RI-1215

ECONOLINE - DC/DC-Converter RI Series, 2 Watt, SIP4 (Single Output) Features ● ● ● 1kVDC Isolation No Heatsink Required No Extern. Components Required ● ● ● Custom Solutions Available UL94V-0 Package Material Efficiency to 80% Selection Guide Part Number SIP4 RI-XX3.3 RI-XX05 RI-XX07 RI-XX09 RI-XX12 RI-XX15 RI-XX24 Input Voltage (VDC) 5, 9, 12, 15, 24 5, 9, 12, 15, 24 5, 9, 12, 15, 24 5, 9, 12, 15, 24 5, 9, 12, 15, 24 5, 9, 12, 15, 24 5, 9, 12, 15, 24 Output Voltage (VDC) 3.3 5 7 9 12 15 24 Output Current (mA) 606 400 285 222 168 132 83 Efficiency (%) 70 75 72 76 78 80 80 Specifications (Core Operating Area) and Operating Temperature / Derating-Graph Input Voltage Input Filter Output Voltage Accuracy Line Voltage Regulation Load Voltage Regulation (10% to 100% full load) Efficiency at Full Load Isolation Voltage Isolation Resistance (Viso = 500VDC) Isolation Capacitance Short Circuit Protection Switching Frequency at Full Load Operating Temperature Storage Temperature Package Weight 3.3V output type 5V output type 7V, 9V, 12V, 15V, 24V output types ±10% Capacitor Type ±5% 1,2%/1% V Input 20% max. 15% max. 10% max. 70% min. 1.000VDC min. 10 GΩ min. 30pF min./85pF max. 1 Second 35kHz min. / 85kHz max. –40°C to +85°C (see Graph) -55°C to +125°C 1.4g 4.0 3.0 Output Power (Watts) 2.0 Safe Operating Area 1.0 0 -40 0 50 100 125 150 85 Operating Temperature ˚C www.recom-international.com August 2002 EC 51 ECONOLINE - DC/DC-Converter RI Series, 2 Watt, SIP4 (Single Output) Package Style and Pinning (mm) 4 PIN SIP Package 3rd angle projection 11.50 7.55 Pin Connections RI-0505 RECOM **** RI-0505 RECOM **** Pin # 1 2 3 4 Dual -Vin +Vin –Vout +Vout 10.20 0.51 typ. 4.10 0.75 typ. 1234 1234 0.25 7.62 1.27 typ. Recommended Footprint Details 2.54 2.54 1.00 ø+0.15/–0 XX.X ± 0.5 mm XX.XX ± 0.25 mm EC 52 August 2002 www.recom-international.com
