860-02-006

THESE DRAWINGS ARE THE PROPERTY OF QUALTEK ELECTRONICS AND NOT TO BE REPRODUCED FOR OR COMMUNICATED TO A THIRD PARTY WITHOUT THE EXPRESS WRITTEN PERMISSION OF AN OFFICER OF QUALTEK ELECTRONICS. PHYSICAL DIMENSIONS: REVISION REV. B DESCRIPTION RoHS Compliancy DATE 06-01-06 APPROVED DP ELECTRICAL CHARACTERISTICS: 1-1. VOLTAGE RATING...................................115/250VAC 1-2. CURRENT RATING A. @ 115 VAC..........................................2 A RMS MAX B. @ 250 VAC.........................................2 A RMS MAX OPERATING FREQUENCY......................50/60Hz LEAKAGE CURRENT: EACH LINE TO GROUND A. @ 115 VAC 60Hz............................0.25 mA MAX B. @ 250 VAC 50Hz.............................0.45 mA MAX HIPOT RATING (FOR ONE MINUTE) A. LINE TO GROUND...........................2250 VDC B. LINE TO LINE.....................................1450 VDC MINIMUM INSERTION LOSS IN dB: (AT 50 OHM SYSTEM) .01 / / .05 / / .10 / / .15 29 5 .50 38 19 1.0 40 28 5.0 42 48 10 43 51 30 41 50 28.50 44.0 36.0 LABEL 1-3. 1-4. 42.0 53.0 57.0 M3 R3.5 29.0 ± 0.1 1-5. 1-6. FREQ. MHz COM. MODE dB DIF. MODE dB 32.60 1-7. OPERATING TEMPERATURE.................-25° TO +85° C SAFETY: RoHS COMPLIANT 33.1 ± 0.1 PANEL CUTOUT 1-8. 1-9. SCHEMATIC: L: 4.0mH C1: 0.1uF C2: 3300pF Dim range (mm) 0-1 1-6 6-18 18-50 50-120 120-250 250-500 Tolerance +/(mm) 0.15 0.20 0.30 0.50 0.70 0.90 1.20 CONTROLLED Qualtek Electronics Corp. Part Number: Description: PPC DIVISION 860-02/006 EMI FILTER UNIT: mm REV. B Approved / Date JJH / 02-04-03 Drawn / Date B.ZHANG 02-04-03 Checked / Date 02-04-03
