858-06-014

THESE DRAWINGS ARE THE PROPERTY OF QUALTEK ELECTRONICS AND NOT TO BE REPRODUCED FOR OR COMMUNICATED TO A THIRD PARTY WITHOUT THE EXPRESS WRITTEN PERMISSION OF AN OFFICER OF QUALTEK ELECTRONICS. 1. PHYSICAL DIMENSIONS Ø3.3(2X) 54.0MAX 50.0MAX 39.5MAX REVISION REV. B C DESCRIPTION RoHS Compliancy Updated Specifications DATE 06-01-06 01-03-08 APPROVED DP DP ELECTRICAL CHARACTERISTICS: 1-1. VOLTAGE RATING...................................115/250VAC 1-2. CURRENT RATING A. @ 115 VAC..........................................8 A RMS MAX B. @ 250 VAC.........................................6 A RMS MAX OPERATING FREQUENCY......................50/60Hz LEAKAGE CURRENT: EACH LINE TO GROUND A. @ 115 VAC 60Hz............................0.20 mA MAX B. @ 250 VAC 50Hz.............................0.40 mA MAX HIPOT RATING (FOR ONE MINUTE) A. LINE TO GROUND...........................2250 VDC B. LINE TO LINE.....................................1450 VDC MINIMUM INSERTION LOSS IN dB: (AT 50 OHM SYSTEM) .01 / / .05 6 1 .10 10 2 .15 12 4 .50 18 10 1.0 24 15 5.0 35 35 10 40 40 30 40 40 1-3. 52.0 ± 0.5 40.0 ± 0.5 1-4. 28.4MAX 1-5. 1-6. FREQ. MHz 40.0 ± 0.13 28.45 ± 0.5 0 M3(2X) 21.3MAX COM. MODE dB DIF. MODE dB 1-7. 1-8. 1-9. OPERATING TEMPERATURE.................-25° TO +100°C SAFETY: RoHS COMPLIANT 21.6 ± 0 0.5 R3.0(4X) PANEL CUTOUT Dim range (mm) 0-1 Tolerance +/(mm) 0.15 0.20 0.30 0.50 0.70 0.90 1.20 CONTROLLED Qualtek Electronics Corp. Part Number: Description: 2. ELECTRICAL SCHEMATIC PPC DIVISION 858-06/014 EMI FILTER UNIT: mm L: C1: C2: R: 0.8mH 0.1uF 2200pF 1MΩ 1-6 6-18 18-50 50-120 120-250 250-500 REV. C Approved / Date JJH / 09-17-01 Drawn / Date B.ZHANG 09-17-01 Checked / Date 09-17-01
