ECONOLINE - DC/DC-Converter
RS Series, 2 Watt, SIP8, Regulated, Isolated (Single Output) Features
● ● ● ●
2:1 Wide Range Voltage Input 1kVDC Isolation Efficiency to 83% UL 94V-0 Package Material
● ●
0.05% Line Regulation Continuous Short Circiut Protection with Current Foldback ● Low Noise
Selection Guide
Part Number SIP8 RS-0505 RS-0509 RS-0512 RS-0515 RS-1205 RS-1209 RS-1212 RS-1215 RS-2405 RS-2409 RS-2412 RS-2415 RS-4805 RS-4809 RS-4812 RS-4815 Input Voltage Range (VDC) 5-9 5-9 5-9 5-9 9-18 9-18 9-18 9-18 18-36 18-36 18-36 18-36 36-72 36-72 36-72 36-72 Rated Output Voltage (VDC) 5 9 12 15 5 9 12 15 5 9 12 15 5 9 12 15 Output Current at Full Load (mA) 400 222 167 133 400 222 167 133 400 222 167 133 400 222 167 133 SIP8 Package Style
Capacitance
Cin Cout 5-9V, 9-18V & 18-36V input types 36V -72V input types 36V-72V input types 10µF, 50V 10µF, 100V 100µF, 25V
www.recom-international.com
August 2002
EC 61
ECONOLINE - DC/DC-Converter
RS Series, 2 Watt, SIP8, Regulated, Isolated (Single Output) Electrical Specifications (measured at TA = 25°C, at nominal input voltage and rated output current unless otherwise specified)
Input Voltage Range Output Accuracy Rated Power Isolation Voltage Ripple & Noise (B/W = 20MHz) Line Regulation Load Regulation (10% to 100% Load) Switching Frequency at Full Load Short Circuit Protection Operating Temperature Range Storage Temperature Range Efficiency 2:1 ±1% typ. 2 W max. 1kVDC
Output Power (Watts) 1.5 1.0 Safe Operating Area 0.5 0 -40 0 50 100 125 150 80 Operating Temperature ˚C 2.0
50mV p-p max. ±0.2% max. ±0,5% typ. 85kHz min. Continuous –40°C to +80°C (see graph) –50°C to +125°C up to 83%
Package Style and Pinning (mm)
8 Pin SIP Package Style
Cin
0.25±0.05 2.0±0.50 123 5678 3.20 typ.
Cout
All RS-XXXX types 10uF, 100V Philips Part No. 15162109 100uF, 25V Philips Part No. 13556101
Recommended Footprint Details
2.54
21.80 max. 9.20 max.
1.0ø+0.15/–0 2.54
Pin 3 (CTRL) This pin provides an Off function which puts the converter into a low power mode. When the pin is ‘high’ the converter is OFF and when the pin is high ‘Z’ the converter is ON. There is no allowed low state for this pin. Voltage to be applied via a limiting resistor with a recommended value of 1K for RS05xx; 3.3K for RS-12xx; RS-24xx and 10K for RS-48xx) Pin 5 (NE) This pin is used internally and must have no external connection. Pin 8 (Cs) This pin provides a connection point to the main reservoir capacitor. Additional capacitance can be added from this to pin 7. Any low esr capacitor will improve ripple and noise in some measure. The benefit of this access point over simple additional output filter inductor. Maximum values of external capacitance will be depend on the output voltage/loading of the converter and the desired ripple figure. Starting values can be in the range of 100uF.
Control Pin Input Current:
11.10 max. 3.10min. 0.50±0.05 2.54 typ.
RS-0505 RECOM ****
10mA
0.50±0.05
Voltage Set Point Accuracy with external input/output capacitors refer to recommended test circuit: Control Pin (CTRL) Input Current, control voltage applied via 1K resistor, output voltage must reduce to 0V:
typ. ± 1% max. ±2%
Pin Connections Pin # Single Description 1 2 3 4 5 6 7 8 NE +Vout OVout CS GND +Vin CTRL Negative input Positive input Control input (can be left open) Not fitted No exernal connection allowed Positive output Negative output Optional external capacitor
typ. 3mA max. 6mA
External capacitance Although these converter will work without external capacitors, they are necessary in order to guarantee the full parametric performance over the full line load range. All parts have been tested and characterised using the following recommended values and test circuit.
D2 C5 C6
C S Pin 8
L1
++ Pin 7 0V–
VO
External Cap.
EC 62
August 2002
www.recom-international.com
