MCO-1S-P

MCO-1S-P Programmable SMD Clock Oscillator HCMOS / TTL Features     Programmable wide frequency range 6 ~ 130 MHz Output signal HCMOS / TTL compatible Phase jitter < 80 ps Short lead times for samples: < 1 week max. Parameter Frequency range Supply voltage Supply current Frequency stability (*) Output signal Output level Output load Phase jitter Symmetry Rise / Fall time Tri-state function Operating temperature range Storage temperature range Packaging (*) All inclusive: Not usable for data transmission Specification MCO-1S3P 6 ~ 100 MHz +3.3 V 5 % < 33 mA ±25 ppm ±50 ppm V OH  0.9 Vdc 15 pF < 80 ps @ 12 kHz ~ 20 MHz from carrier frequency @ ½ Vdc 40 ~ 60 % MCO-1S5P 6 ~ 130 MHz +5.0 V 5 % < 50 mA -20 ~ +70 °C -40 ~ +85 °C CMOS or TTL V OL  0.1 Vdc 3 ~ 7 ns pin #1 = high or open pin #3  signal pin #1 = low pin #3  high impedance -20 ~ +70 °C commercial application -40 ~ +85 °C industrial application -55 ~ +125 °C In tape or Stick frequency stability vs. temperature, tolerance, aging, supply & load variation, on request Pin function #1 #2 #3 #4 Tri-state GND Output Vdc Example for solder pattern Do not design any conductive path between the pattern Example for IR reflow soldering temperature 2002/95/EC RoHS compliant QuartzCom AG sales@quartzcom.com www.quartzcom.com QuartzCom Asia sales-asia@quartzcom.com QuartzCom USA sales-usa@quartzcom.com 20 Apr. 10
