210X-R10

MINIATURE WIREWOUND RESISTORS 1 WATT to 10 WATT RESISTORS CAPACITORS COILS DELAY LINES 200 SERIES RoHS Term.W is RoHS compliant & 260°C compatible Significant space savings! Tolerance to +0.01%, TCR to 5ppm/°C Wide resistance range: 0.005Ω to 250K Available on exclusive SWIFTTM delivery program All sizes available on Tape & Reel OPTIONS Option X: Low Inductance Option P: Increased Pulse Capability Option F: Flameproof Coating Option ER: 100-Hour Burn-In Also available: low thermal emf (opt.E), matched sets, cut & formed leads, special marking, 4-terminal, hi-rel screening, hermetic seal, non-standard values, increased voltage, etc. Customized components are an RCD speciality! TYPICAL SIZE COMPARISON 2W carbon composition 2W wirewound (standard) 2W wirewound (type 210) Typically half the size of conventional resistors! Type 202 is world’s smallest wirewound resistor! Series 200 resistors offer the same MIL-grade construction as Series 100 resistors except utilize proprietary materials and processing, enabling significant size reductions. Series 200 resistors are ideal when PCB real estate is at a premium! Highest grade materials enable excellent stability and environmental performance. DERATING: Power resistors reach elevated temperatures when operated near full wattage, and therefore should be mounted off the PCB and derated according to required stability levels. % OF RATED POWER 100 80 60 40 20 0 25 50 75 100 125 150 175 200 AMBIENT TEMPERATURE (°C) 225 250 275 300 ← 1.375” Min3 → ← A → Type 202 is 1.1” ← B → ↓ ↑ D →C← DIMENSIONS RCD Type Wattage Rating Maximum Voltage 1 Resistance Range A .150 ±.032 [ 3.81 ± .8] .250 ±.040 [6.35 ±1] .350 ±.040 [8.9 ±1] .500 ±.040 [ 12.7 ±1] .625 ±.040 [15.9 ±1] 1.040 ±.048 [26.4 ±1.2] B (Max) .200 [5.08] .300 [7.62] .480 [12.2] .595 [15.1] .765 [19.4] 1.125 [28.6] C2 .064 ±.02 [1.63 ± .5] .093 ±.025 [2.36 ± .6] .140 ±.032 [3.56 ± .8] .188 ±.032 [4.78 ± .8] .232 ±.032 [5.89 ± .8] .350 ±.032 [8.89 ± .8] Inch [mm] D (Nominal Diameter) Standard .020 [0.5] .020 [0.5] .031 [0.8] .031 [0.8] .040 [1.0] .040 [1.0] Optional N/A .024 (Opt."22") [0.6] N/A .040 (Opt."18") [1.0] N/A N/A 202 210 232 235 255 272 1 2 3 1.0W 2.0W 3.0W 5.0W 7.0W 10W 30V 40V 60V 157V 210V 600V .01Ω to 2K .01Ω to 10K .005Ω to 20K .005Ω to 40K .005Ω to 80K .005Ω to 250K Volt rating determined by E =√(PR), E not to exceed max. rating. Increased ratings available. Multiply by 0.7 for Opt. X Allow .032” additional for Option X and values below 1.0Ω Lead length applies to bulk packaged parts units, parts supplied on tape may be shorter (refer to taping specification) SPECIFICATIONS: Te m p e r a t u r e C o e f f i c i e nt t yp . ( C o ns ul t f a c t o r y fo r TC o n o p t. P ) .0 0 5 - .0 0 9 9 Ω : 6 0 0 p p m s td (2 0 0 , 3 0 0 p p m o p t.) .0 1 - .0 4 9 Ω: 3 0 0 p p m s td (1 0 0 , 2 0 0 p p m o p t.) .0 5 - .0 9 9 Ω 2 0 0 p p m s td (5 0 , 1 0 0 p p m o p t.) .1 - .9 9 Ω: 9 0 p p m s td (1 0 , 2 0 , 3 0 , 5 0 p p m o p t) 1 - 9 .9 Ω: 5 0 p p m s td (1 0 , 2 0 , 3 0 p p m o p t.) 1 0 Ω & a b o ve : 2 0 p p m s t d ( 5 , 1 0 p p m o p t . ) 1 t o 5 0 µ H t yp i c a l , d e p e nd s o n s i ze & r e s i s t a nc e va l ue . S p e c i f y O p t . X f o r no n- i nd uc t i ve p e r f o r m a nc e ( s e e b e l o w ) . ≤ 50Ω > 50Ω Ty p e 2 0 2 X - 2 3 5 X : 0 . 2 µ H M a x 0 . 3 7 µ H M a x Ty p e 2 5 5 X : 0 .3 µ H Ma x 0 .6 µ H Ma x Ty p e 2 7 2 X : 0 .6 µ H Ma x 1 .0 µ H Ma x 5 X ra te d W 2 0 2 -2 3 5 , 1 0 X ra te d W 2 5 5 -2 7 2 P/N DESIGNATION: RCD Type Options: X, P, F, ER, E, 22, 18 (leave blank if standard) 210 - 1001 - F B W In d u c t a n c e , S t a nd a r d Resis. Code: ≤1%: 3 signif. figures & multiplier, e.g. R100= 0.1Ω, 1R00= 1Ω,1000= 100Ω, 1001= 1KΩ. Resis. Code 2% - 10%: 2 signif. figures & multiplier, e.g. R10= 0.1Ω, 1R0= 1Ω,100= 10Ω, 101=100Ω, 102= 1KΩ. Use extra digits as needed: e.g. R005, R0075, R012 Tolerance: K=10%, J=5%, H=3%,F=1%, D=0.5%, C=0.25%, B=0.1%, A=0.05%, Q=0.02%, T=0.01% Packaging: B = Bulk, T = T&R Optional TC: 5= 5ppm, 10= 10ppm, etc., if 100ppm & above use 3-digit code: 101 = 100ppm, 201= 200ppm, etc. (leave blank if standard) Termination: W= Lead-free, Q= Tin/Lead (leave blank if either is acceptable, in which case RCD will select based on lowest price and quickest delivery In d u c t a n c e , O p t . X ( l e ve l s a s l o w a s 2 0 nH a va i l . ) O ve r l o a d , 5 S e c . D i e l e c t r i c S t r e n g t h 5 0 0 V ( 3 0 0 V Ty p e 2 0 2 ) , 1 K V a v a i l a b l e ( O p t . 3 3 ) RCD Components Inc, 520 E.Industrial Park Dr, Manchester, NH, USA 03109 rcdcomponents.com Tel: 603-669-0054 Fax: 603-669-5455 Email:sales@rcdcomponents.com FA014D Sale of this product is in accordance with GF-061. Specifications subject to change without notice. 44
