RI-1207S

, Features Unregulated Converters ● ● ● ● ● ● ● Custom Solutions Available 1kVDC Isolation No External Components Required Optional Continuous Short Circuit Protected UL94V-0 Package Material No Heatsink Required Efficiency to 87% ECONOLINE DC/DC-Converter RI Series 2 Watt SIP4 Single Output Selection Guide Part Number SIP4 RI-xx3.3S RI-xx05S RI-xx07S RI-xx09S RI-xx12S RI-xx15S Input Voltage (VDC) 5, 9, 12, 15, 24 5, 9, 12, 15, 24 5, 9, 12, 15, 24 5, 9, 12, 15, 24 5, 9, 12, 15, 24 5, 9, 12, 15, 24 Output Voltage (VDC) 3.3 5 7 9 12 15 Output Current (mA) 606 400 285 222 167 133 83 Efficiency (%) 70-75 78-83 78-83 78-83 80-85 80-85 80-87 RI-xx24S 5, 9, 12, 15, 24 24 xx = Input Voltage * add Suffix “P” for Continuous Short Circuit Protection, e.g. RI-0505S/P Specifications (Core Operating Area) Input Voltage Range Output Voltage Accuracy Line Voltage Regulation Load Voltage Regulation (10% to 100% full load) Output Ripple and Noise (20MHz limited) Operating Frequency Efficiency at Full Load No Load Power Consumption Isolation Voltage Rated Working Voltage Isolation Capacitance Isolation Resistance Short Circuit Protection P-Suffix Operating Temperature Range (free air convection) Storage Temperature Range Relative Humidity Package Weight MTBF (+25°C) (+85°C) 70 3.3V output types 5V, output type 9V, 12V, 15V, 24V output types ±10% ±5% 1.2%/1% of Vin typ. 20% max. 15% max. 10% max. 200mVp-p max. 35kHz min. / 50kHz typ. / 85kHz max. 70% min. / 80% typ. 142mW min. / 185mW typ. / 252mW max. (tested for 1 second) 1000VDC min. (long term isolation) see Application Notes 30pF min. / 85pF max. Output Power (%) 100 80 60 40 20 0 -40 0 50 100 150 Derating-Graph (Ambient Temperature) 10 GΩ min. 1 Second Continuous -40°C to +85°C (see Graph) -55°C to +125°C 95% RH 1.4g using MIL-HDBK 217F using MIL-HDBK 217F July-2006 845 x 10 hours 160 x 103 hours 3 Safe Operating Area 85 Operating Temperature °C } Detailed Information see Application Notes chapter "MTBF" www.recom-international.com ECONOLINE DC/DC-Converter Typical Characteristics RI Series RI-xx05S Efficiency / Load 100 80 60 RI-xx3.3S Efficiency / Load 100 80 60 40 RI-xx07S Efficiency / Load 100 80 60 123.3 243.3 2405 1205 0507 2407 053.3 Efficiency % Efficiency % 40 20 0 0505 Efficiency % 40 20 0 1207 20 0 0% 20% 40% 60% 80% 100% 0% 20% 40% 60% 80% 100% 0% 20% 40% 60% Total Output current (%) 80% 100% Deviation / Load 25.000 20.000 25.000 20.000 Deviation / Load 25.000 20.000 Deviation / Load Deviation from Nominal (%) Deviation from Nominal (%) 15.000 10.000 5.000 0.000 -5.000 -10.000 15.000 10.000 5.000 0.000 -5.000 -10.000 Deviation from Nominal (%) 053.3 243.3 1205 2405 15.000 10.000 5.000 0.000 -5.000 -10.000 0507 123.3 0505 1207 2407 0% 20% 40% 60% Total Output current (%) 80% 10 0% 20% 40% 60% Total Output current (%) 80% 100% 0% 20% 40% 60% Total Output current (%) 80% 100% RI-xx12S Efficiency / Load 100 80 60 40 100 RI-xx15S Efficiency / Load 0515 2412 80 60 40 1212 Efficiency % 0512 1215 2415 Efficiency % 20 0 20 0 0% 20% 40% 60% Total Output current (%) 80% 100% 0% 20% 40% 60% 80% 100% Total Output current (%) Deviation / Load 25.000 20.000 25.000 20.000 Deviation / Load Deviation from Nominal (%) Deviation from Nominal (%) 15.000 10.000 5.000 0.000 -5.000 -10.000 2412 0512 15.000 10.000 5.000 0.000 -5.000 -10.000 1215 0515 1212 2415 0% 20% 40% 60% Total Output current (%) 80% 100% 0% 20% 40% 60% Total Output current (%) 80% 100% www.recom-international.com July-2006 71 ECONOLINE DC/DC-Converter Package Style and Pinning (mm) RI Series 3rd angle projection 4 PIN SIP Package 7.55 10.20 RECOM RI-0505 **** 0.51 typ. RECOM RI-0505 **** 4.10 0.51 typ. 1234 Recommended Footprint Details 1.00 ø+0.15/–0 2.54 0.25 2.03 Bottom View Pin Connections Pin # 1 2 3 4 Dual -Vin +Vin –Vout +Vout 11.50 1.27 7.62 Top View XX.X ± 0.5 mm XX.XX ± 0.25 mm 2.54 72 July-2006 www.recom-international.com
