RE-2424SP

RE-2424SP

  • 厂商:

    RECOM

  • 封装:

  • 描述:

    RE-2424SP - 1 Watt SIP4 & SIP7 Single Output - Recom International Power

  • 数据手册
  • 价格&库存
RE-2424SP 数据手册
Features Unregulated Converters ● ● ● ● ● ● ● Industry Standard Pinout 1kVDC & 2kVDC Isolation UL94V-0 Package Material Optional Continuous Short Circuit Protected Fully Encapsulated Custom Solutions Available Efficiency to 85% ECONOLINE DC/DC-Converter RO & RE Series 1 Watt SIP4 & SIP7 Single Output Selection Guide Part Number SIP 4 RO-xx1.8S RO-xx3.3S RO-xx05S RO-xx09S RO-xx12S RO-xx15S SIP 7 RE-xx1.8S RE-xx3.3S RE-xx05S RE-xx09S RE-xx12S RE-xx15S (2kV) (H) (H) (H) (H) (H) (H) Input Voltage (VDC) 1.8, 3.3, 5, 9, 12, 15, 24 1.8, 3.3, 5, 9, 12, 15, 24 1.8, 3.3, 5, 9, 12, 15, 24 1.8, 3.3, 5, 9, 12, 15, 24 1.8, 3.3, 5, 9, 12, 15, 24 1.8, 3.3, 5, 9, 12, 15, 24 Output Voltage (VDC) 1.8 3.3 5 9 12 15 Output Current (mA) 555 303 200 111 83 66 Efficiency (%) 70 75 70-78 76-78 78-80 80-84 RO-xx24S RE-xx24S (H) 1.8, 3.3, 5, 9, 12, 15, 24 24 42 74-85 xx = Input Voltage * add Suffix “P” for Continuous Short Circuit Protection, e.g. RO-051.8S/P, RO-051.8S/HP Specifications (Core Operating Area) Input Voltage Range Output Voltage Accuracy Line Voltage Regulation Load Voltage Regulation (10% to 100% full load) Output Ripple and Noise (20MHz limited) Operating Frequency Efficiency at Full Load No Load Power Consumption Isolation Voltage Rated Working Voltage Isolation Voltage Rated Working Voltage Isolation Capacitance Isolation Resistance Short Circuit Protection P-Suffix Operating Temperature Range (free air convection) Storage Temperature Range Relative Humidity Package Weight MTBF (+25°C) (+85°C) RO types RE types using MIL-HDBK 217F RO types RE types 3 ±10% ±5% 1.2%/1% of Vin typ. 1.8V, 3.3V output types 5V output type 9V, 12V, 15V, 24V output types 20% max. 15% max. 10% max. 100mVp-p max. 50kHz min. / 100kHz typ. / 105kHz max. 70% min. / 80% typ. 101mW min. / 126mW typ. / 220mW max. (tested for 1 second) (long term isolation) H-Suffix H-Suffix (tested for 1 second) (long term isolation) 1000VDC min. see Application Notes 2000VDC min. see Application Notes 20pF min. / 75pF max. 10 GΩ min. 1 Second Continuous Output Power (%) 100 80 60 40 30 20 0 Derating-Graph (Ambient Temperature) -40°C to +85°C (see Graph) -55°C to +125°C 95% RH 1.4g 2.2g 985 x 10 hours 992 x 103 hours 200 x 103 hours 145 x 103 hours July-2006 Safe Operating Area 85 Operating Temperature °C -40 0 50 100 150 } Detailed Information see Application Notes chapter "MTBF" using MIL-HDBK 217F RO types RE types 16 www.recom-international.com ECONOLINE DC/DC-Converter Typical Characteristics RO & RE Series RO/RE-xx09S Efficiency / Load 100 80 60 RO/RE-xx05S Efficiency / Load 100 80 60 40 3.305 1205 0509 0505 Efficiency % 40 20 0 1209 3.309 Efficiency % 20 0 0% 20% 40% 60% Total Output current (%) 80% 100% 0% 20% 40% 60% Total Output current (%) 80% 100% Deviation / Load 25.000 20.000 25.000 20.000 Deviation / Load Deviation from Nominal (%) 15.000 10.000 5.000 0.000 -5.000 -10.000 Deviation from Nominal (%) 3.305 0505 15.000 10.000 5.000 0.000 -5.000 -10.000 3.309 0509 1205 1209 0% 20% 40% 60% Total Output current (%) 80% 100% 0% 20% 40% 60% Total Output current (%) 80% 100% RO/RE-xx12S Efficiency / Load 100 80 60 40 RO/RE-xx15S Efficiency / Load 100 80 60 0512 1212 1215 3.312 Efficiency % 40 20 0 0515 3.315 Efficiency % 20 0 0% 20% 40% 60% 80% 100% 0% 20% 40% 60% 80% 100% Total Output current (%) Total Output current (%) Deviation / Load 25.000 20.000 25.000 20.000 Deviation / Load Deviation from Nominal (%) Deviation from Nominal (%) 15.000 10.000 5.000 0.000 -5.000 -10.000 0512 1212 15.000 10.000 5.000 0.000 -5.000 -10.000 0515 3.315 3.312 0% 20% 40% 60% Total Output current (%) 80% 100% 1215 0% 20% 40% 60% Total Output current (%) 80% 100% www.recom-international.com July-2006 17 ECONOLINE DC/DC-Converter Package Style and Pinning (mm) RO & RE Series 3rd angle projection 4 PIN SIP Package 6.00 RECOM RO-0505S **** RECOM RO-0505S **** 10.00 0.51 typ. 4.10 0.51 typ. 1234 Recommended Footprint Details 11.50 0.25 1.9 Bottom View RO Pin Connections Pin # 1 2 3 Single –Vin +Vin –Vout 2.54 1.27 1.00 ø+0.15/–0 7.62 Top View 2.54 4 +Vout XX.X ± 0.5 mm XX.XX ± 0.25 mm 7 PIN SIP Package 6.00 RECOM RE-0505S **** RECOM RE-0505S **** 10.20 0.51 typ. 4.10 0.51 typ. 12 4 6 Recommended Footprint Details 19.60 1.27 2.0 Bottom View RE Pin Connections Pin # 1 2 4 Single +Vin –Vin –Vout 1.00 ø+0.15/–0 0.25 2.54 12.70 2.54 Top View 6 +Vout XX.X ± 0.5 mm XX.XX ± 0.25 mm 18 July-2006 www.recom-international.com
