705-00-00

THESE DRAWINGS ARE THE PROPERTY OF QUALTEK ELECTRONICS AND NOT TO BE REPRODUCED FOR OR COMMUNICATED TO A THIRD PARTY WITHOUT THE EXPRESS WRITTEN PERMISSION OF AN OFFICER OF QUALTEK ELECTRONICS. REVISION REV. B DESCRIPTION RoHS Compliancy DATE 06-01-06 APPROVED DP 51.3 17.5 65.0 37.1 Ø7.6ID Ø13.0 16.9 NOTES: MATERIAL: MOULDING: NYLON, FLAMMABILITY RATING U.L. 94V-0 CONTACTS: BRASS, NICKEL PLATED RATING: 10A 250V AC INSULATION RESISTANCE: >1000 M OHM CONTACT RESISTANCE: < 10m OHM A.C. BREAKDOWN: POLE-POLE: 4.5kV POLE-ACCESSIBLE: 4kV OPERATING TEMPERATURE: -40˚ C TO +70˚ C WITHDRAWL FORCE: 10N (MIN), 50N (MAX) APPROVALS: UL,CSA, VDE FOR USE WITH 18 AWG CORDAGE RoHS COMPLIANT Dim range (mm) 0-1 1-6 6-18 18-50 50-120 120-250 250-500 Tolerance +/(mm) 0.15 0.20 0.30 0.50 0.70 0.90 1.20 CONTROLLED Qualtek Electronics Corp. Part Number: Description: PPC DIVISION 705-00/00 REWIRABLE PLUG ASSEMBLY UNIT: mm REV. B Approved / Date JJH / 12-30-02 Drawn / Date B.Zhang 12-30-02 Checked / Date 12-30-02
