864-10-009

THESE DRAWINGS ARE THE PROPERTY OF QUALTEK ELECTRONICS AND NOT TO BE REPRODUCED FOR OR COMMUNICATED TO A THIRD PARTY WITHOUT THE EXPRESS WRITTEN PERMISSION OF AN OFFICER OF QUALTEK ELECTRONICS. 1. PHYSICAL DIMENSIONS 2.58MAX. 2.37 ± 0 M3(2X) 1.575 ± 0.02 1.99MAX. 1.12 ± 0.02 0.02 REVISION REV. B DESCRIPTION RoHS Compliancy DATE 06-01-06 APPROVED DP ELECTRICAL CHARACTERISTICS: 1-1. VOLTAGE RATING...................................115/250VAC 1-2. CURRENT RATING A. @ 115/250 VAC..................................10 A RMS MAX B. @ 250 VAC (VDE).................................6(4) A RMS MAX OPERATING FREQUENCY......................50/60Hz LEAKAGE CURRENT: EACH LINE TO GROUND A. @ 115 VAC 60Hz............................0.25 mA MAX B. @ 250 VAC 50Hz.............................0.45 mA MAX HIPOT RATING (FOR ONE MINUTE) A. LINE TO GROUND...........................2250 VDC B. LINE TO LINE.....................................1450 VDC MINIMUM INSERTION LOSS IN dB: (AT 50 OHM SYSTEM) .01 / / .05 10 2 .10 15 5 .15 20 8 .50 20 15 1.0 30 30 5.0 40 40 10 40 45 30 30 35 1.14 ± 0.02 0 1-3. 1-4. 2.5 ± 0.02 R0.0984MAX. PANEL CUTOUT 1-5. 1-6. FREQ. MHz 3.51MAX. 3.28MAX. COM. MODE dB DIF. MODE dB 1-7. 1-8. 1-9. OPERATING TEMPERATURE.................-25° TO +85° C SAFETY: RoHS COMPLIANT 2.37MAX. 2. ELECTRICAL SCHEMATIC 1.14MAX. Dim range (mm) 0-1 1-6 6-18 18-50 50-120 120-250 250-500 Tolerance +/(mm) 0.15 0.20 0.30 0.50 0.70 0.90 1.20 CONTROLLED Qualtek Electronics Corp. Part Number: Description: L: C1: C2: R: 1.6mH 0.22uF 3300pF 1MΩ PPC DIVISION 864-10/009 EMI FILTER UNIT: in REV. B Approved / Date JJH / 10-03-01 Drawn / Date B.ZHANG 10-03-01 Checked / Date 10-03-01
