MCO-SM-P-4J

MCO-SM-P-4J Plastic moulded SMD Clock Oscillator Programmable Features     Applications: microprocessor, instrumentation, interface Output frequency up to 68 MHz Low price Programmable Parameter Frequency range Supply voltage Supply current Frequency stability (*) Output signal Output level Output load Jitter (rms) Symmetry Rise / Fall time Enable / Disable function Operating temperature range Storage temperature range Packaging unit (*) All inclusive: Customer specifications on request Specification MCO-SM-3P-4J +3.3 V 5 % 3 ~ 45 mA ±50 ppm ±100 ppm V OH  0.9 Vdc -20 ~ +70 °C -40 ~ +85 °C V OL  0 .1 Vdc 50 pF < 20 ps @ 12 kHz ~ 20 MHz from carrier frequency 45 ~ 55 % @ ½ Vdc 2 ~ 8 ns pin #1 = high or open pin #3  (E) enable pin #1 = low pin #3  (D) disabled to Hi-Z -20 ~ +70 °C commercial application -40 ~ +85 °C industrial application -55 ~ +125 °C tape & reel 500 or 1’000 pieces frequency stability vs. temperature, tolerance, aging, supply & load variation MCO-SM-5P-4J +5.0 V 5 % 1.544 ~ 68.00 MHz HCMOS / TTL compatible Pin function #1 #2 #3 #4 E/D or non connected GND Output Vdc Example for solder pattern Example for IR reflow soldering temperature 2002/95/EC RoHS compliant QuartzCom AG sales@quartzcom.com www.quartzcom.com QuartzCom Asia sales-asia@quartzcom.com QuartzCom USA sales-usa@quartzcom.com 20 Apr. 10
