860-06-005

THESE DRAWINGS ARE THE PROPERTY OF QUALTEK ELECTRONICS AND NOT TO BE REPRODUCED FOR OR COMMUNICATED TO A THIRD PARTY WITHOUT THE EXPRESS WRITTEN PERMISSION OF AN OFFICER OF QUALTEK ELECTRONICS. Ø0.126 1. PHYSICAL DIMENSIONS REVISION REV. B DESCRIPTION RoHS Compliancy DATE 06-01-06 APPROVED DP ELECTRICAL CHARACTERISTICS: 1-1. VOLTAGE RATING...................................115/250VAC 1-2. CURRENT RATING A. @ 115 VAC..........................................6 A RMS MAX B. @ 250 VAC.........................................6 A RMS MAX OPERATING FREQUENCY......................50/60Hz LEAKAGE CURRENT: EACH LINE TO GROUND A. @ 115 VAC 60Hz............................0.25 mA MAX B. @ 250 VAC 50Hz.............................0.45 mA MAX HIPOT RATING (FOR ONE MINUTE) A. LINE TO GROUND...........................2250 VDC B. LINE TO LINE.....................................1450 VDC MINIMUM INSERTION LOSS IN dB: (AT 50 OHM SYSTEM) .01 / / .05 / / .10 15 4 .15 20 6 .50 30 15 1.0 35 20 5.0 50 40 10 55 45 30 45 45 1.417 ± 0.02 1.14MAX. 1.75MAX. 1-3. 1-4. 1-5. 2.00MAX. 2.42MAX. 2.57MAX. 1.14 ± 0.012 0 1-6. FREQ. MHz COM. MODE dB DIF. MODE dB 1.29MAX. 1-7. OPERATING TEMPERATURE.................-25° TO +85° C SAFETY: RoHS COMPLIANT M3 R0.14 1.30 ± 0.012 0 PANEL CUTOUT 1-8. 1-9. 2. ELECTRICAL SCHEMATIC Dim range (mm) 0-1 1-6 6-18 18-50 50-120 120-250 250-500 Tolerance +/(mm) 0.15 0.20 0.30 0.50 0.70 0.90 1.20 CONTROLLED Qualtek Electronics Corp. Part Number: Description: L: 1.3mH C1: 0.1uF C2: 3300pF PPC DIVISION 860-06/005 EMI FILTER UNIT: in REV. B Approved / Date JJH / 01-14-03 Drawn / Date B.ZHANG 01-14-03 Checked / Date 01-14-03
