QBLP600-RGB

QBLP600-RGB 0606 RGB LED TRI COLOR --------------------------------------------------------------------------------------------------------------------------------------- QT-Brightek Chip LED Series SMD 0606 RGB LED Part No.: QBLP600-RGB Product: QBLP600-RGB Date: April 26, 2016 Version# 2.1 Page 1 of 10 QBLP600-RGB 0606 RGB LED TRI COLOR --------------------------------------------------------------------------------------------------------------------------------------Table of Contents: Introduction ........................................................................................................................................... 3 Electrical / Optical Characteristic (Ta=25 oC) ........................................................................................ 4 Absolute Maximum Rating .................................................................................................................... 4 Characteristic Curves ............................................................................................................................ 6 Solder Profile & Footprint ...................................................................................................................... 7 Packing ................................................................................................................................................. 8 Labeling ................................................................................................................................................ 9 Ordering Information ............................................................................................................................. 9 Revision History .................................................................................................................................. 10 Disclaimer ........................................................................................................................................... 10 Product: QBLP600-RGB Date: April 26, 2016 Version# 2.1 Page 2 of 10 QBLP600-RGB 0606 RGB LED TRI COLOR --------------------------------------------------------------------------------------------------------------------------------------- Introduction Feature:  Water clear lens  Package in tape and reel  Ultra bright 0606 LED package  Common Anode  InGaN technology for IB/IG  AlInGaP technology for R Description: These ultra bright 0606 RGB LEDs have a height profile of 0.80mm. Combination of high brightness output and small footprint, these LEDs are ideal for keypad backlighting, status indication, and color mixing applications. Application:  Status indication  Back lighting application Certification & Compliance:  TS16949  ISO9001  RoHS Compliant Dimension: Units: mm / tolerance = +/-0.1mm Product: QBLP600-RGB Date: April 26, 2016 Version# 2.1 Page 3 of 10 QBLP600-RGB 0606 RGB LED TRI COLOR --------------------------------------------------------------------------------------------------------------------------------------- Electrical / Optical Characteristic (Ta=25 oC) Product Color IF(mA) QBLP600-RGB Red True Green Blue 20 20 20 VF(V) Typ. Max 2.0 2.5 3.4 3.7 3.1 3.7 Min 615 515 465 λD (nm) Typ. 620 520 470 Max 630 525 475 IV(mcd) Min Typ. 80 125 200 380 40 75 Absolute Maximum Rating Material InGaN (IB/IG) AlInGaP (R) Pd (mW) 111 75 IF (mA) 30 30 IFP (mA)* 125 125 VR (V) 5 5 TOP (oC) -40 ~ + 80 -40 ~ + 80 TST (oC) TSOL (oC)** -40 ~ +85 260 -40 ~ +85 260 *Duty 1/8 @ 1KHz o **IR Reflow for no more than 10 sec @ 260 C Forward Voltage VF for AlInGaP @ IF=20mA Bin □ Min. 1.7 Max. 2.5 Unit V Forward Voltage VF for InGaN @ IF=20mA Bin f g h Product: QBLP600-RGB Min. 2.8 3.1 3.4 Max. 3.1 3.4 3.7 Unit V Date: April 26, 2016 Version# 2.1 Page 4 of 10 QBLP600-RGB 0606 RGB LED TRI COLOR --------------------------------------------------------------------------------------------------------------------------------------- Luminous Intensity IV @ IF=20mA Bin F G H I J K L M N O P Q Min. 40 50 63 80 100 125 160 200 250 320 400 500 Max. 50 63 80 100 125 160 200 250 320 400 500 630 Unit mcd Dominant Wavelength λD for Red @ IF=20mA Bin s t u Min. 615 620 625 Max. 620 625 630 Unit nm Dominant Wavelength λD for Green @ IF=20mA Bin S T U V Min. 515 517.5 520 522.5 Max. 517.5 520 522.5 525 Unit nm Dominant Wavelength λD for Blue @ IF=20mA Bin G H I J Product: QBLP600-RGB Min. 465 467.5 470 472.5 Max. 467.5 470 472.5 475 Unit nm Date: April 26, 2016 Version# 2.1 Page 5 of 10 QBLP600-RGB 0606 RGB LED TRI COLOR --------------------------------------------------------------------------------------------------------------------------------------- Characteristic Curves Product: QBLP600-RGB Date: April 26, 2016 Version# 2.1 Page 6 of 10 QBLP600-RGB 0606 RGB LED TRI COLOR --------------------------------------------------------------------------------------------------------------------------------------- Solder Profile & Footprint -Recommended tin solder specifications: melting temperature in the range of 178~192 °C -The recommended reflow soldering profile is as follows (temperatures indicated are as measured on the surface of the LED resin): Recommended Pad Layout Units: mm Product: QBLP600-RGB Tolerance: ± 0.1mm Date: April 26, 2016 Version# 2.1 Page 7 of 10 QBLP600-RGB 0606 RGB LED TRI COLOR --------------------------------------------------------------------------------------------------------------------------------------- Packing Reel Dimension: Unit: mm Tape Dimension: A 2 4 1 3 A Unit: mm Arrangement of Tape: Packaging Specification: Product: QBLP600-RGB Date: April 26, 2016 Version# 2.1 Page 8 of 10 QBLP600-RGB 0606 RGB LED TRI COLOR --------------------------------------------------------------------------------------------------------------------------------------- Labeling Ordering Information Part # Orderable Part # QBLP600-RGB QBLP600-RGB Product: QBLP600-RGB Spec Range Red: Iv=125mcd typ. @ IF=20mA, λD=615nm to 630nm True Green: Iv=380mcd typ. @ IF=20mA, λD=515nm to 525nm Blue: Iv=75mcd typ. @ IF=20mA, λD=465nm to 475nm Date: April 26, 2016 Version# 2.1 Quantity per reel 1,000 units Page 9 of 10 QBLP600-RGB 0606 RGB LED TRI COLOR --------------------------------------------------------------------------------------------------------------------------------------- Revision History Description: New Release of QBLP600-RGB Brightness Updates Labeling update Spec Update Update format Update packing spec and PCB drawing Revision # V1.0 V1.1 V1.2 V1.3 V2.0 V2.1 Revision Date 02/03/2011 06/01/2011 06/25/2011 12/12/2011 07/15/2013 04/26/2016 Disclaimer QT-BRIGHTEK reserves the right to make changes without further notice to any products herein to improve reliability, function or design. QT-BRIGHTEK does not assume any liability arising out of the application or use of any product or circuit described herein; neither does it convey any license under its patent rights, nor the rights of others. Life Support Policy QT-BRIGHTEK’s products are not authorized for use as critical components in life support devices or systems without the express written approval of QT-BRIGHTEK. As used herein: 1. Life support devices or systems are devices or systems which, (a) are intended for surgical implant into the body, or (b) support or sustain life, and (c) whose failure to perform when properly used in accordance with instructions for use provided in the labeling, can be reasonably expected to result in a significant injury of the user. 2. A critical component in any component of a life support device or system whose failure to perform can be reasonably expected to cause the failure of the life support device or system, or to affect its safety or effectiveness. Product: QBLP600-RGB Date: April 26, 2016 Version# 2.1 Page 10 of 10
