730-20-01

THESE DRAWINGS ARE THE PROPERTY OF QUALTEK ELECTRONICS AND NOT TO BE REPRODUCED FOR OR COMMUNICATED TO A THIRD PARTY WITHOUT THE EXPRESS WRITTEN PERMISSION OF AN OFFICER OF QUALTEK ELECTRONICS. REVISION REV. B DESCRIPTION RoHS Compliancy DATE 06-01-06 APPROVED DP 4.06 R3 . 5 5.07 .5 R0 1 2 3 16 ± 0.25 36.6 ± 0.2 26.1 ± 0.2 10.4 03 .25” 34 ± 0.15 6.1 ± 0.2 41.9 ± 0.25 51.3 ± 0.25 R0 .5 CONTROLLED 3 2 1 Bracket 08F Black Color Screw Q235 Black Color Captive Nut Q235 Black Color Dim range (mm) 0-1 1-6 6-18 18-50 50-120 120-250 250-500 Tolerance +/(mm) 0.15 0.20 0.30 0.50 0.70 0.90 1.20 Drawn / Date B.Zhang 08-27-03 1 1 1 Qualtek Electronics Corp. Part Number: Description: PPC DIVISION 730-20/01 NOTES: RoHS COMPLIANT AC RECEPTACLE UNIT: mm Checked / Date 08-27-03 Approved / Date JJH / 08-27-03 12.7 R2. 1 REV. B
