TSS-104-M

TANTALUM CHIP TANGOLDTM CAPACITORS RESISTORS CAPACITORS COILS DELAY LINES TS SERIES- General Purpose TSE SERIES- Low ESR Epoxy molded, UL94V-0 Flame Retardant Excellent humidity and surge performance Low leakage current -55° to +125°C operating temperature range Extended capacitance range and low profile designs available Top View Side View RoHS Term.W is RoHS compliant & 260°C compatible New! Mini 0805 case size RCD’s TangoldTM construction provides superior performance and wide capacitance range as a result of a solid slug of high-gain tantalum powders sintered under vacuum. The flame retardant epoxy molding ensures optimum environmental protection and dielectric strength. Non-standard values, low-profile packages, custom marking, military screening, fusible, etc., are available. DIMENSIONS (low profile version also available) Case Siz e S (0805) [2012] A (1206) [3216] B (1411) [3528] C (2412) [6032] D (2917) [7343] E (2917H) [7343H] L .079±.008 [2 ±0.2] .126±.008 [3.2±0.2] .138±.008 [3.5±0.2] .236±.012 [6.0±0.3] .287±.012 [7.3±0.3] .287±.012 [7.3±0.3] W .049±.008 [1.25±0.2] .063±.008 [1.6±0.2] .110±.008 [2.8±0.2] .126±.012 [3.2±0.3] .169±.012 [4.3±0.3] 169±.012 [4.3±0.3] H .047±.008 [1.2±0.2] 063±.008 [1.6±0.2] .075±.008 [1.9±0.2] .098±.012 [2.5±0.3] .110±.012 [2.8±0.3] .162±.012 [4.1±0.3] T .043±.008 [1.1 ±0.2] .047±.008 [1.2±0.2] .087±.008 [2.2±0.2] .087±.008 [2.2±0.2] .094±.008 [2.4±0.2] .094±.008 [2.4±0.2] S .020±.012 [.5±0.3] .031±.012 [0.8±0.3] .031±.012 [0.8±0.3] .051±.012 [1.3±0.3] .051±.012 [1.3±0.3] .051±.012 [1.3±0.3] + Anode ↓ T ↑ ← L → →S← ↓ H ←W→ Bottom View ↑ End View STANDARD CAPACITANCE AND ESR (Ω) VALUES (extended value range available in each size, ESR is typ.) Volt Rating 85°C2 4VDC (5VSurge) 6.3VDC (8V Surge) 10VDC(13V Surge) 16VDC(20V Surge) 20VDC(26V Surge) 25VDC(33V Surge) 35VDC(46V Surge) 50VDC(65V Surge) se se se TSE TSE uF Code Caze E'TS' 'ESR' Caze E'TS' 'ESR' Caze E'TS' Si Si Si SR SR SR 0.1 104 .15 154 .22 224 .33 334 .47 474 .68 684 S 30 1.0 105 A/S 14/25 A/S 13/25 1.5 155 S 30 A/S 12/25 A/S 10 2.2 225 S 25 A/S 9/20 6/NA A/S 7 3.3 335 A/S 9/20 4/NA A/S 7/12 6/NA B/A 5/5.5 4.7 475 A/S 7.5/14 3.5/NA B/A 5/6 NA/3.5 B/A 4/5 6.8 685 B/A 6/6.5 NA/3 B/A 4/5 1.2/2 B/A 3/4 10 106 B/A 4/6 1.2/2 B/A 3/4 1/2 B/A 2.5/3 15 156 B/A 3.5/4 1.2/2 C/B 2.5/3.2 .6/.7 C/B 2.2/2.8 22 226 C/B 2.5/3.2 .5/.6 C/B 2/2.5 .5/.6 C/B 1.8/2.4 33 336 C/B 2.2/2.8 .5/.5 D/C 1.3/1.8 NA/.3 D/C 1.1/1.6 47 476 D/C 1.3/1.8 NA/.5 D/C 1.1/1.6 .22/.25 D/C .9/1.2 68 686 D/C 1.1/1.6 .2/.25 D/C .9/1.6 .2/.2 D 0.9 100 107 D/C .9/1.3 .2/.2 D/C .9/1.4 .15/.3 D 0.9 150 157 D/C .7/1.0 .15/.3 D .9 .15 E 0.9 220 227 D .9 .15 E .9 .15 E 0.9 330 337 E .9 E .9 .15 E 0.9 .15 470 477 E .9 .15 1 Leakage current = 0.01CµfV (or 0.5µA, whichever is greater) 2 Derate voltage rating by .825%/°C above 85°C 'TSE' Case 'TS' ESR Size ESR 6/NA 6/NA NA/4 1.5/3 1.2/3 .8/2 .5/.7 .4/.7 .25/.3 .22/.3 .2 .15 .15 .15 .10 S S A/S A/S B/A B/A B/A C/B C/B C D/C D/C D/C D D E E 'TSE' Case 'TS' 'TSE' Case 'TS' ESR Size ESR ESR Size ESR S 25 S 25 S 25 S 25 25 S 25 A 14 25 A/S 12/25 8/NA A 10 11/20 6/NA A 9 5.5 B/A 7/8 8/12 6/NA B/A 5/6.5 NA/4.5 B 5 5.5/6.5 NA/4 B/A 3.5/5.3 1.5/4 B 4.5 4.5/5 2/4 C/B 2.5/3 NA/1.3 C 2.8 3.5/4 1.5/3 D/C 2.5/2.8 NA/.6 C 2.4 2.5/3.5 .8/1.2 D/C 1.8/2 NA/.6 D/C 1.4/2 2/2.8 .6/.8 D 1.3 NA/.5 D/C 1.2/1.8 1.8 .4 D 1.1 .35 D 1 1.1/1.6 .25/.35 D 0.9 .3 D .9 .9/1.5 .25/.3 D 0.9 .25 E .9 .9/1.4 .2/.3 E/D .9/.9 NA/.2 0.9 .15 E 0.9 .2 0.9 .15 0.9 .15 0.9 'TSE' Case 'TS' ESR Size ESR A 24 A 21 A 18 A 15 9 B/A 10/12 6 B 8 2/4 B 6.5 1.5 C/B 4.5/5.2 2.2 C 3.5 1.2 D/C 2.0/2.5 .6 D/C 1.5/2.2 NA/.6 D 1.3 .4/.6 D 1 .4 E .9 .4 E .9 .3 'TSE' ESR 10 6 6 6 2.5/4 2.5 2 2.5/3 1.5 NA/.8 .7/.7 .5 .4 .3 .3 Case 'TS' 'TSE' Size ESR ESR A 22 10 B/A 17/15 10/10 B 14 10 B 12 2.5 C/B 8 1.8/2.0 C/B 7 1.6/3.0 C 5.5 1.6 D/C 4/4.5 1/1.5 D /C 2.5 .8/1.5 D 2.0 .8 1.4 .6 D E .5 SPECIFICATIONS CAPACITANCE ∆C FROM INITIAL @20°C (120Hz) -55°C +85°C +125°C
