QBL8XX60D 5mm Round Lamp --------------------------------------------------------------------------------------------------------------------------------------- QT-Brightek Lamp Series 5mm Round Lamp Part No.: QBL8XX60D XX: Color Code Product: QBL8XX60D Date: November 16, 2017 Version# 1.0 Page 1 of 8 QBL8XX60D 5mm Round Lamp --------------------------------------------------------------------------------------------------------------------------------------Table of Contents: Introduction ........................................................................................................................................... 3 Electrical / Optical Characteristic (Ta=25 oC) ........................................................................................ 4 Absolute Maximum Rating .................................................................................................................... 4 Characteristic Curves ............................................................................................................................ 5 Ordering Information ............................................................................................................................. 7 Revision History .................................................................................................................................... 8 Disclaimer ............................................................................................................................................. 8 Product: QBL8XX60D Date: November 16, 2017 Version# 1.0 Page 2 of 8 QBL8XX60D 5mm Round Lamp --------------------------------------------------------------------------------------------------------------------------------------- Introduction Feature:  Color diffused lens  Packaged in bulk pack  5mm round lamp  Viewing angle: 60º typ. Application:  General purpose indicator application  Electronic signs and electronics board  LED lighting Certification & Compliance:  TS16949 These bright 5mm round type lamps are suitable for all  ISO9001 indicator applications such as electronic signs and  RoHS Compliant electronic board indictor. Description: Dimension: Units: mm / general tolerance = +/-0.25mm unless otherwise specified Product: QBL8XX60D Date: November 16, 2017 Version# 1.0 Page 3 of 8 QBL8XX60D 5mm Round Lamp --------------------------------------------------------------------------------------------------------------------------------------- Electrical / Optical Characteristic (Ta=25 oC) Product Color IF (mA) QBL8R60D QBL8S60D QBL8O60D QBL8Y60D QBL8AG60D QBL8IG60D QBL8IB60D Red Deep Red Orange Yellow Yellow Green True Green Blue 20 20 20 20 20 20 20 VF (V) Typ. Max. 2.0 2.6 2.0 2.6 2.0 2.6 2.0 2.6 2.0 2.6 3.2 3.6 3.2 3.6 λD (nm) Typ. 624 630 605 590 573 525 470 IV (mcd) Min. Typ. 210 350 90 160 70 120 160 210 45 70 1000 1700 350 600 Absolute Maximum Rating Material AlInGaP Pd (mW) 65 IF (mA) 25 IFP (mA)* 100 VR (V) 5 InGaN 95 25 100 5 *1/10 Duty Cycle, 0.1ms Pulse Width **Wave Soldering for no more than 3 sec @ 260 oC Product: QBL8XX60D TOP (oC) -40 to +85 TST (oC) -40 to +100 TSOL (oC)** 260 -40 to +85 -40 to +100 260 Date: November 16, 2017 Version# 1.0 Page 4 of 8 QBL8XX60D 5mm Round Lamp --------------------------------------------------------------------------------------------------------------------------------------- Characteristic Curves AlInGaP (R/S/AG/O/Y) Product: QBL8XX60D Date: November 16, 2017 Version# 1.0 Page 5 of 8 QBL8XX60D 5mm Round Lamp --------------------------------------------------------------------------------------------------------------------------------------InGaN (IG/IB) Product: QBL8XX60D Date: November 16, 2017 Version# 1.0 Page 6 of 8 QBL8XX60D 5mm Round Lamp --------------------------------------------------------------------------------------------------------------------------------------- Ordering Information Part # QBL8R60D QBL8S60D QBL8O60D QBL8Y60D QBL8AG60D QBL8IG60D QBL8IB60D Orderable Part # QBL8R60D QBL8S60D QBL8O60D QBL8Y60D QBL8AG60D QBL8IG60D QBL8IB60D Product: QBL8XX60D Spec Range Iv=350mcd typ. @ 20mA, λD=624nm typ. Iv=160mcd typ. @ 20mA, λD=630nm typ. Iv=120mcd typ. @ 20mA, λD=605nm typ. Iv=210mcd typ. @ 20mA, λD=590nm typ. Iv=70mcd typ. @ 20mA, λD=573nm typ. Iv=1700mcd typ. @ 20mA, λD=525nm typ. Iv=600mcd typ. @ 20mA, λD=470nm typ. Date: November 16, 2017 Version# 1.0 Quantity per bag 500pcs 500pcs 500pcs 500pcs 500pcs 500pcs 500pcs Page 7 of 8 QBL8XX60D 5mm Round Lamp --------------------------------------------------------------------------------------------------------------------------------------- Revision History Description: New Release of QBL8XX60D Revision # V1.0 Revision Date 11/16/2017 Disclaimer QT-BRIGHTEK reserves the right to make changes without further notice to any products herein to improve reliability, function or design. QT-BRIGHTEK does not assume any liability arising out of the application or use of any product or circuit described herein; neither does it convey any license under its patent rights, nor the rights of others. Life Support Policy QT-BRIGHTEK’s products are not authorized for use as critical components in life support devices or systems without the express written approval of QT-BRIGHTEK. As used herein: 1. Life support devices or systems are devices or systems which, (a) are intended for surgical implant into the body, or (b) support or sustain life, and (c) whose failure to perform when properly used in accordance with instructions for use provided in the labeling, can be reasonably expected to result in a significant injury of the user. 2. A critical component in any component of a life support device or system whose failure to perform can be reasonably expected to cause the failure of the life support device or system, or to affect its safety or effectiveness. Product: QBL8XX60D Date: November 16, 2017 Version# 1.0 Page 8 of 8
