860-03-008

THESE DRAWINGS ARE THE PROPERTY OF QUALTEK ELECTRONICS AND NOT TO BE REPRODUCED FOR OR COMMUNICATED TO A THIRD PARTY WITHOUT THE EXPRESS WRITTEN PERMISSION OF AN OFFICER OF QUALTEK ELECTRONICS. REVISION REV. B DESCRIPTION RoHS Compliancy DATE 06-01-06 APPROVED DP 1. PHYSICAL DIMENSIONS ELECTRICAL CHARACTERISTICS: 1-1. VOLTAGE RATING...................................115/250VAC 36.0 1-2. CURRENT RATING A. @ 115 VAC..........................................3 A RMS MAX B. @ 250 VAC.........................................3 A RMS MAX OPERATING FREQUENCY......................50/60Hz LEAKAGE CURRENT: EACH LINE TO GROUND A. @ 115 VAC 60Hz............................0.20 mA MAX B. @ 250 VAC 50Hz.............................0.40 mA MAX HIPOT RATING (FOR ONE MINUTE) A. LINE TO GROUND...........................2250 VDC B. LINE TO LINE.....................................1450 VDC MINIMUM INSERTION LOSS IN dB: (AT 50 OHM SYSTEM) .01 / / .05 / / .10 / / .15 20 4 .50 30 10 1.0 35 20 5.0 35 35 10 35 35 30 35 40 38.3 LABEL 41.0 1-3. 1-4. R2.5(8X) R3.5 28.5 ± 0.1 M3(2X) 1-5. 1-6. 36.00 ± 0.1 FREQ. MHz COM. MODE dB DIF. MODE dB 43.5 54.5 57.5 2. ELECTRICAL SCHEMATIC Dim range (mm) 0-1 1-6 6-18 18-50 50-120 120-250 250-500 1-7. OPERATING TEMPERATURE.................-25° TO +85° C SAFETY: RoHS COMPLIANT 39.0 ± 0.1 PANEL CUTOUT 1-8. 1-9. L: 2.4mH C1: 0.1uF C2: 2200pF Tolerance +/(mm) 0.15 0.20 0.30 0.50 0.70 0.90 1.20 CONTROLLED Qualtek Electronics Corp. Part Number: Description: PPC DIVISION 860-03/008 EMI FILTER UNIT: mm REV. B Approved / Date JJH / 05-17-04 Drawn / Date B.ZHANG 05-17-04 Checked / Date 05-17-04
