858-10-022

THESE DRAWINGS ARE THE PROPERTY OF QUALTEK ELECTRONICS AND NOT TO BE REPRODUCED FOR OR COMMUNICATED TO A THIRD PARTY WITHOUT THE EXPRESS WRITTEN PERMISSION OF AN OFFICER OF QUALTEK ELECTRONICS. REVISION REV. B DESCRIPTION RoHS Compliancy DATE 06-01-06 APPROVED DP 1. PHYSICAL DIMENSIONS 1.55MAX ELECTRICAL CHARACTERISTICS: 1-1. VOLTAGE RATING...................................115/250VAC 1-2. CURRENT RATING A. @ 115 VAC..........................................10 A RMS MAX B. @ 250 VAC.........................................10 A RMS MAX OPERATING FREQUENCY......................50/60Hz LEAKAGE CURRENT: EACH LINE TO GROUND A. @ 115 VAC 60Hz............................0.20 mA MAX B. @ 250 VAC 50Hz.............................0.40 mA MAX HIPOT RATING (FOR ONE MINUTE) A. LINE TO GROUND...........................2250 VDC B. LINE TO LINE.....................................1450 VDC MINIMUM INSERTION LOSS IN dB: (AT 50 OHM SYSTEM) .01 / / .05 1 1 .10 2 2 .15 4 4 .50 10 10 1.0 13 15 5.0 28 25 10 35 30 30 40 40 1-3. 1.575 ± 0.02 1.18MAX 1.99MAX 3 1 1-4. G 5 2 4 1-5. Ø0.13 1.97MAX CUTOUT (MOUNTING FROM FRONT) R0.098(2X) 0.83MAX M3 1.20 ± 0.02 0 0.835 ± 0 .012 1-6. FREQ. MHz COM. MODE dB DIF. MODE dB 1-7. 1-8. 1-9. OPERATING TEMPERATURE.................-25° TO +85° C SAFETY: RoHS COMPLIANT R0.04MAX(2X) 2. ELECTRICAL SCHEMATIC 1.575 ± 0.005 L: C1: C2: R: 0.2mH 0.1uF 2200pF 1MΩ Dim range (mm) 0-1 1-6 6-18 18-50 50-120 120-250 250-500 Tolerance +/(mm) 0.15 0.20 0.30 0.50 0.70 0.90 1.20 CONTROLLED Qualtek Electronics Corp. Part Number: Description: PPC DIVISION 858-10/022 EMI FILTER UNIT: in REV. B Approved / Date JJH / 09-24-01 Drawn / Date B.ZHANG 09-24-01 Checked / Date 09-24-01
