610-16100

ALUMINUM HOUSED RESISTORS RESISTORS CAPACITORS COILS DELAY LINES 600 SERIES RoHS Term.W is RoHS compliant & 260°C compatible Standard units feature lug terminals (605 - 630) or threaded terminals (635 & 640). Option L (605-625): Insulated stranded wires embedded into the case. Black TFE 18awg x 12”L with ¼” strip is standard (16awg TFE & 14awg PVC avail). Also available with 4 insulated lead wires (Opt.4L), and with a wide variety of terminals... quick-connect male (Opt. LM=.25x.032); female (Opt. LF=.25x.032”, LFS=.187x.020); ring terminal (Opt. LR=.145” I.D., LRR=.25” I.D.). Option 2T & 4T (605-625): Straight leadwires. 2T is 2-terminal design, 4T is 4-terminal. Each have 18awg x 1” min lead length. 16awg x 1” and 12AWG x .5” also available (12 AWG not avail in Opt 4T). Widest selection in the industry! 5 to 1000 Watt 0.005Ω to1MΩ, tolerance to .01%, TC to 5ppm High power and high pulse capacity in compact size Welded wirewound construction, low noise Available on exclusive SWIFT TM delivery program! Option X: Non-inductive Option P: Increased pulse capability Option ER: 100 hour burn-in per MIL-PRF-39009 Option B: Increased power Additional modifications: unanodized cases, custom marking, increased dielectric/creepage & working voltage, low thermal emf (opt.E), etc. Customized components are an RCD Specialty! A L D 605-630 View From Top B N H C Type 630 & 640 have 4 mounting holes A L D 635-640 View From Top B H FE 605-630 View From Side G Option 4R (605-630): 4-terminal design. 16AWG lug terminals are welded to standard terminals. FE 635-640 View From Side C G 3.00±.01” (640 only) 1/4-20,12-24 Option Q (605-630): .187x.020” male fast-on terminal; Opt. Q2 (610-625) is .250x.032” male terminal. Opt. Q & Q2 add 0.9 ±0.125” to Dim. D. SPECIFICATIONS: Consult factory for dimensions on liquid cooled design up to 1000 Watt RCD Type 605 MIL Type1 RE/RER60 Wattage,Mounted Std 7.5 Opt.B MIL 15 5 Resis. Voltage Range (Ω) Rating2 .005-20K 160 A ±.005 B ±.005 C ±.062 D ±.062 E ±.031 F ±.031 G ±.031 H ±.010 L ±.005 N ±.005 Mtg Screw 1 .444 .490 .600 1.125 .334 .646 .320 .065 .093 .050 #2 [11.3] [12.5] [15.2] [28.6] [8.5] [16.4] [8.2] [1.6] [2.4] [1.3] [M2] .562 .625 .750 1.375 .420 .800 .405 .075 .093 .086 #2 610 RE/RER65 12.5 20 10 .005-100K 265 [14.3] [15.9] [19.0] [35.0] [10.8] [20.3] [10.3] [1.9] [2.4] [2.2] [M2] .719 .781 1.062 1.938 .531 1.080 .546 .088 .125 .086 #4 615 RE/RER70 25 35 20 .005-200K 550 [18.3] [19.8] [27.0] [49.3 [13.5] [27.4] [13.9] [2.2] [3.2] [2.2] [M2.5] 1.563 .844 1.968 2.781 .609 1.140 .610 .088 .125 .086 #4 620 RE/RER75 50 60 30 .005-400K 1250 [39.7] [21.5] [50.0] [70.6] [15.6] [28.8] [15.5] [2.2] [3.2] [2.2] [M2.5] 1.563 .844 2.850 3.663 .609 1.140 .610 .088 .125 .086 #4 625 75 .01-500K 1900 [39.7] [21.5] [72.4] [93.0] [15.6] [28.8] [15.5] [2.2] [3.2] [2.2] [M2.5] 1.377±.01 1.457±.01 2.579 3.38±.09 1.053 1.839 .960±.05 .138±.03 .173±.01 .086 Min #8 630 100 0.1-100K 1900 [35.0] [37.0] [65.5] [85.9] [26.7] [46.7] [24.4] [3.5] [4.4] [2.2] [M4] #8 2.75±.01 2.25±.01 3.50 5.48±.09 1.812 2.812 1.75 .188±.03 .188±.01 n/a 635 RE77 100 150 75 0.1-600K 1900 [M4] [69.85] [57.15] [88.9] [139.14] [46.0] [71.42] [44.45] [4.78] [4.78] #8 3.875±.01 2.50±.01 4.50 7.00±.09 2.125 3.00 2.188 .250±.03 .188±.01 n/a 640 RE80 250 300 120 0.1-1M 2300 [M4] [98.42] [63.5] [114.3] [177.8] [53.98] [76.2] [55.58] [6.35] [4.78] Military part numbers are for reference only and do not imply qualification. 2 Max. voltage = ( PR)½ , not to exceed the value listed (increased ratings avail). Multiply by 0.7 for Opt.X. TYPICAL PERFORMANCE CHARACTERISTICS: Temp.Coefficient .0 0 5 - .0 0 9 9 Ω : .0 1 - .0 4 9 Ω : .0 5 - .0 9 9 Ω : .1 - .9 9 Ω : 1 - 9 .9 Ω : 1 0 Ω & a b o ve : 6 0 0 p p m s td (2 0 0 , 3 0 0 p p m o p t.) 3 0 0 p p m s td (1 0 0 , 2 0 0 p p m o p t.) 2 0 0 p p m s td (5 0 , 1 0 0 p p m o p t.) 9 0 p p m s td (1 0 , 2 0 , 3 0 , 5 0 p p m o p t) 5 0 p p m s td (1 0 , 2 0 , 3 0 p p m o p t.) 2 0 p p m s td (5 , 1 0 p p m o p t.) DERATING: Power rating is based on the use of a suitable heat sink and thermal compound to limit case temp. to 200°C. Derate wattage 0.44%/°C above 25°C. Recommended aluminum chassis area is 64in² x.040” thick for type 605 and 610, 83in² x.040” thick for type 615, 144in² x.060” thick for type 620, and 144in² x .125” for types 625 through 640. Without a heat sink, derate wattage rating by 60%. P/N DESIGNATION: 610 - 1001 - F B W Dielectric (DWV) Optional Standard3 605, 610 1K V 2KV (Opt.36), 2.5KV (Opt.34) 615, 620, 625 2K V 2.5KV (Opt.34), 3KV (Opt.41) 630, 635, 640 2.5KV 3KV (Opt.41), 4KV (Opt.65) Inductance, Opt.X ≤50Ω >50Ω 605 0.2uH Max 0.37uH Max 610, 615 0.3uH Max 0.6uH Max 620, 625 0.65uH Max 1.2uH Max 630, 635, 640 1.5uH Max 3.0uH Max Load Life (1000 hrs) ±1% (±2% for 625-640, and ±3% Opt.B) Moisture Resistance ±0.5% Overload 5x rated W, 5 Sec (V not to exceed DWV) Terminal Strength 10-lb pull test Operating Temp. -55°C to +250°C 3 The dielectric strength on Opt. L resistors is 50% of standard (available up to 3KV) RCD Type Options: X, Q2, Q, P, LRR, LR, LM, LFS, LF, L, ER, E, B, 65, 41, 36, 34, 16, 14, 4T, 4R, 4L (leave blank if std) Resis. Code: ≤1%: 3 signif. figures & multiplier, e.g. R010=0.01Ω, R100= 0.1Ω, 1R00= 1Ω,1000= 100Ω, 1001= 1KΩ Resis. Code 2% - 10%: 2 signif. figures & multiplier, e.g. R01=0.01Ω, R10= 0.1Ω, 1R0= 1Ω,100= 10Ω, 102= 1KΩ Tolerance: K=10%, J=5%, H=3%, G=2%, F=1%, D=0.5%, C=0.25%, B=0.1%, A=0.05%, Q=0.02%, T=0.01% Packaging: B = standard Non-std lead length for option L (inches): (12” = std) 4”, 16”, etc. Optional TC (leave blank if std): 5=5ppm, 10=10ppm; 20=20ppm; 30=30ppm; 50=50ppm; 101=100ppm, 201=200ppm, 301=300ppm) Termination: W= Lead-free, Q= Tin/Lead (leave blank if either is acceptable) RCD Components Inc, 520 E.Industrial Park Dr, Manchester, NH, USA 03109 rcdcomponents.com Tel: 603-669-0054 Fax: 603-669-5455 Email:sales@rcdcomponents.com FA018F Sale of this product is in accordance with GF-061. Specifications subject to change without notice. 46
