848-10-003

THESE DRAWINGS ARE THE PROPERTY OF QUALTEK ELECTRONICS AND NOT TO BE REPRODUCED FOR OR COMMUNICATED TO A THIRD PARTY WITHOUT THE EXPRESS WRITTEN PERMISSION OF AN OFFICER OF QUALTEK ELECTRONICS. PHYSICAL DIMENSIONS: REVISION REV. B C DESCRIPTION RoHS Compliancy Updated Specifications DATE 06-01-06 08-12-08 APPROVED DP LY ELECTRICAL CHARACTERISTICS: 1-1. VOLTAGE RATING...................................115/250VAC 1-2. CURRENT RATING A. @ 115 VAC..........................................10 A RMS MAX B. @ 250 VAC...........................................8 A RMS MAX OPERATING FREQUENCY......................50/60Hz LEAKAGE CURRENT: EACH LINE TO GROUND A. @ 115 VAC 60Hz............................0.45 mA MAX B. @ 250 VAC 50Hz.............................0.90 mA MAX HIPOT RATING (FOR ONE MINUTE) A. LINE TO GROUND...........................2250 VDC B. LINE TO LINE.....................................1450 VDC MINIMUM INSERTION LOSS IN dB: (AT 50 OHM SYSTEM) .01 2 0 .05 8 1 .10 12 15 .15 15 25 .50 20 50 1.0 25 50 5.0 40 45 10 45 45 30 40 45 1 3 Ø0.188 1-3. 1-4. 2.06MAX 1-5. 2 4 1-6. 2.94 ± 0.02 3.34MAX 3.75MAX FREQ. MHz COM. MODE dB DIF. MODE dB 1-7. OPERATING TEMPERATURE.................-25° TO +85° C SAFETY: RoHS COMPLIANT 1.54MAX 1-8. 1-9. SCHEMATIC: L1: L2: C1: C2: R: 40.0uH 1.2mH 0.22uF 3300+2200pF 330KΩ Dim range (mm) 0-1 1-6 6-18 18-50 50-120 120-250 250-500 Tolerance +/(mm) 0.15 0.20 0.30 0.50 0.70 0.90 1.20 CONTROLLED Qualtek Electronics Corp. Part Number: Description: PPC DIVISION 848-10/003 EMI FILTER UNIT: in REV. C Approved / Date JJH / 01-16-02 Drawn / Date B.ZHANG 01-16-02 Checked / Date 01-16-02
