.20 10.92 0.125 DIA 0.345 0.532 0.026 0.47 0.095 0.303 0.37 0.405 0.592 0.028 0.53 0.115 0.323 0.43 1. Dimension “E” is nominal. A C B F D H E G I K L 05021.R11 4/11 Page 4 www.protekdevices.com 05021 Only One Name Means ProTek’Tion™ 704-15K36 - 704-15K36T PACKAGE InFORMATIOn 704T OUTLInE DIMEnSIOnS DIM A B C D E F G H I J K nOTES 16.51 8.51 21.84 5.59 17.53 0.65 0.335 8.26 11.43 23.37 0.86 0.22 0.69 MILLIMETERS MIn 62.74 53.34 4.32 10.54 InCHES MIn 2.47 2.10 0.17 0.415 MAX 64.26 54.48 5.33 12.07 MAX 2.53 2.145 0.21 0.475 3.18 DIA 9.27 0.125 DIA 0.325 0.45 0.92 0.365 1. Dimensions “E”, “G”, “I” and “K” are nominal. A C B F I D G H E J K ORDERInG InFORMATIOn BASE PART nUMBER 704-15K36 704-15K36T nOTES SUBMODULE SCREEnInG H1 H1 SUBMODULE & MODULE SCREEnInG H2 H2 SUBMODULE, MODULE, GROUP B & C LOT TESTInG H3 H2 1. Marking on Part - logo, date code, polarity dot (for positive terminal) and part number. Package outline per document number 06035.R2 9/09 05021.R11 4/11 Page 5 www.protekdevices.com 05021 Only One Name Means ProTek’Tion™ 704-15K36 - 704-15K36T COMPAny InFORMATIOn COMPAny PROFILE ProTek Devices, based in Tempe, Arizona USA, is a manufacturer of Transient Voltage Suppression (TVS) products designed specifically for the protection of electronic systems from the effects of lightning, Electrostatic Discharge (ESD), Nuclear Electromagnetic Pulse (NEMP), inductive switching and EMI/RFI. With over 25 years of engineering and manufacturing experience, ProTek designs TVS devices that provide application specific protection solutions for all electronic equipment/systems. ProTek Devices Analog Products Division, also manufactures analog interface, control, RF and power management products. COnTACT US Corporate Headquarters 2929 South Fair Lane Tempe, Arizona 85282 USA By Telephone General: 602-431-8101 Sales: 602-414-5109 Customer Service: 602-414-5114 By Fax General: 602-431-2288 By E-mail: Sales: sales@protekdevices.com Customer Service: service@protekdevices.com Technical Support: support@protekdevices.com Web www.protekdevices.com www.protekanalog.com WARRAnTy DISCLAIMER ProTek warrants only that the 704-15K36 product (the “Device”) has been manufactured to meet the electrical specifications set forth in the electrical specification data sheet published by ProTek Devices. ProTek disclaims all other warranties. If the Device is applied or used in circumstances in which the electrical characteristics specified for the Device are exceeded, the Device may fail. ProTek Devices is not liable for any failures of the Device if the Device is used in circumstances that exceed the published specifications for the Device. If for any reason the Device fails, customer’s sole and exclusive remedy shall be replacement of the failed Device. Customer assumes all risks arising from incorporation of the Device in to any other product. Customer acknowledges that ProTek Devices has made the Device available to the Customer for inspection, and the Customer has had an opportunity to inspect and test the Device. COPYRIGHT © ProTek Devices 1998 - This literature is subject to all applicable copyright laws and is not for resale in any manner. SPECIFICATIONS: ProTek reserves the right to change the electrical and or mechanical characteristics described herein without notice. DESIGN CHANGES: ProTek reserves the right to discontinue product lines without notice and that the final judgement concerning selection and specifications is the buyer’s and that in furnishing engineering and technical assistance. ProTek assumes no responsibility with respect to the selection or specifications of such products. ProTek makes no warranty, representation or guarantee regarding the suitability of its products for any particular purpose, nor does ProTek assume any liability arising out of the application or use of any product or circuit and specifically disclaims any and all liability without limitation special, consequential or incidental damages. LIFE SUPPORT POLICY: ProTek Devices products are not authorized for use in life support systems without written consent from the factory. 05021.R11 4/11 Page 6 www.protekdevices.com
