PC-10-2400B4

LAMINATED TRANSFORMERS Low Frequency, Open-Style Laminated, Concentric Vertical Profile, PC Plug-In Series AGENCY APPROVALS UL, 506, File E73539 UL Recognized Class B UL 1446, File E80130 CSA 22.2#66, File LR68051-2 Single 115V 6-Pin PC-10-90B53 PC-10-120B1 PC-10-440B2 PC-10-1000B3 PC-10-2400B4 PC-12-70B54 PC-12-100B5 PC-12-350B6 PC-12-800B7 PC-12-2000B8 PC-16-55B55 PC-16-75B9 PC-16-260B10 PC-16-640B11 PC-16-1500B12 PC-20-45B56 PC-20-60B13 PC-20-220B14 PC-20-500B15 PC-20-1200B16 PC-24-35B57 PC-24-50B17 PC-24-180B18 PC-24-450B19 PC-24-1000B20 PC-28-30B58 PC-28-40B49 PC-28-160B50 PC-28-360B51 PC-28-800B52 PC-34-25B59 PC-34-35B21 PC-34-125B22 PC-34-300B23 PC-34-700B24 PC-40-20B60 PC-40-30B25 PC-40-110B26 PC-40-250B27 PC-40-600B28 PC-56-15B61 PC-56-20B29 PC-56-80B30 PC-56-180B31 PC-56-420B32 PC-120-8B63 PC-120-10B37 PC-120-35B38 PC-120-85B39 PC-120-200B40 PC-230-4B65 PC-230-5B45 PC-230-20B46 PC-230-40B47 PC-230-100B48 Dusl 115/230V 8-Pin DPC-10-90B53 DPC-10-120B1 DPC-10-440B2 DPC-10-1000B3 DPC-10-2400B4 DPC-12-70B54 DPC-12-100B5 DPC-12-350B6 DPC-12-800B7 DPC-12-2000B8 DPC-16-55B55 DPC-16-75B9 DPC-16-260B10 DPC-16-640B11 DPC-16-1500B12 DPC-20-45B56 DPC-20-60B13 DPC-20-220B14 DPC-20-500B15 DPC-20-1200B16 DPC-24-35B57 DPC-24-50B17 DPC-24-180B18 DPC-24-450B19 DPC-24-1000B20 DPC-28-30B58 DPC-28-40B49 DPC-28-160B50 DPC-28-360B51 DPC-28-800B52 DPC-34-25B59 DPC-34-35B21 DPC-34-125B22 DPC-34-300B23 DPC-34-700B24 DPC-40-20B60 DPC-40-30B25 DPC-40-110B26 DPC-40-250B27 DPC-40-600B28 DPC-56-15B61 DPC-56-20B29 DPC-56-80B30 DPC-56-180B31 DPC-56-420B32 DPC-120-8B63 DPC-120-10B37 DPC-120-35B38 DPC-120-85B39 DPC-120-200B40 DPC-230-4B65 DPC-230-5B45 DPC-230-20B46 DPC-230-40B47 DPC-230-100B48 Size 25 37 50 62 24 25 37 50 62 24 25 37 50 62 24 25 37 50 62 24 25 37 50 62 24 25 37 50 62 24 25 37 50 62 24 25 37 50 62 24 25 37 50 62 24 25 37 50 62 24 25 37 50 62 24 Series V.C.T.@mA Parallel @ 2x Current V.@mA 10 @ 90 5 @ 180 10 @ 120 5 @ 240 10 @ 440 5 @ 880 10 @ 1000 5 @ 2000 10 @ 2400 5 @ 4800 12.6 @ 70 6.3 @ 140 12.6 @ 100 6.3 @ 200 12.6 @ 350 6.3 @ 700 12.6 @ 800 6.3 @ 1600 12.6 @ 2000 6.3 @ 4000 16 @ 55 8 @ 110 16 @ 75 8 @ 150 16 @ 260 8 @ 520 16 @ 640 8 @ 1280 16 @ 1500 8 @ 3000 20 @ 45 10 @ 90 20 @ 60 10 @ 120 20 @ 220 10 @ 440 20 @ 500 10 @ 1000 20 @ 1200 10 @ 2400 24 @ 35 12 @ 70 24 @ 50 12 @ 100 24 @ 180 12 @ 360 24 @ 450 12 @ 900 24 @ 1000 12 @ 2000 28 @ 30 14 @ 60 28 @ 40 14 @ 80 28 @ 160 14 @ 320 28 @ 360 14 @ 720 28 @ 800 14 @ 1600 34 @ 25 17 @ 50 34 @ 35 17 @ 70 34 @ 125 17 @ 250 34 @ 300 17 @ 600 34 @ 700 17 @ 1400 40 @ 20 20 @ 40 40 @ 30 20 @ 60 40 @ 110 20 @ 220 40 @ 250 20 @ 500 40 @ 600 20 @ 1200 56 @ 15 28 @ 30 56 @ 20 28 @ 40 56 @ 80 28 @ 160 56 @ 180 28 @ 360 56 @ 420 28 @ 840 120 @ 8 60 @ 16 120 @ 10 60 @ 20 120 @ 35 60 @ 70 120 @ 85 60 @ 170 120 @ 200 60 @ 400 230 @ 4 115 @ 8 230 @ 5 115 @ 10 230 @ 20 115 @ 40 230 @ 40 115 @ 80 230 @ 100 115 @ 200 PC Series Concentric Vertical Mount Isolation between primary and secondary of 1500V. Vacuum Impregnated to withstand modern board washing systems and to reduce audible noise. Available in single or dual primary Baked Resin provides fully cured and environmentally resistant finish that will not peel or flake. Rugged Construction Universal Design compatible with industry-standard footprints D PC - 10 - 2400 B 4 Primary Rating No First Letter – 115V – 6-pin “D” First Letter – 115/230V – 8-pin Secondary Voltage Rating (Volts RMS) B – No frame Secondary Current Rating (mA RMS) Individual Specification Transformer Series PC – Single Section Bobbin (47/500Hz) Mechanical Configuration Dimensions (inches) Size 25 37 50 62 24 VA 1.0 1.2 4.4 10 24 Wt. (oz.) 2.5 3 5 9 12 L 1.000 1.375 1.625 1.875 1.625 H 0.830 1.188 1.375 1.625 1.375 W 1.375 1.125 1.250 1.438 2.250 B 1.200 1.000 1.100 1.300 2.100 6-pin X 0.250 0.312 0.400 0.400 0.400 8-pin A 0.200 0.200 0.250 0.250 0.250 Mechanical Dimensions for Style B (no frame) are shown. PC Terminal (Plug-In Mounting) H 2 W B X 1 3 4 8 7 6 5 W B A 1 2 3 4 Schematics PC 6-pin 3 4 5 6 DPC 8-pin L 5 6 3/16 A A X 1 115V 2 Recommended PC Hole Diameter = .052 1 115V 2 3 115V 4 5 6 7 8 USA 858 674 8100 • Germany 49 7032 7806 0 • Singapore 65 6287 8998 • Shanghai 86 21 54643211 / 2 • China 86 769 85538070 • Taiwan 886 3 4641811 www.pulseeng.com 43 LT2006 (7/06)
