R8C/20 Group, R8C/21 Group RENESAS MCU REJ03B0120-0200 Rev.2.00 Aug 27, 2008 1. Overview This MCU is built using the high-performance silicon gate CMOS process using the R8C CPU core and is packaged in a 48-pin plastic molded LQFP. This MCU operates using sophisticated instructions featuring a high level of instruction efficiency. With 1 Mbyte of address space, it is capable of executing instructions at high speed. This Furthermore, the data flash (1 KB x 2 blocks) is embedded in the R8C/21 Group. The difference between R8C/20 and R8C/21 Groups is only the existence of the data flash. Their peripheral functions are the same. 1.1 Applications Automotive, etc. Rev.2.00 Aug 27, 2008 REJ03B0120-0200 Page 1 of 41 R8C/20 Group, R8C/21 Group 1. Overview 1.2 Performance Overview Table 1.1 outlines the Functions and Specifications for R8C/20 Group and Table 1.2 outlines the Functions and Specifications for R8C/21 Group. Table 1.1 CPU Functions and Specifications for R8C/20 Group Item Specification Number of fundamental instructions 89 instructions Minimum instruction execution time 50 ns (f(XIN) = 20 MHz, VCC = 3.0 to 5.5 V) 100 ns (f(XIN) = 10 MHz, VCC = 2.7 to 5.5 V) Operating mode Single-chip Address space 1 Mbyte Memory capacity Refer to Table 1.3 Product Information for R8C/20 Group Peripheral Ports I/O ports: 41 pins, Input port: 3 pins Function Timers Timer RA: 8 bits x 1 channel, Timer RB: 8 bits x 1 channel (Each timer equipped with 8-bit prescaler) Timer RD: 16 bits x 2 channel (Circuits of input capture and output compare) Timer RE: With compare match function Serial interface 1 channel (UART0) Clock synchronous I/O, UART 1 channel (UART1) UART Clock synchronous serial interface 1 channel I2C bus interface(2), Clock synchronous serial I/O with chip select LIN module Hardware LIN: 1 channel (timer RA, UART0) A/D converter 10-bit A/D converter: 1 circuit, 12 channels Watchdog timer 15 bits x 1 channel (with prescaler) Reset start selectable Interrupt Internal: 11 sources, External: 5 sources, Software: 4 sources, Priority level: 7 levels Clock generation circuits 2 circuits XIN clock generation circuit (with on-chip feedback resistor) On-chip oscillator (high speed, low speed) High-speed on-chip oscillator has frequency adjustment function. Oscillation stop detection Stop detection of XIN clock oscillation function Voltage detection circuit On-chip Power-on reset circuit include On-chip Electric Supply voltage VCC = 3.0 to 5.5 V (f(XIN) = 20 MHz)(J version) Characteristics VCC = 3.0 to 5.5 V (f(XIN) = 16 MHz)(K version) VCC = 2.7 to 5.5 V (f(XIN) = 10 MHz) Current consumption Typ. 11.0 mA (VCC = 5 V, f(XIN) = 20 MHz, High-speed onchip oscillator stopping) Typ. 5.3 mA (VCC = 5 V, f(XIN) = 10 MHz, High-speed on-chip oscillator stopping) Flash Memory Programming and erasure voltage VCC = 2.7 to 5.5 V Programming and erasure 100 times endurance Operating Ambient Temperature -40 to 85°C -40 to 125°C (option(1)) Package 48-pin mold-plastic LQFP NOTES: 1. When using options, be sure to inquire about the specification. 2. I2C bus is a registered trademark of Koninklijke Philips Electronics N.V. Rev.2.00 Aug 27, 2008 REJ03B0120-0200 Page 2 of 41 R8C/20 Group, R8C/21 Group 1. Overview Table 1.2 CPU Functions and Specifications for R8C/21 Group Item Specification Number of fundamental instructions 89 instructions Minimum instruction execution time 50 ns (f(XIN) = 20 MHz, VCC = 3.0 to 5.5 V) 100 ns (f(XIN) = 10 MHz, VCC = 2.7 to 5.5 V) Operating mode Single-chip Address space 1 Mbyte Memory capacity Refer to Table 1.4 Product Information for R8C/21 Group Peripheral Ports I/O ports: 41 pins, Input port: 3 pins Function Timers Timer RA: 8 bits x 1 channel, Timer RB: 8 bits x 1 channel (Each timer equipped with 8-bit prescaler) Timer RD: 16 bits x 2 channel (Circuits of input capture and output compare) Timer RE: With compare match function Serial interface 1 channel (UART0) Clock synchronous I/O, UART 1 channel (UART1) UART Clock synchronous serial interface 1 channel I2C bus interface(2), Clock synchronous serial I/O with chip select LIN module Hardware LIN: 1 channel (Timer RA, UART0) A/D converter 10-bit A/D converter: 1 circuit, 12 channels Watchdog timer 15 bits x 1 channel (with prescaler) Reset start selectable Interrupts Internal: 11 sources, External: 5 sources, Software: 4 sources, Priority level: 7 levels Clock generation circuits 2 circuits XIN clock generation circuit (with on-chip feedback resistor) On-chip oscillator (high speed, low speed) High-speed on-chip oscillator has frequency adjustment function. Oscillation stop detection Stop detection of XIN clock oscillation function Voltage detection circuit On-chip Power-on reset circuit include On-chip Electric Supply voltage VCC = 3.0 to 5.5 V (f(XIN) = 20 MHz)(J version) Characteristics VCC = 3.0 to 5.5 V (f(XIN) = 16 MHz)(K version) VCC = 2.7 to 5.5 V (f(XIN) = 10 MHz) Current consumption Typ. 11.0 mA (VCC = 5 V, f(XIN) = 20 MHz, High-speed onchip oscillator stopping) Typ. 5.3 mA (VCC = 5 V, f(XIN) = 10 MHz, High-speed on-chip oscillator stopping) Flash Memory Programming and erasure voltage VCC = 2.7 to 5.5 V Programming and erasure 10,000 times (data flash) endurance 1,000 times (program ROM) Operating Ambient Temperature -40 to 85°C -40 to 125°C (option(1)) Package 48-pin mold-plastic LQFP NOTES: 1. When using options, be sure to inquire about the specification. 2. I2C bus is a registered trademark of Koninklijke Philips Electronics N.V. Rev.2.00 Aug 27, 2008 REJ03B0120-0200 Page 3 of 41 R8C/20 Group, R8C/21 Group 1. Overview 1.3 Block Diagram Figure 1.1 shows a Block Diagram. 8 8 8 6 3 3 8 I/O port Port P0 Port P1 Port P2 Port P3 Port P4 Port P6 Timer A/D converter (10 bits × 12 channels) UART or clock synchronous serial I/O (8 bits × 1 channel) System clock generation circuit XIN-XOUT High-speed on-chip oscillator Low-speed on-chip oscillator Timer RA (8 bits) Timer RB (8 bits) Timer RD (16 bits × 2 channels) Timer RE (8 bits) UART (8 bits × 1 channel) I2C bus interface or clock synchronous serial I/O with chip select (8 bits × 1 channel) LIN module (1 channel) Watchdog timer (15 bits) R8C CPU core R0H R1H R2 R3 A0 A1 FB R0L R1L SB USP ISP INTB PC FLG Memory ROM(1) RAM(2) Multiplier NOTES: 1. ROM size depends on MCU type. 2. RAM size depends on MCU type. Figure 1.1 Block Diagram Rev.2.00 Aug 27, 2008 REJ03B0120-0200 Page 4 of 41 R8C/20 Group, R8C/21 Group 1. Overview 1.4 Product Information Table 1.3 lists Product Information for R8C/20 Group and Table 1.4 lists Product Information for R8C/21 Group. Table 1.3 Product Information for R8C/20 Group ROM Capacity 32 Kbytes 48 Kbytes 64 Kbytes 96 Kbytes 128 Kbytes(1) 32 Kbytes 48 Kbytes 64 Kbytes 96 Kbytes 128 Kbytes(1) RAM Capacity 2 Kbytes 2.5 Kbytes 3 Kbytes 5 Kbytes 6 Kbytes 2 Kbytes 2.5 Kbytes 3 Kbytes 5 Kbytes 6 Kbytes Package Type PLQP0048KB-A PLQP0048KB-A PLQP0048KB-A PLQP0048KB-A PLQP0048KB-A PLQP0048KB-A PLQP0048KB-A PLQP0048KB-A PLQP0048KB-A PLQP0048KB-A Current of Aug. 2008 Remarks J version Flash memory version Type No. R5F21206JFP R5F21207JFP R5F21208JFP R5F2120AJFP R5F2120CJFP R5F21206KFP R5F21207KFP R5F21208KFP R5F2120AKFP R5F2120CKFP K version NOTE: 1. Do not use addresses 20000h to 23FFFh because these areas are used for the emulator debugger. Refer to 23. Notes on Emulator Debugger of Hardware Manual. Part number R 5 F 21 20 6 J XXX FP Package type: FP: PLQP0048KB-A (0.5 mm pin-pitch, 7 mm square body) ROM number Classification J: Operating ambient temperature -40°C to 85°C (J version) K: Operating ambient temperature -40°C to 125°C (K version) ROM capacity 6: 32 KB 7: 48 KB 8: 64 KB A: 96 KB C: 128 KB R8C/20 Group R8C/2x Series Memory type F: Flash memory version Renesas MCU Renesas semiconductors Figure 1.2 Type Number, Memory Size, and Package of R8C/20 Group Rev.2.00 Aug 27, 2008 REJ03B0120-0200 Page 5 of 41 R8C/20 Group, R8C/21 Group 1. Overview Table 1.4 Product Information for R8C/21 Group ROM Capacity Program ROM Data Flash 32 Kbytes 1 Kbyte X 2 48 Kbytes 1 Kbyte X 2 64 Kbytes 1 Kbyte X 2 96 Kbytes 1 Kbyte X 2 128 Kbytes(1) 1 Kbyte X 2 32 Kbytes 48 Kbytes 64 Kbytes 96 Kbytes 1 Kbyte X 2 1 Kbyte X 2 1 Kbyte X 2 1 Kbyte X 2 (1) 1 Kbyte X 2 128 Kbytes RAM Capacity 2 Kbytes 2.5 Kbytes 3 Kbytes 5 Kbytes 6 Kbytes 2 Kbytes 2.5 Kbytes 3 Kbytes 5 Kbytes 6 Kbytes Package Type PLQP0048KB-A PLQP0048KB-A PLQP0048KB-A PLQP0048KB-A PLQP0048KB-A PLQP0048KB-A PLQP0048KB-A PLQP0048KB-A PLQP0048KB-A PLQP0048KB-A Current of Aug. 2008 Remarks J version Flash memory version Type No. R5F21216JFP R5F21217JFP R5F21218JFP R5F2121AJFP R5F2121CJFP R5F21216KFP R5F21217KFP R5F21218KFP R5F2121AKFP R5F2121CKFP K version NOTE: 1. Do not use addresses 20000h to 23FFFh because these areas are used for the emulator debugger. Refer to 23. Notes on Emulator Debugger of Hardware Manual. Part number R 5 F 21 21 6 J XXX FP Package type: FP: PLQP0048KB-A (0.5 mm pin-pitch, 7 mm square body) ROM number Classification J: Operating ambient temperature -40°C to 85°C (J version) K: Operating ambient temperature -40°C to 125°C (K version) ROM capacity 6: 32 KB 7: 48 KB 8: 64 KB A: 96 KB C: 128 KB R8C/21 Group R8C/2x Series Memory type F: Flash memory version Renesas MCU Renesas semiconductors Figure 1.3 Type Number, Memory Size, and Package of R8C/21 Group Rev.2.00 Aug 27, 2008 REJ03B0120-0200 Page 6 of 41 R8C/20 Group, R8C/21 Group 1. Overview 1.5 Pin Assignments Figure 1.4 shows Pin Assignments (Top View). P6_7/INT3/RXD1 P1_2/KI2/AN10 Pin assignments (top view) P1_0/KI0/AN8 P1_1/KI1/AN9 P3_0/TRAO P3_1/TRBO P0_7/AN0 P6_6/INT2/TXD1 26 36 35 34 33 32 31 30 29 28 27 P0_6/AN1 P0_5/AN2 P0_4/AN3 P4_2/VREF P6_0/TREO P6_2 P6_1 P0_3/AN4 P0_2/AN5 P0_1/AN6 P0_0/AN7 P3_7/SSO 37 38 39 40 41 42 43 44 45 46 47 48 10 11 12 1 2 3 4 5 6 7 8 9 25 P4_5/INT0 P6_3 P6_4 P6_5 24 23 22 21 20 P1_3/KI3/AN11 P1_4/TXD0 P1_5/RXD0/(TRAIO)/(INT1)(2) P1_6/CLK0 P1_7/TRAIO/INT1 P2_0/TRDIOA0/TRDCLK P2_1/TRDIOB0 P2_2/TRDIOC0 P2_3/TRDIOD0 P2_4/TRDIOA1 P2_5/TRDIOB1 P2_6/TRDIOC1 R8C/20 Group, R8C/21 Group 19 18 17 16 15 14 13 P3_3/SSI P4_3 P4_4 P3_5/SCL/SSCK P3_4/SDA/SCS NOTES: 1. P4_7 is an input-only port. 2. Can be assigned to the pin in parentheses by a program. 3. Confirm the pin 1 position on the package by referring to the package dimensions. Package: PLQP0048KB-A 0.5 mm pin pitch, 7 mm square body Figure 1.4 Pin Assignments (Top View) Rev.2.00 Aug 27, 2008 REJ03B0120-0200 Page 7 of 41 P2_7/TRDIOD1 P4_7/XOUT VSS/AVSS MODE RESET P4_6/XIN (1) VCC/AVCC R8C/20 Group, R8C/21 Group 1. Overview 1.6 Pin Functions Table 1.5 lists the Pin Functions and Table 1.6 lists the Pin Name Information by Pin Number. Table 1.5 Type Power Supply Input Analog Power Supply Input Reset Input MODE XIN Clock Input XIN Clock Output VCC VSS AVCC, AVSS RESET MODE XIN XOUT Pin Functions Symbol I/O Type I I I I I O Description Apply 2.7 V to 5.5 V to the VCC pin. Apply 0 V to the VSS pin. Applies the power supply for the A/D converter. Connect a capacitor between AVCC and AVSS. Input “L” on this pin resets the MCU. Connect this pin to VCC via a resistor. These pins are provided for the XIN clock generation circuit I/O. Connect a ceramic resonator or a crystal oscillator between the XIN and XOUT pins. To use an externally derived clock, input it to the XIN pin and leave the XOUT pin open. INT interrupt input pins. INT0 Timer RD input pins. INT1 Timer RA input pins. Key input interrupt input pins. Timer RA I/O pin. Timer RA output pin. Timer RB output pin. Timer RD I/O ports. INT Interrupt Input INT0 to INT3 I Key Input Interrupt Timer RA Timer RB Timer RD KI0 to KI3 TRAIO TRAO TRBO TRDIOA0, TRDIOA1, TRDIOB0, TRDIOB1, TRDIOC0, TRDIOC1, TRDIOD0, TRDIOD1 TRDCLK TREO CLK0 RXD0, RXD1 TXD0, TXD1 I I/O O O I/O I O I/O I O I/O I/O I/O I/O I/O I/O I I I/O External clock input pin. Divided clock output pin. Transfer clock I/O pin. Serial data input pins. Serial data output pins. Clock I/O pin. Data I/O pin. Data I/O pin. Chip-select signal I/O pin. Clock I/O pin. Data I/O pin. Reference voltage input pin to A/D converter. Analog input pins to A/D converter. CMOS I/O ports. Each port contains an input/output select direction register, allowing each pin in that port to be directed for input or output individually. Any port set to input can select whether to use a pull-up resistor or not by a program. Timer RE Serial Interface I2C Bus Interface Clock Synchronous Serial I/O with Chip Select SCL SDA SSI SCS SSCK SSO Reference Voltage Input VREF A/D Converter I/O Port AN0 to AN11 P0_0 to P0_7, P1_0 to P1_7, P2_0 to P2_7, P3_0, P3_1, P3_3 to P3_5, P3_7, P4_3 to P4_5, P6_0 to P6_7 P4_2, P4_6, P4_7 Input Port I Input only ports. I: Input O: Output I/O: Input and output Rev.2.00 Aug 27, 2008 REJ03B0120-0200 Page 8 of 41 R8C/20 Group, R8C/21 Group 1. Overview Table 1.6 Pin Name Information by Pin Number Port P3_5 P3_3 P3_4 MODE P4_3 P4_4 I/O Pin Functions for of Peripheral Modules Clock Synchronous Serial A/D I2C Bus Timer Serial I/O Interface Interface Converter with Chip Select SSCK SCL SSI SDA SCS Pin Control Pin Number 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 Interrupt RESET XOUT P4_7 VSS/AVSS XIN P4_6 VCC/AVCC P2_7 P2_6 P2_5 P2_4 P2_3 P2_2 P2_1 P2_0 P1_7 P1_6 P1_5 P1_4 P1_3 P4_5 P6_6 P6_7 P1_2 P1_1 P1_0 P3_1 P3_0 P6_5 P6_4 P6_3 P0_7 P0_6 P0_5 P0_4 P4_2 P6_0 P6_2 P6_1 P0_3 P0_2 P0_1 P0_0 P3_7 INT1 (INT1)(1) KI3 INT0 INT2 INT3 KI2 KI1 KI0 TRDIOD1 TRDIOC1 TRDIOB1 TRDIOA1 TRDIOD0 TRDIOC0 TRDIOB0 TRDIOA0/TRDCLK TRAIO (TRAIO)(1) CLK0 RXD0 TXD0 AN11 INT0 TXD1 RXD1 AN10 AN9 AN8 TRBO TRAO AN0 AN1 AN2 AN3 TREO VREF AN4 AN5 AN6 AN7 SSO NOTE: 1. Can be assigned to the pin in parentheses by a program. Rev.2.00 Aug 27, 2008 REJ03B0120-0200 Page 9 of 41 R8C/20 Group, R8C/21 Group 2. Central Processing Unit (CPU) 2. Central Processing Unit (CPU) Figure 2.1 shows the CPU Registers. The CPU contains 13 registers. Of these, R0, R1, R2, R3, A0, A1, and FB comprise a register bank. Two sets of register banks are provided. b31 b15 b8b7 b0 R2 R3 R0H (high-order of R0) R0L (low-order of R0) R1H (high-order of R1) R1L (low-order of R1) Data registers(1) R2 R3 A0 A1 FB b19 b15 b0 Address registers(1) Frame base registers(1) INTBH INTBL Interrupt table register The 4-high order bits of INTB are INTBH and the 16-low order bits of INTB are INTBL. b19 b0 PC Program counter b15 b0 USP ISP SB b15 b0 User stack pointer Interrupt stack pointer Static base register FLG b15 b8 b7 b0 Flag register IPL U I OBSZDC Carry flag Debug flag Zero flag Sign flag Register bank select flag Overflow flag Interrupt enable flag Stack pointer select flag Reserved area Processor interrupt priority level Reserved area NOTE: 1. A register bank comprises these registers. Two sets of register banks are provided. Figure 2.1 CPU Registers Rev.2.00 Aug 27, 2008 REJ03B0120-0200 Page 10 of 41 R8C/20 Group, R8C/21 Group 2. Central Processing Unit (CPU) 2.1 Data Registers (R0, R1, R2 and R3) R0 is a 16-bit register for transfer, arithmetic, and logic operations. The same applies to R1 to R3. R0 can be split into high-order bit (R0H) and low-order bit (R0L) to be used separately as 8-bit data registers. The same applies to R1H and R1L as R0H and R0L. R2 can be combined with R0 to be used as a 32-bit data register (R2R0). The same applies R3R1 as R2R0. 2.2 Address Registers (A0 and A1) A0 is a 16-bit register for address register indirect addressing and address register relative addressing. They also are used for transfer, arithmetic and logic operations. The same applies to A1 as A0. A1 can be combined with A0 to be used a 32-bit address register (A1A0). 2.3 Frame Base Register (FB) FB is a 16-bit register for FB relative addressing. 2.4 Interrupt Table Register (INTB) INTB, a 20-bit register, indicates the start address of an interrupt vector table. 2.5 Program Counter (PC) PC, 20 bits wide, indicates the address of an instruction to be executed. 2.6 User Stack Pointer (USP) and Interrupt Stack Pointer (ISP) The stack pointer (SP), USP and ISP, are 16 bits wide each. The U flag of FLG is used to switch between USP and ISP. 2.7 Static Base Register (SB) SB is a 16-bit register for SB relative addressing. 2.8 Flag Register (FLG) FLG is a 11-bit register indicating the CPU status. 2.8.1 Carry Flag (C) The C flag retains a carry, borrow, or shift-out bit that has occurred in the arithmetic and logic unit. 2.8.2 Debug Flag (D) The D flag is for debug only. Set to 0. 2.8.3 Zero Flag (Z) The Z flag is set to 1 when an arithmetic operation resulted in 0; otherwise, 0. 2.8.4 Sign Flag (S) The S flag is set to 1 when an arithmetic operation resulted in a negative value; otherwise, 0. 2.8.5 Register Bank Select Flag (B) The register bank 0 is selected when the B flag is 0. The register bank 1 is selected when this flag is set to 1. 2.8.6 Overflow Flag (O) The O flag is set to 1 when the operation resulted in an overflow; otherwise, 0. Rev.2.00 Aug 27, 2008 REJ03B0120-0200 Page 11 of 41 R8C/20 Group, R8C/21 Group 2. Central Processing Unit (CPU) 2.8.7 Interrupt Enable Flag (I) The I flag enables a maskable interrupt. An interrupt is disabled when the I flag is set to 0, and are enabled when the I flag is set to 1. The I flag is set to 0 when an interrupt request is acknowledged. 2.8.8 Stack Pointer Select Flag (U) ISP is selected when the U flag is set to 0; USP is selected when the U flag is set to 1. The U flag is set to 0 when a hardware interrupt request is acknowledged or the INT instruction of software interrupt numbers. 0 to 31 is executed. 2.8.9 Processor Interrupt Priority Level (IPL) IPL, 3 bits wide, assigns processor interrupt priority levels from level 0 to level 7. If a requested interrupt has greater priority than IPL, the interrupt is enabled. 2.8.10 Reserved Bit If necessary, set to 0. When read, the content is undefined. Rev.2.00 Aug 27, 2008 REJ03B0120-0200 Page 12 of 41 R8C/20 Group, R8C/21 Group 3. Memory 3. 3.1 Memory R8C/20 Group Figure 3.1 shows a Memory Map of R8C/20 Group. The R8C/20 Group has 1 Mbyte of address space from address 00000h to FFFFFh. The internal ROM is allocated lower addresses, beginning with address 0FFFFh. For example, a 48-Kbyte internal ROM is allocated addresses 04000h to 0FFFFh. The fixed interrupt vector table is allocated addresses 0FFDCh to 0FFFFh. They store the starting address of each interrupt routine. The internal RAM is allocated higher addresses, beginning with address 00400h. For example, a 2.5-Kbyte internal RAM is allocated addresses 00400h to 00DFFh. The internal RAM is used not only for storing data but also for calling subroutines and as stacks when interrupt requests are acknowledged. Special function registers (SFR) are allocated addresses 00000h to 002FFh. The peripheral function control registers are allocated here. All addresses within the SFR, which have nothing allocated are reserved for future user and cannot be accessed by users. 00000h SFR (Refer to 4. Special Function Registers (SFRs)) 002FFh 00400h Internal RAM 0XXXXh 01300h 02000h 03000h Reserved area 0FFDCh Internal RAM 0SSSSh 0YYYYh Undefined instruction Overflow BRK instruction Address match Single step Watchdog timer•oscillation stop detection•voltage detection Internal ROM (program ROM) 0FFFFh ZZZZZh FFFFFh Internal ROM(2) (program ROM) 0FFFFh Address break (Reserved) Reset NOTES: 1. The blank regions are reserved. Do not access locations in these regions. 2. Do not use addresses 20000h to 23FFFh because these areas are used for the emulator debugger. Refer to 23. Notes on Emulator Debugger of Hardware Manual. Internal ROM Part Number Size Address 0YYYYh Address ZZZZZh 08000h 04000h 04000h 04000h 04000h 13FFFh 1BFFFh 23FFFh Size 2 Kbytes 2.5 Kbytes 3 Kbytes 5 Kbytes 6 Kbytes R5F21206JFP, R5F21206KFP 32 Kbytes R5F21207JFP, R5F21207KFP 48 Kbytes R5F21208JFP, R5F21208KFP 64 Kbytes R5F2120AJFP, R5F2120AKFP 96 Kbytes R5F2120CJFP, R5F2120CKFP 128 Kbytes Internal RAM Address 0XXXXh Address 0SSSSh 00BFFh 00DFFh 00FFFh 00FFFh 00FFFh 037FFh 03BFFh Figure 3.1 Memory Map of R8C/20 Group Rev.2.00 Aug 27, 2008 REJ03B0120-0200 Page 13 of 41 R8C/20 Group, R8C/21 Group 3. Memory 3.2 R8C/21 Group Figure 3.2 shows a Memory Map of R8C/21 Group. The R8C/21 Group has 1 Mbyte of address space from address 00000h to FFFFFh. The internal ROM (program ROM) is allocated lower addresses, beginning with address 0FFFFh. For example, a 48-Kbyte internal ROM is allocated addresses 04000h to 0FFFFh. The fixed interrupt vector table is allocated addresses 0FFDCh to 0FFFFh. They store the starting address of each interrupt routine. The internal ROM (data flash) is allocated addresses 02400h to 02BFFh. The internal RAM is allocated higher addresses, beginning with address 00400h. For example, a 2.5-Kbyte internal RAM is allocated addresses 00400h to 00DFFh. The internal RAM is used not only for storing data but also for calling subroutines and as stacks when interrupt requests are acknowledged. Special function registers (SFR) are allocated addresses 00000h to 002FFh. The peripheral function control registers are allocated them. All addresses within the SFR, which have nothing allocated are reserved for future use and cannot be accessed by users. 00000h SFR (Refer to 4. Special Function Registers (SFRs)) 002FFh 00400h Internal RAM 0XXXXh 01300h 02000h 02400h Reserved area 0FFDCh Internal ROM (data flash)(1) 02BFFh 03000h 0SSSSh 0YYYYh Internal RAM Internal ROM (program ROM) Undefined instruction Overflow BRK instruction Address match Single step Watchdog timer•oscillation stop detection•voltage detection 0FFFFh ZZZZZh FFFFFh Internal ROM(3) (program ROM) 0FFFFh Address break (Reserved) Reset NOTES: 1. Data flash block A (1 Kbyte) and B (1 Kbyte) are shown. 2. The blank regions are reserved. Do not access locations in these regions. 3. Do not use addresses 20000h to 23FFFh because these areas are used for the emulator debugger. Refer to 23. Notes on Emulator Debugger of Hardware Manual. Internal ROM Size Address 0YYYYh Address ZZZZZh R5F21216JFP, R5F21216KFP 32 Kbytes 08000h R5F21217JFP, R5F21217KFP 48 Kbytes R5F21218JFP, R5F21218KFP 64 Kbytes R5F2121AJFP, R5F2121AKFP 96 Kbytes R5F2121CJFP, R5F2121CKFP 128 Kbytes 04000h 04000h 04000h 04000h 13FFFh 1BFFFh 23FFFh Part Number Internal RAM Address 0XXXXh Address 0SSSSh Size 2 Kbytes 00BFFh 2.5 Kbytes 3 Kbytes 5 Kbytes 6 Kbytes 00DFFh 00FFFh 00FFFh 00FFFh 037FFh 03BFFh Figure 3.2 Memory Map of R8C/21 Group Rev.2.00 Aug 27, 2008 REJ03B0120-0200 Page 14 of 41 R8C/20 Group, R8C/21 Group 4. Special Function Registers (SFRs) 4. Special Function Registers (SFRs) An SFR (special function register) is a control register for a peripheral function. Table 4.1 to Table 4.6 list the SFR Information. Table 4.1 Address 0000h 0001h 0002h 0003h 0004h 0005h 0006h 0007h 0008h 0009h 000Ah 000Bh 000Ch 000Dh 000Eh 000Fh 0010h 0011h 0012h 0013h 0014h 0015h 0016h 0017h 0018h 0019h 001Ah 001Bh 001Ch 001Dh 001Eh 001Fh 0020h 0021h 0022h 0023h 0024h 0025h 0026h 0030h 0031h 0032h 0033h 0034h 0035h 0036h 0037h 0038h 0039h 003Fh SFR Information (1)(1) Register Symbol After reset Processor Mode Register 0 Processor Mode Register 1 System Clock Control Register 0 System Clock Control Register 1 PM0 PM1 CM0 CM1 00h 00h 01101000b 00100000b Protect Register Oscillation Stop Detection Register Watchdog Timer Reset Register Watchdog Timer Start Register Watchdog Timer Control Register Address Match Interrupt Register 0 PRCR OCD WDTR WDTS WDC RMAD0 00h 00000100b XXh XXh 00X11111b 00h 00h 00h 00h 00h 00h 00h Address Match Interrupt Enable Register Address Match Interrupt Register 1 AIER RMAD1 Count Source Protect Mode Register CSPR 00h 10000000b(8) High-Speed On-Chip Oscillator Control Register 0 High-Speed On-Chip Oscillator Control Register 1 High-Speed On-Chip Oscillator Control Register 2 FRA0 FRA1 FRA2 00h When shipping 00h Voltage Detection Register 1(2) Voltage Detection Register 2(6) VCA1 VCA2 00001000b 00h(3) 01000000b(4) Voltage Monitor 1 Circuit Control Register(7) Voltage Monitor 2 Circuit Control Register(5) VW1C VW2C 0000X000b(3) 0100X001b(4) 00h X: Undefined NOTES: 1. The blank regions are reserved. Do not access locations in these regions. 2. Software reset, watchdog timer reset, and voltage monitor 2 reset do not affect this register. 3. The LVD0ON bit in the OFS register is set to 1. 4. Power-on reset, voltage monitor 1 reset or the LVD0ON bit in the OFS register is set to 0. 5. Software reset, watchdog timer reset, and voltage monitor 2 reset do not affect b2 and b3. 6. Software reset, watchdog timer reset, and voltage monitor 2 reset do not affect b7. 7. Software reset, the watchdog timer rest, and the voltage monitor 2 reset do not affect other than the b0 and b6. 8. The CSPROINI bit in the OFS register is 0. Rev.2.00 Aug 27, 2008 REJ03B0120-0200 Page 15 of 41 R8C/20 Group, R8C/21 Group Table 4.2 Address 0040h 0041h 0042h 0043h 0044h 0045h 0046h 0047h 0048h 0049h 004Ah 004Bh 004Ch 004Dh 004Eh 004Fh 0050h 0051h 0052h 0053h 0054h 0055h 0056h 0057h 0058h 0059h 005Ah 005Bh 005Ch 005Dh 005Eh 005Fh 0060h 0061h 0062h 0063h 0064h 0065h 0066h 0067h 0068h 0069h 006Ah 006Bh 006Ch 006Dh 006Eh 006Fh 0070h 0071h 0072h 0073h 0074h 0075h 0076h 0077h 0078h 0079h 007Ah 007Bh 007Ch 007Dh 007Eh 007Fh 4. Special Function Registers (SFRs) SFR Information (2)(1) Register Symbol After reset Timer RD0 Interrupt Control Register Timer RD1 Interrupt Control Register Timer RE Interrupt Control Register TRD0IC TRD1IC TREIC XXXXX000b XXXXX000b XXXXX000b Key Input Interrupt Control Register A/D Conversion Interrupt Control Register SSU Interrupt Control Register/IIC Bus Interrupt Control Register(2) UART0 Transmit Interrupt Control Register UART0 Receive Interrupt Control Register UART1 Transmit Interrupt Control Register UART1 Receive Interrupt Control Register INT2 Interrupt Control Register Timer RA Interrupt Control Register Timer RB Interrupt Control Register INT1 Interrupt Control Register INT3 Interrupt Control Register KUPIC ADIC SSUIC/IICIC S0TIC S0RIC S1TIC S1RIC INT2IC TRAIC TRBIC INT1IC INT3IC XXXXX000b XXXXX000b XXXXX000b XXXXX000b XXXXX000b XXXXX000b XXXXX000b XX00X000b XXXXX000b XXXXX000b XX00X000b XX00X000b INT0 Interrupt Control Register INT0IC XX00X000b X: Undefined NOTES: 1. The blank regions are reserved. Do not access locations in these regions. 2. Selected by the IICSEL bit in the PMR register. Rev.2.00 Aug 27, 2008 REJ03B0120-0200 Page 16 of 41 R8C/20 Group, R8C/21 Group Table 4.3 Address 0080h 0081h 0082h 0083h 0084h 0085h 0086h 0087h 0088h 0089h 008Ah 008Bh 008Ch 008Dh 008Eh 008Fh 0090h 0091h 0092h 0093h 0094h 0095h 0096h 0097h 0098h 0099h 009Ah 009Bh 009Ch 009Dh 009Eh 009Fh 00A0h 00A1h 00A2h 00A3h 00A4h 00A5h 00A6h 00A7h 00A8h 00A9h 00AAh 00ABh 00ACh 00ADh 00AEh 00AFh 00B0h 00B1h 00B2h 00B3h 00B4h 00B5h 00B6h 00B7h 00B8h 00B9h 00BAh 00BBh 00BCh 00BDh 00BEh 00BFh 4. Special Function Registers (SFRs) SFR Information (3)(1) Register Symbol After reset UART0 Transmit/Receive Mode Register UART0 Bit Rate Register UART0 Transmit Buffer Register UART0 Transmit/Receive Control Register 0 UART0 Transmit/Receive Control Register 1 UART0 Receive Buffer Register UART1 Transmit/Receive Mode Register UART1 Bit Rate Register UART1 Transmit Buffer Register UART1 Transmit/Receive Control Register 0 UART1 Transmit/Receive Control Register 1 UART1 Receive Buffer Register U0MR U0BRG U0TB U0C0 U0C1 U0RB U1MR U1BRG U1TB U1C0 U1C1 U1RB 00h XXh XXh XXh 00001000b 00000010b XXh XXh 00h XXh XXh XXh 00001000b 00000010b XXh XXh SS Control Register H/IIC Bus Control Register 1(2) SS Control Register L/IIC Bus Control Register 2(2) SS Mode Register/IIC Bus Mode Register 1(2) SS Enable Register/IIC Bus Interrupt Enable Register(2) SS Status Register/IIC Bus Status Register(2) SS Mode Register 2/Slave Address Register(2) SS Transmit Data Register/IIC Bus Transmit Data Register(2) SS Receive Data Register/IIC Bus Receive Data Register(2) SSCRH/ICCR1 SSCRL/ICCR2 SSMR/ICMR SSER/ICIER SSSR/ICSR SSMR2/SAR SSTDR/ICDRT SSRDR/ICDRR 00h 01111101b 00011000b 00h 00h/0000X000b 00h FFh FFh X: Undefined NOTES: 1. The blank regions are reserved. Do not access locations in these regions. 2. Selected by the IICSEL bit in the PMR register. Rev.2.00 Aug 27, 2008 REJ03B0120-0200 Page 17 of 41 R8C/20 Group, R8C/21 Group Table 4.4 Address 00C0h 00C1h 00C2h 00C3h 00C4h 00C5h 00C6h 00C7h 00C8h 00C9h 00CAh 00CBh 00CCh 00CDh 00CEh 00CFh 00D0h 00D1h 00D2h 00D3h 00D4h 00D5h 00D6h 00D7h 00D8h 00D9h 00DAh 00DBh 00DCh 00DDh 00DEh 00DFh 00E0h 00E1h 00E2h 00E3h 00E4h 00E5h 00E6h 00E7h 00E8h 00E9h 00EAh 00EBh 00ECh 00EDh 00EEh 00EFh 00F0h 00F1h 00F2h 00F3h 00F4h 00F5h 00F6h 00F7h 00F8h 00F9h 00FAh 00FBh 00FCh 00FDh 00FEh 00FFh 4. Special Function Registers (SFRs) SFR Information (4)(1) Register A/D Register AD Symbol XXh XXh After reset A/D Control Register 2 A/D Control Register 0 A/D Control Register 1 ADCON2 ADCON0 ADCON1 00h 00h 00h Port P0 Register Port P1 Register Port P0 Direction Register Port P1 Direction Register Port P2 Register Port P3 Register Port P2 Direction Register Port P3 Direction Register Port P4 Register Port P4 Direction Register Port P6 Register Port P6 Direction Register P0 P1 PD0 PD1 P2 P3 PD2 PD3 P4 PD4 P6 PD6 XXh XXh 00h 00h XXh XXh 00h 00h XXh 00h XXh 00h UART1 Function Select Register U1SR XXh Port Mode Register External Input Enable Register INT Input Filter Select Register Key Input Enable Register Pull-Up Control Register 0 Pull-Up Control Register 1 PMR INTEN INTF KIEN PUR0 PUR1 00h 00h 00h 00h 00h XX00XX00b X: Undefined NOTE: 1. The blank regions are reserved. Do not access locations in these regions. Rev.2.00 Aug 27, 2008 REJ03B0120-0200 Page 18 of 41 R8C/20 Group, R8C/21 Group Table 4.5 Address 0100h 0101h 0102h 0103h 0104h 0105h 0106h 0107h 0108h 0109h 010Ah 010Bh 010Ch 010Dh 010Eh 010Fh 0110h 0111h 0112h 0113h 0114h 0115h 0116h 0117h 0118h 0119h 011Ah 011Bh 011Ch 011Dh 011Eh 011Fh 0120h 0121h 0122h 0123h 0124h 0125h 0126h 0127h 0128h 0129h 012Ah 012Bh 012Ch 012Dh 012Eh 012Fh 0130h 0131h 0132h 0133h 0134h 0135h 0136h 0137h 0138h 0139h 013Ah 013Bh 013Ch 013Dh 013Eh 013Fh 4. Special Function Registers (SFRs) SFR Information (5)(1) Register Timer RA Control Register Timer RA I/O Control Register Timer RA Mode Register Timer RA Prescaler Register Timer RA Register LIN Control Register LIN Status Register Timer RB Control Register Timer RB One-Shot Control Register Timer RB I/O Control Register Timer RB Mode Register Timer RB Prescaler Register Timer RB Secondary Register Timer RB Primary Symbol TRACR TRAIOC TRAMR TRAPRE TRA LINCR LINST TRBCR TRBOCR TRBIOC TRBMR TRBPRE TRBSC TRBPR After reset 00h 00h 00h FFh FFh 00h 00h 00h 00h 00h 00h FFh FFh FFh Timer RE Counter Data Register Timer RE Compare Data Register TRESEC TREMIN 00h 00h Timer RE Control Register 1 Timer RE Control Register 2 Timer RE Count Source Select Register TRECR1 TRECR2 TRECSR 00h 00h 00001000b Timer RD Start Register Timer RD Mode Register Timer RD PWM Mode Register Timer RD Function Control Register Timer RD Output Master Enable Register 1 Timer RD Output Master Enable Register 2 Timer RD Output Control Register Timer RD Digital Filter Function Select Register 0 Timer RD Digital Filter Function Select Register 1 TRDSTR TRDMR TRDPMR TRDFCR TRDOER1 TRDOER2 TRDOCR TRDDF0 TRDDF1 11111100b 00001110b 10001000b 10000000b FFh 01111111b 00h 00h 00h X: Undefined NOTE: 1. The blank regions are reserved. Do not access locations in these regions. Rev.2.00 Aug 27, 2008 REJ03B0120-0200 Page 19 of 41 R8C/20 Group, R8C/21 Group Table 4.6 Address 0140h 0141h 0142h 0143h 0144h 0145h 0146h 0147h 0148h 0149h 014Ah 014Bh 014Ch 014Dh 014Eh 014Fh 0150h 0151h 0152h 0153h 0154h 0155h 0156h 0157h 0158h 0159h 015Ah 015Bh 015Ch 015Dh 015Eh 015Fh 01B0h 01B1h 01B2h 01B3h 01B4h 01B5h 01B6h 01B7h 01B8h 01B9h 01BAh 01BBh 01BCh 01BDh 01BEh 01BFh FFFFh 4. Special Function Registers (SFRs) SFR Information (6)(1) Register Timer RD Control Register 0 Timer RD I/O Control Register A0 Timer RD I/O Control Register C0 Timer RD Status Register 0 Timer RD Interrupt Enable Register 0 Timer RD PWM Mode Output Level Control Register 0 Timer RD Counter 0 Timer RD General Register A0 Timer RD General Register B0 Timer RD General Register C0 Timer RD General Register D0 Timer RD Control Register 1 Timer RD I/O Control Register A1 Timer RD I/O Control Register C1 Timer RD Status Register 1 Timer RD Interrupt Enable Register 1 Timer RD PWM Mode Output Level Control Register 1 Timer RD Counter 1 Timer RD General Register A1 Timer RD General Register B1 Timer RD General Register C1 Timer RD General Register D1 Symbol TRDCR0 TRDIORA0 TRDIORC0 TRDSR0 TRDIER0 TRDPOCR0 TRD0 TRDGRA0 TRDGRB0 TRDGRC0 TRDGRD0 TRDCR1 TRDIORA1 TRDIORC1 TRDSR1 TRDIER1 TRDPOCR1 TRD1 TRDGRA1 TRDGRB1 TRDGRC1 TRDGRD1 After reset 00h 10001000b 10001000b 11100000b 11100000b 11111000b 00h 00h FFh FFh FFh FFh FFh FFh FFh FFh 00h 10001000b 10001000b 11000000b 11100000b 11111000b 00h 00h FFh FFh FFh FFh FFh FFh FFh FFh Flash Memory Control Register 4 Flash Memory Control Register 1 Flash Memory Control Register 0 FMR4 FMR1 FMR0 01000000b 1000000Xb 00000001b Option Function Select Register OFS (Note 2) X: Undefined NOTES: 1. The blank regions are reserved. Do not access locations in these regions. 2. The OFS register cannot be changed by a program. Use a flash programmer to write to it. Rev.2.00 Aug 27, 2008 REJ03B0120-0200 Page 20 of 41 R8C/20 Group, R8C/21 Group 5. Electrical Characteristics 5. Electrical Characteristics Table 5.1 Symbol VCC/AVCC VI VO Pd Topr Tstg Supply voltage Input voltage Output voltage Power dissipation Operating ambient temperature Storage temperature -40°C ≤ Topr ≤ 85°C 85°C < Topr ≤ 125°C Absolute Maximum Ratings Parameter Condition Rated value -0.3 to 6.5 -0.3 to VCC+0.3 -0.3 to VCC+0.3 300 125 -40 to 85 (J version) / -40 to 125 (K version) -65 to 150 Unit V V V mW mW °C °C Table 5.2 Symbol VCC/AVCC VSS/AVCC VIH VIL IOH(sum) IOH(peak) IOH(avg) IOL(sum) IOL(peak) IOL(avg) f(XIN) Recommended Operating Conditions Parameter Supply voltage Supply voltage Input “H” voltage Input “L” voltage Peak sum output “H” current Peak output “H” current Average output “H” current Peak sum output “L” currents Peak output “L” currents Average output “L” current XIN clock input oscillation frequency 3.0 V ≤ VCC ≤ 5.5 V -40°C ≤ Topr ≤ 85°C 3.0 V ≤ VCC ≤ 5.5 V -40°C ≤ Topr ≤ 125°C 2.7 V ≤ VCC < 3.0 V Sum of all Pins IOL (peak) Sum of all Pins IOH (peak) Conditions Standard Min. 2.7 − 0.8VCC 0 − − − − − − 0 0 0 0 0 0 − Typ. − 0 − − − − − − − − − − − − − − 125 Max. 5.5 − VCC 0.2VCC -60 -10 -5 60 10 5 20 16 10 20 16 10 − Unit V V V V mA mA mA mA mA mA MHz MHz MHz MHz MHz MHz kHz − System clock OCD2 = 0 When XIN clock is selected. OCD2 = 1 When on-chip oscillator clock is selected. 3.0 V ≤ VCC ≤ 5.5 V -40°C ≤ Topr ≤ 85°C 3.0 V ≤ VCC ≤ 5.5 V -40°C ≤ Topr ≤ 125°C 2.7 V ≤ VCC < 3.0 V FRA01 = 0 When low-speed onchip oscillator clock is selected. FRA01 = 1 When high-speed onchip oscillator clock is selected. 3.0 V ≤ VCC ≤ 5.5 V -40°C ≤ Topr ≤ 85°C FRA01 = 1 When high-speed onchip oscillator clock is selected. − − 20 MHz − − 10 MHz NOTES: 1. VCC = 2.7 to 5.5 V at Topr = -40 to 85°C (J version) / -40 to 125°C (K version), unless otherwise specified. 2. The average output current indicates the average value of current measured during 100 ms. Rev.2.00 Aug 27, 2008 REJ03B0120-0200 Page 21 of 41 R8C/20 Group, R8C/21 Group 5. Electrical Characteristics Table 5.3 Symbol − − A/D Converter Characteristics Parameter Resolution Absolute Accuracy 10-bit mode 8-bit mode 10-bit mode 8-bit mode Vref = AVCC φAD = 10 MHz, Vref = AVCC = 5.0 V φAD = 10 MHz, Vref = AVCC = 5.0 V φAD = 10 MHz, Vref = AVCC = 3.3 V φAD = 10 MHz, Vref = AVCC = 3.3 V Vref = AVCC 10-bit mode 8-bit mode φAD = 10 MHz, Vref = AVCC = 5.0 V φAD = 10 MHz, Vref = AVCC = 5.0 V Conditions Standard Min. − − − − − 10 3.3 2.8 2.7 0 0.25 1 Without sample & hold With sample & hold Typ. − − − − − − − − − − − − Max. 10 ±3 ±2 ±5 ±2 40 − − AVCC AVCC 10 10 Unit Bits LSB LSB LSB LSB kΩ µs µs V V MHz MHz Rladder tconv Vref VIA − Resistor ladder Conversion time Reference voltage Analog input voltage(2) A/D operating clock frequency NOTES: 1. VCC = AVCC = 2.7 to 5.5 V at Topr = -40 to 85°C (J version) / -40 to 125°C (K version), unless otherwise specified. 2. When analog input voltage exceeds reference voltage, A/D conversion result is 3FFh in 10-bit mode, FFh in 8-bit mode. P0 P1 P2 P3 P4 P6 30pF Figure 5.1 Ports P0 to P4, P6 Timing Measurement Circuit Rev.2.00 Aug 27, 2008 REJ03B0120-0200 Page 22 of 41 R8C/20 Group, R8C/21 Group 5. Electrical Characteristics Table 5.4 Symbol − − − Flash Memory (Program ROM) Electrical Characteristics Parameter Program/erase endurance(2) Byte program time Block erase time Conditions R8C/20 Group R8C/21 Group Standard Min. 100(3) 1,000(3) − − − 650 0 − 2.7 2.7 0 Ambient temperature = 55°C 20 Typ. − − 50 0.4 − − − − − − − − Max. − − 400 9 97 + CPU clock × 6 cycle − − 3 + CPU clock × 4 cycle 5.5 5.5 60 − Unit times times µs s µs µs ns µs V V °C year td(SR-SUS) Time delay from suspend request until erase suspend − − − − − − − Interval from erase start/restart until following suspend request Interval from program start/restart until following suspend request Time from suspend until program/erase restart Program, erase voltage Read voltage Program, erase temperature Data hold time(7) NOTES: 1. VCC = 2.7 to 5.5 V at Topr = -40 to 85°C (J version) / -40 to 125°C (K version), unless otherwise specified. 2. Definition of programming/erasure endurance The programming and erasure endurance is defined on a per-block basis. If the programming and erasure endurance is n (n = 100 or 1,000), each block can be erased n times. For example, if 1,024 1-byte writes are performed to different addresses in block A, a 1 Kbyte block, and then the block is erased, the programming/erasure endurance still stands at one. However, the same address must not be programmed more than once per erase operation (overwriting prohibited). 3. Endurance to guarantee all electrical characteristics after program and erase (1 to Min. value can be guaranteed). 4. In a system that executes multiple programming operations, the actual erasure endurance can be reduced by writing to sequential addresses in turn so that as much of the block as possible is used up before performing an erase operation. For example, when programming groups of 16 bytes, the effective number of rewrites can be minimized by programming up to 128 groups before erasing them all in one operation. It is also advisable to retain data on the erasure endurance of each block and limit the number of erase operations to a certain number. 5. If error occurs during block erase, attempt to execute the clear status register command, then the block erase command at least three times until the erase error does not occur. 6. Customers desiring program/erase failure rate information should contact their Renesas technical support representative. 7. The data hold time includes time that the power supply is off or the clock is not supplied. Rev.2.00 Aug 27, 2008 REJ03B0120-0200 Page 23 of 41 R8C/20 Group, R8C/21 Group 5. Electrical Characteristics Table 5.5 Symbol − − − − − Flash Memory (Data Flash Block A, Block B) Electrical Characteristics(4) Parameter Program/erase endurance(2) Byte program time (Program/erase endurance ≤ 1,000 times) Byte program time (Program/erase endurance > 1,000 times) Block erase time (Program/erase endurance ≤ 1,000 times) Block erase time (Program/erase endurance > 1,000 times) Conditions Standard Min. 10,000(3) − − − − − 650 0 − 2.7 2.7 -40 Ambient temperature = 55°C 20 Typ. − 50 65 0.2 0.3 − − − − − − − − Max. − 400 − 9 − 97 + CPU clock × 6 cycle − − 3 + CPU clock × 4 cycle 5.5 5.5 85(8) − Unit times µs µs s s µs µs ns µs V V °C year td(SR-SUS) Time delay from suspend request until erase suspend − − − − − − − Interval from erase start/restart until following suspend request Interval from program start/restart until following suspend request Time from suspend until program/erase restart Program, erase voltage Read voltage Program, erase temperature Data hold time(9) NOTES: 1. VCC = 2.7 to 5.5 V at Topr = -40 to 85°C (J version) / -40 to 125°C (K version), unless otherwise specified. 2. Definition of programming/erasure endurance The programming and erasure endurance is defined on a per-block basis. If the programming and erasure endurance is n (n = 10,000), each block can be erased n times. For example, if 1,024 1-byte writes are performed to different addresses in block A, a 1 Kbyte block, and then the block is erased, the programming/erasure endurance still stands at one. However, the same address must not be programmed more than once per erase operation (overwriting prohibited). 3. MInimum endurance to guarantee all electrical characteristics after program and erase (1 to Min. value can be guaranteed). 4. Standard of block A and block B when program and erase endurance exceeds 1,000 times. Byte program time to 1,000 times are the same as that in program ROM. 5. In a system that executes multiple programming operations, the actual erasure endurance can be reduced by writing to sequential addresses in turn so that as much of the block as possible is used up before performing an erase operation. For example, when programming groups of 16 bytes, the effective number of rewrites can be minimized by programming up to 128 groups before erasing them all in one operation. In addition, averaging the erasure endurance between blocks A and B can further reduce the actual erasure endurance. It is also advisable to retain data on the erasure endurance of each block and limit the number of erase operations to a certain number. 6. If error occurs during block erase, attempt to execute the clear status register command, then the block erase command at least three times until the erase error does not occur. 7. Customers desiring program/erase failure rate information should contact their Renesas technical support representative. 8. 125°C for K version. 9. The data hold time includes time that the power supply is off or the clock is not supplied. Rev.2.00 Aug 27, 2008 REJ03B0120-0200 Page 24 of 41 R8C/20 Group, R8C/21 Group 5. Electrical Characteristics Suspend request (Maskable interrupt request) FMR46 Fixed time Clock-dependent time td(SR-SUS) Access restart Figure 5.2 Time delay until Suspend Table 5.6 Symbol Vdet1 td(Vdet1-A) − td(E-A) Vccmin Voltage Detection 1 Circuit Electrical Characteristics Parameter Voltage detection level(3, 4) Voltage monitor 1 reset generation time(5) VCA26 = 1, VCC = 5.0 V Voltage detection circuit self power consumption Waiting time until voltage detection circuit operation starts(2) MCU operating voltage minimum value Condition Standard Min. 2.70 − − − 2.70 Typ. 2.85 40 0.6 − − Max. 3.00 200 − 100 − Unit V µs µA µs V NOTES: 1. The measurement condition is VCC = 2.7 V to 5.5 V and Topr = -40°C to 85°C (J version) / -40°C to 125°C (K version). 2. Necessary time until the voltage detection circuit operates when setting to 1 again after setting the VCA26 bit in the VCA2 register to 0. 3. Hold Vdet2 > Vdet1. 4. This parameter shows the voltage detection level when the power supply drops. The voltage detection level when the power supply rises is higher than the voltage detection level when the power supply drops by approximately 0.1 V. 5. Time until the voltage monitor 1 reset is generated after the voltage passes Vdet1 when VCC falls. When using the digital filter, its sampling time is added to td(Vdet1-A). When using the voltage monitor 1 reset, maintain this time until VCC = 2.0 V after the voltage passes Vdet1 when the power supply falls. Table 5.7 Symbol Vdet2 td(Vdet2-A) − td(E-A) Voltage Detection 2 Circuit Electrical Characteristics Parameter Voltage detection level(4) Voltage monitor 2 reset/interrupt request generation time(2, 5) Voltage detection circuit self power consumption Waiting time until voltage detection circuit operation starts(3) VCA27 = 1, VCC = 5.0V Condition Standard Min. 3.3 − − − Typ. 3.6 40 0.6 − Max. 3.9 200 − 100 Unit V µs µA µs NOTES: 1. The measurement condition is VCC = 2.7 V to 5.5 V and Topr = -40°C to 85°C (J version) / -40°C to 125°C (K version). 2. Time until the voltage monitor 2 reset/interrupt request is generated since the voltage passes Vdet2. 3. Necessary time until the voltage detection circuit operates when setting to 1 again after setting the VCA27 bit in the VCA2 register to 0. 4. Hold Vdet2 > Vdet1. 5. When using the digital filter, its sampling time is added to td(Vdet2-A). When using the voltage monitor 2 reset, maintain this time until VCC = 2.0 V after the voltage passes Vdet2 when the power supply falls. Rev.2.00 Aug 27, 2008 REJ03B0120-0200 Page 25 of 41 R8C/20 Group, R8C/21 Group 5. Electrical Characteristics Table 5.8 Symbol Vpor1 Vpor2 trth Power-on Reset Circuit, Voltage Monitor 1 Reset Circuit Electrical Characteristics(3) Parameter Power-on reset valid voltage(4) Power-on reset or voltage monitor 1 valid voltage External power VCC rise gradient VCC ≤ 3.6 V VCC > 3.6 V Condition Min. − 0 20(2) 20(2) Standard Typ. − − − − Max. 0.1 Vdet1 − 2,000 V V mV/msec mV/msec Unit NOTES: 1. Topr = -40°C to 85°C (J version) / -40°C to 125°C (K version), unless otherwise specified. 2. This condition (the minimum value of external power VCC rise gradient) does not apply if Vpor2 ≥ 1.0 V. 3. To use the power-on reset function, enable voltage monitor 1 reset by setting the LVD1ON bit in the OFS register to 0, the VW1C0 and VW1C6 bits in the VW1C register to 1 respectively, and the VCA26 bit in the VCA2 register to 1. 4. tw(por1) indicates the duration the external power VCC must be held below the effective voltage (Vpor1) to enable a power on reset. When turning on the power for the first time, maintain tw(por1) for 30s or more if -20°C ≤ Topr ≤ 125°C, maintain tw(por1) for 3,000s or more if -40°C ≤ Topr < -20°C. Vdet1(3) External power Vcc Vpor1 tw(por1) Sampling time(1, 2) Vdet1(3) trth td(Vdet1-A) Vpor2 2.0 V trth Internal reset signal (“L” valid) 1 × 32 fOCO-S 1 × 32 fOCO-S NOTES: 1. When using the voltage monitor 1 digital filter, ensure VCC is 2.0 V or higher during the sampling time. 2. The sampling clock can be selected. Refer to 6. Voltage Detection Circuit of Hardware Manual for details. 3. Vdet1 indicates the voltage detection level of the voltage detection 1 circuit. Refer to 6. Voltage Detection Circuit of Hardware Manual for details. Figure 5.3 Power-on Reset Circuit Electrical Characteristics Rev.2.00 Aug 27, 2008 REJ03B0120-0200 Page 26 of 41 R8C/20 Group, R8C/21 Group 5. Electrical Characteristics Table 5.9 Symbol fOCO40M High-Speed On-Chip Oscillator Circuit Electrical Characteristics Parameter High-speed on-chip oscillator frequency temperature • supply voltage dependence Condition VCC = 4.75 V to 5.25 V, 0°C ≤ Topr ≤ 60°C(2) VCC = 3.0 V to 5.25 V, -20°C ≤ Topr ≤ 85°C(2) VCC = 3.0 V to 5.5 V, -40°C ≤ Topr ≤ 85°C(2) VCC = 3.0 V to 5.5 V, -40°C ≤ Topr ≤ 125°C(2) VCC = 2.7 V to 5.5 V, -40°C ≤ Topr ≤ 125°C(2) Standard Min. 39.2 38.8 38.4 38.0 37.6 08h Adjust the FRA1 register to -1 bit (the value when the reset is deasserted) VCC = 5.0 V, Topr = 25°C − Typ. 40 40 40 40 40 40 + 0.3 Max. 40.8 41.2 41.6 42.0 42.4 F7h − Unit MHz MHz MHz MHz MHz − MHz − − The value of the FRA1 register when the reset is deasserted High-speed on-chip oscillator adjustment range − − Oscillation stability time Self power consumption when high-speed on-chip oscillator oscillating − − 10 600 100 − µs µA NOTES: 1. VCC = 2.7 V to 5.5 V, Topr = -40°C to 85°C (J version) / -40°C to 125°C (K version), unless otherwise specified. 2. The standard value shows when the reset is deasserted for the FRA1 register. Table 5.10 Symbol fOCO-S − − Low-Speed On-Chip Oscillator Circuit Electrical Characteristics Parameter Low-speed on-chip oscillator frequency Oscillation stability time Self power consumption when low-speed on-chip oscillator oscillating VCC = 5.0 V, Topr = 25°C Condition Standard Min. 40 − − Typ. 125 10 15 Max. 250 100 − Unit kHz µs µA NOTE: 1. VCC = 2.7 V to 5.5 V, Topr = -40°C to 85°C (J version) / -40°C to 125°C (K version), unless otherwise specified. Table 5.11 Symbol td(P-R) td(R-S) Power Supply Circuit Timing Characteristics Parameter Time for internal power supply stabilization during power-on(2) STOP exit time(3) Condition Standard Min. 1 − Typ. − − Max. 2000 150 Unit µs µs NOTES: 1. The measurement condition is VCC = 2.7 to 5.5 V and Topr = -40°C to 85°C (J version) / -40°C to 125°C (K version), unless otherwise specified. 2. Waiting time until the internal power supply generation circuit stabilizes during power-on. 3. Time until CPU clock supply starts since the interrupt is acknowledged to exit stop mode. Rev.2.00 Aug 27, 2008 REJ03B0120-0200 Page 27 of 41 R8C/20 Group, R8C/21 Group 5. Electrical Characteristics Table 5.12 Symbol tSUCYC tHI tLO tRISE tFALL tSU tH tLEAD tLAG tOD tSA tOR Timing Requirements of Clock Synchronous Serial I/O with Chip Select(1) Parameter SSCK clock cycle time SSCK clock “H” width SSCK clock “L” width SSCK clock rising time SSCK clock falling time SSO, SSI data input setup time SSO, SSI data input hold time SCS setup time SCS hold time SSO, SSI data output delay time SSI slave access time SSI slave out open time Slave Slave Master Slave Master Slave Conditions Standard Min. 4 0.4 0.4 − − − − 100 1 1tCYC + 50 1tCYC + 50 − − − Typ. − − − − − − − − − − − − − − Max. − 0.6 0.6 1 1 1 1 − − − − 1 1tCYC + 100 1tCYC + 100 Unit tCYC(2) tSUCYC tSUCYC tCYC(2) µs tCYC(2) µs ns tCYC(2) ns ns tCYC(2) ns ns NOTES: 1. VCC = 2.7 to 5.5 V, VSS = 0 V at Topr = -40 to 85°C (J version) / -40 to 125°C (K version), unless otherwise specified. 2. 1tCYC = 1/f1(s) Rev.2.00 Aug 27, 2008 REJ03B0120-0200 Page 28 of 41 R8C/20 Group, R8C/21 Group 5. Electrical Characteristics 4-wire bus communication mode, Master, CPHS = 1 VIH or VOH SCS (output) VIH or VOH tHI tFALL tRISE SSCK (output) (CPOS = 1) tLO tHI SSCK (output) (CPOS = 0) tLO tSUCYC SSO (output) tOD SSI (input) tSU tH 4-wire bus communication mode, Master, CPHS = 0 VIH or VOH SCS (output) VIH or VOH tHI tFALL tRISE SSCK (output) (CPOS = 1) tLO tHI SSCK (output) (CPOS = 0) tLO tSUCYC SSO (output) tOD SSI (input) tSU tH CPHS, CPOS: Bits in SSMR register Figure 5.4 I/O Timing of Clock Synchronous Serial I/O with Chip Select (Master) Rev.2.00 Aug 27, 2008 REJ03B0120-0200 Page 29 of 41 R8C/20 Group, R8C/21 Group 5. Electrical Characteristics 4-wire bus communication mode, Slave, CPHS = 1 VIH or VOH SCS (input) VIH or VOH tLEAD tHI tFALL tRISE tLAG SSCK (input) (CPOS = 1) tLO tHI SSCK (input) (CPOS = 0) tLO tSUCYC SSO (input) tSU tH SSI (output) tSA tOD tOR 4-wire bus communication mode, Slave, CPHS = 0 SCS (input) VIH or VOH VIH or VOH tLEAD tHI tFALL tRISE tLAG SSCK (input) (CPOS = 1) tLO tHI SSCK (input) (CPOS = 0) tLO tSUCYC SSO (input) tSU tH SSI (output) tSA tOD tOR CPHS, CPOS: Bits in SSMR register Figure 5.5 I/O Timing of Clock Synchronous Serial I/O with Chip Select (Slave) Rev.2.00 Aug 27, 2008 REJ03B0120-0200 Page 30 of 41 R8C/20 Group, R8C/21 Group 5. Electrical Characteristics tHI VIH or VOH SSCK VIH or VOH tLO tSUCYC SSO (output) tOD SSI (input) tSU tH Figure 5.6 I/O Timing of Clock Synchronous Serial I/O with Chip Select (Clock Synchronous Communication Mode) Rev.2.00 Aug 27, 2008 REJ03B0120-0200 Page 31 of 41 R8C/20 Group, R8C/21 Group 5. Electrical Characteristics Table 5.13 Symbol tSCL tSCLH tSCLL tsf tSP tBUF tSTAH tSTAS tSTOP tSOAS tSDAH Timing Requirements of I2C Bus Interface(1) Parameter SCL input cycle time SCL input “H” width SCL input “L” width SCL, SDA input falling time SCL, SDA input spike pulse rejection time SDA input bus-free time Start condition input hole time Retransmit start condition input setup time Stop condition input setup time Data input setup time Data input hold time Conditions Min. 12tCYC + 600(2) 3tCYC + 300(2) 5tCYC + 300(2) − − 5tCYC(2) 3tCYC(2) 3tCYC(2) 3tCYC(2) 1tCYC + 20(2) 0 Standard Typ. − − − − − − − − − − − Max. − − − Unit ns ns ns ns ns ns ns ns ns ns ns 300 1tCYC(2) − − − − − − NOTES: 1. VCC = 2.7 to 5.5 V, VSS = 0V at Topr = -40 to 85°C (J version) / -40 to 125°C (K version), unless otherwise specified. 2. 1tCYC = 1/f1(s) VIH SDA tBUF VIL tSTAH tSCLH tSTAS tSP tSTOP SCL P(2) S(1) tSf tSCLL tSCL Sr(3) tSr tSDAH tSDAS P(2) NOTES: 1. Start condition 2. Stop condition 3. Retransmit “Start” condition Figure 5.7 I/O Timing of I2C Bus Interface Rev.2.00 Aug 27, 2008 REJ03B0120-0200 Page 32 of 41 R8C/20 Group, R8C/21 Group 5. Electrical Characteristics Table 5.14 Symbol VOH Electrical Characteristics (1) [VCC = 5 V] Parameter Condition IOH = -5 mA IOH = -200 µA Drive capacity HIGH Drive capacity LOW IOL = 5 mA IOL = 200 µA Drive capacity HIGH Drive capacity LOW Standard Min. Typ. VCC − 2.0 − VCC − 0.3 − VCC − 2.0 − VCC − 2.0 − − − − − − − Output “H” Voltage Except XOUT XOUT IOH = -1 mA IOH = -500 µA Max. VCC VCC VCC VCC 2.0 0.45 2.0 2.0 − Unit V V V V V V V V V VOL Output “L” Voltage Except XOUT XOUT IOL = 1 mA IOL = 500 µA − − VT+-VT- Hysteresis INT0, INT1, INT2, INT3, KI0, KI1, KI2, KI3, TRAIO, RXD0, RXD1, CLK0, SSI, SCL, SDA, SSO RESET VI = 5 V, VCC = 5 V VI = 0 V, VCC = 5 V VI = 0 V, VCC = 5 V XIN During stop mode 0.1 0.5 0.1 − − 1.0 − − − V µA µA kΩ MΩ IIH IIL RPULLUP RfXIN VRAM Input “H” current Input “L” current Pull-Up Resistance Feedback Resistance RAM Hold Voltage 30 − 2.0 50 1.0 − 5.0 -5.0 167 − − V NOTE: 1. VCC = 4.2 to 5.5 V at Topr = -40 to 85°C (J version) / -40 to 125°C (K version), f(XIN) = 20 MHz, unless otherwise specified. Rev.2.00 Aug 27, 2008 REJ03B0120-0200 Page 33 of 41 R8C/20 Group, R8C/21 Group 5. Electrical Characteristics Table 5.15 Electrical Characteristics (2) [VCC = 5 V] (Topr = -40 to 85°C (J version) / -40 to 125°C (K version), Unless Otherwise Specified.) Parameter Condition XIN = 20 MHz (square wave) High-speed on-chip oscillator off Low-speed on-chip oscillator on = 125 kHz No division XIN = 16 MHz (square wave) High-speed on-chip oscillator off Low-speed on-chip oscillator on = 125 kHz No division XIN = 10 MHz (square wave) High-speed on-chip oscillator off Low-speed on-chip oscillator on = 125 kHz No division XIN = 20 MHz (square wave) High-speed on-chip oscillator off Low-speed on-chip oscillator on = 125 kHz Divide-by-8 XIN = 16MHz (square wave) High-speed on-chip oscillator off Low-speed on-chip oscillator on = 125 kHz Divide-by-8 XIN = 10 MHz (square wave) High-speed on-chip oscillator off Low-speed on-chip oscillator on = 125 kHz Divide-by-8 High-speed XIN clock off on-chip High-speed on-chip oscillator on fOCO = 10 MHz oscillator Low-speed on-chip oscillator on = 125 kHz mode No division XIN clock off High-speed on-chip oscillator on fOCO= 10 MHz Low-speed on-chip oscillator on = 125 kHz Divide-by-8 Low-speed XIN clock off on-chip High-speed on-chip oscillator off oscillator Low-speed on-chip oscillator on = 125 kHz mode Divide-by-8 FMR47 = 1 Wait mode XIN clock off High-speed on-chip oscillator off Low-speed on-chip oscillator on = 125 kHz While a WAIT instruction is executed Peripheral clock operation VCA20 = 0 VCA26 = VCA27 = 0 XIN clock off High-speed on-chip oscillator off Low-speed on-chip oscillator on = 125 kHz While a WAIT instruction is executed Peripheral clock off VCA20 = 0 VCA26 = VCA27 = 0 Stop mode XIN clock off Topr = 25°C High-speed on-chip oscillator off Low-speed on-chip oscillator off CM10 = 1 Peripheral clock off VCA26 = VCA27 = 0 Stop mode XIN clock off Topr = 85°C High-speed on-chip oscillator off Low-speed on-chip oscillator off CM10 = 1 Peripheral clock off VCA26 = VCA27 = 0 Stop mode XIN clock off Topr = 125°C High-speed on-chip oscillator off Low-speed on-chip oscillator off CM10 = 1 Peripheral clock off VCA26 = VCA27 = 0 Min. − Standard Typ. Max. 11.0 22.0 Unit mA Symbol ICC Power supply current High-clock (VCC = 3.3 to 5.5 V) mode In single-chip mode, the output pins are open and other pins are VSS − 8.8 17.6 mA − 5.8 − mA − 5.0 − mA − 3.8 − mA − 2.8 − mA − 5.8 11.6 mA − 2.5 − mA − 143 286 µA − 53 106 µA − 38 76 µA − 0.8 3.0 µA − 1.2 − µA − 4.0 − µA Rev.2.00 Aug 27, 2008 REJ03B0120-0200 Page 34 of 41 R8C/20 Group, R8C/21 Group 5. Electrical Characteristics Timing Requirements (Unless Otherwise Specified: VCC = 5 V, VSS = 0 V at Topr = 25°C) [VCC = 5 V] Table 5.16 Symbol tc(XIN) tWH(XIN) tWL(XIN) XIN input cycle time XIN input “H” width XIN input “L” width XIN Input Parameter Standard Min. Max. 50 − 25 − 25 − Unit ns ns ns Vcc = 5V tc(XIN) tWH(XIN) XIN input tWL(XIN) Figure 5.8 Table 5.17 Symbol tc(TRAIO) tWH(TRAIO) tWL(TRAIO) XIN Input Timing Diagram when VCC = 5 V TRAIO Input Parameter TRAIO input cycle time TRAIO input “H” width TRAIO input “L” width Standard Min. Max. 100 − 40 − 40 − Unit ns ns ns Vcc = 5V tc(TRAIO) tWH(TRAIO) TRAIO input tWL(TRAIO) Figure 5.9 TRAIO Input Timing Diagram when VCC = 5 V Rev.2.00 Aug 27, 2008 REJ03B0120-0200 Page 35 of 41 R8C/20 Group, R8C/21 Group 5. Electrical Characteristics Table 5.18 Symbol tc(CK) tW(CKH) tW(CKL) td(C-Q) th(C-Q) tsu(D-C) th(C-D) i = 0 or 1 Serial Interface Parameter CLK0 input cycle time CLK0 input “H” width CLK0 input “L” width TXDi output delay time TXDi hold time RXDi input setup time RXDi input hold time Standard Min. Max. 200 − 100 − 100 − − 50 0 − 50 − 90 − Unit ns ns ns ns ns ns ns Vcc = 5V tc(CK) tW(CKH) CLK0 tW(CKL) th(C-Q) TXDi td(C-Q) RXDi tsu(D-C) th(C-D) i = 0 or 1 Figure 5.10 Table 5.19 Symbol tW(INH) tW(INL) Serial Interface Timing Diagram when VCC = 5 V External Interrupt INTi (i = 0 to 3) Input Parameter INTi input “H” width INTi input “L” width Standard Min. Max. (1) − 250 250(2) − Unit ns ns NOTES: 1. When selecting the digital filter by the INTi input filter select bit, use the INTi input HIGH width to the greater value, either (1/digital filter clock frequency x 3) or the minimum value of standard. 2. When selecting the digital filter by the INTi input filter select bit, use the INTi input LOW width to the greater value, either (1/digital filter clock frequency x 3) or the minimum value of standard. Vcc = 5V tW(INL) INTi input i = 0 to 3 tW(INH) Figure 5.11 External Interrupt INTi Input Timing Diagram when VCC = 5 V (i = 0 to 3) Rev.2.00 Aug 27, 2008 REJ03B0120-0200 Page 36 of 41 R8C/20 Group, R8C/21 Group 5. Electrical Characteristics Table 5.20 Symbol VOH Electrical Characteristics (3) [VCC = 3 V] Parameter Condition IOH = -1 mA Drive capacity HIGH Drive capacity LOW IOL = 1 mA Drive capacity HIGH Drive capacity LOW Standard Min. Typ. VCC − 0.5 − VCC − 0.5 − VCC − 0.5 − − − − − Output “H” voltage Except XOUT XOUT IOH = -0.1 mA IOH = -50 µA Max. VCC VCC VCC 0.5 0.5 0.5 − Unit V V V V V V V VOL Output “L” voltage Except XOUT XOUT IOL = 0.1 mA IOL = 50 µA − − VT+-VT- Hysteresis INT0, INT1, INT2, INT3, KI0, KI1, KI2, KI3, TRAIO, RXD0, RXD1, CLK0, SSI, SCL, SDA, SSO RESET VI = 3 V, VCC = 3 V VI = 0 V, VCC = 3 V VI = 0 V, VCC = 3 V XIN During stop mode 0.1 0.3 0.1 − − 0.4 − − − V µA µA kΩ MΩ V IIH IIL RPULLUP RfXIN VRAM Input “H” current Input “L” current Pull-up resistance Feedback resistance RAM hold voltage 66 − 2.0 160 3.0 − 4.0 -4.0 500 − − NOTE: 1. VCC = 2.7 to 3.3 V at Topr = -40 to 85°C (J version) / -40 to 125°C (K version), f(XIN) = 10 MHz, unless otherwise specified. Rev.2.00 Aug 27, 2008 REJ03B0120-0200 Page 37 of 41 R8C/20 Group, R8C/21 Group 5. Electrical Characteristics Table 5.21 Electrical Characteristics (4) [VCC = 3 V] (Topr = -40 to 85°C (J version) / -40 to 125°C (K version), Unless Otherwise Specified.) Parameter Condition XIN = 20 MHz (square wave) High-speed on-chip oscillator off Low-speed on-chip oscillator on = 125 kHz No division XIN = 16 MHz (square wave) High-speed on-chip oscillator off Low-speed on-chip oscillator on = 125 kHz No division XIN = 10 MHz (square wave) High-speed on-chip oscillator off Low-speed on-chip oscillator on = 125 kHz No division XIN = 20 MHz (square wave) High-speed on-chip oscillator off Low-speed on-chip oscillator on = 125 kHz Divide-by-8 XIN = 16 MHz (square wave) High-speed on-chip oscillator off Low-speed on-chip oscillator on = 125 kHz Divide-by-8 XIN = 10 MHz (square wave) High-speed on-chip oscillator off Low-speed on-chip oscillator on = 125 kHz Divide-by-8 High-speed XIN clock off on-chip High-speed on-chip oscillator on fOCO = 10 MHz oscillator Low-speed on-chip oscillator on = 125 kHz mode No division XIN clock off High-speed on-chip oscillator on fOCO = 10 MHz Low-speed on-chip oscillator on = 125 kHz Divide-by-8 Low-speed XIN clock off on-chip High-speed on-chip oscillator off oscillator Low-speed on-chip oscillator on = 125 kHz mode Divide-by-8 FMR47 = 1 Wait mode XIN clock off High-speed on-chip oscillator off Low-speed on-chip oscillator on = 125 kHz While a WAIT instruction is executed Peripheral clock operation VCA20 = 0 VCA26 = VCA27 = 0 XIN clock off High-speed on-chip oscillator off Low-speed on-chip oscillator on = 125 kHz While a WAIT instruction is executed Peripheral clock off VCA20 = 0 VCA26 = VCA27 = 0 Stop mode XIN clock off Topr = 25°C High-speed on-chip oscillator off Low-speed on-chip oscillator off CM10 = 1 Peripheral clock off VCA26 = VCA27 = 0 Stop mode XIN clock off Topr = 85°C High-speed on-chip oscillator off Low-speed on-chip oscillator off CM10 = 1 Peripheral clock off VCA26 = VCA27 = 0 Stop mode XIN clock off Topr = 125°C High-speed on-chip oscillator off Low-speed on-chip oscillator off CM10 = 1 Peripheral clock off VCA26 = VCA27 = 0 Min. − Standard Typ. Max. 10.5 21.0 Unit mA Symbol ICC Power supply current High-clock (VCC = 2.7 to 3.3 V) mode In single-chip mode, the output pins are open and other pins are VSS − 8.3 16.6 mA − 5.3 10.6 mA − 4.5 − mA − 3.3 − mA − 2.3 − mA − 5.6 11.2 mA − 2.4 − mA − 138 276 µA − 48 96 µA − 35 70 µA − 0.7 3.0 µA − 1.1 − µA − 3.8 − µA Rev.2.00 Aug 27, 2008 REJ03B0120-0200 Page 38 of 41 R8C/20 Group, R8C/21 Group 5. Electrical Characteristics Timing Requirements (Unless Otherwise Specified: VCC = 3 V, VSS = 0V at Topr = 25°C) [VCC = 3 V] Table 5.22 Symbol tc(XIN) tWH(XIN) tWL(XIN) XIN input cycle time XIN input “H” width XIN input “L” width XIN Input Parameter Standard Min. Max. 100 − 40 − 40 − Unit ns ns ns Vcc = 3V tc(XIN) tWH(XIN) XIN input tWL(XIN) Figure 5.12 Table 5.23 Symbol tc(TRAIO) tWH(TRAIO) tWL(TRAIO) XIN Input Timing Diagram when VCC = 3 V TRAIO Input Parameter TRAIO input Cycle time TRAIO input “H” width TRAIO input “L” width Standard Min. Max. 300 − 120 − 120 − Unit ns ns ns Vcc = 3V tc(TRAIO) tWH(TRAIO) TRAIO input tWL(TRAIO) Figure 5.13 TRAIO Input Timing Diagram when VCC = 3 V Rev.2.00 Aug 27, 2008 REJ03B0120-0200 Page 39 of 41 R8C/20 Group, R8C/21 Group 5. Electrical Characteristics Table 5.24 Symbol tc(CK) tW(CKH) tW(CKL) td(C-Q) th(C-Q) tsu(D-C) th(C-D) i = 0 or 1 Serial Interface Parameter CLK0 input cycle time CLK0 input “H” width CLK0 input “L” width TXDi output delay time TXDi hold time RXDi input setup time RXDi input hold time Standard Min. Max. 300 − 150 − 150 − − 80 0 − 70 − 90 − Unit ns ns ns ns ns ns ns Vcc = 3V tc(CK) tW(CKH) CLK0 tW(CKL) th(C-Q) TXDi td(C-Q) RXDi tsu(D-C) th(C-D) i = 0 or 1 Figure 5.14 Table 5.25 Symbol tW(INH) tW(INL) Serial Interface Timing Diagram when VCC = 3 V External Interrupt INTi (i = 0 to 3) Input Parameter INTi input “H” width INTi input “L” width Standard Min. Max. (1) − 380 380(2) − Unit ns ns NOTES: 1. When selecting the digital filter by the INTi input filter select bit, use the INTi input HIGH width to the greater value, either (1/digital filter clock frequency x 3) or the minimum value of standard. 2. When selecting the digital filter by the INTi input filter select bit, use the INTi input LOW width to the greater value, either (1/digital filter clock frequency x 3) or the minimum value of standard. Vcc = 3V tW(INL) INTi input i = 0 to 3 tW(INH) Figure 5.15 External Interrupt INTi Input Timing Diagram when VCC = 3 V (i = 0 to 3) Rev.2.00 Aug 27, 2008 REJ03B0120-0200 Page 40 of 41 R8C/20 Group, R8C/21 Group Package Dimensions Package Dimensions Diagrams showing the latest package dimensions and mounting information are available in the “Packages” section of the Renesas Technology website. JEITA Package Code P-LQFP48-7x7-0.50 RENESAS Code PLQP0048KB-A Previous Code 48P6Q-A MASS[Typ.] 0.2g HD *1 D 36 25 NOTE) 1. DIMENSIONS "*1" AND "*2" DO NOT INCLUDE MOLD FLASH. 2. DIMENSION "*3" DOES NOT INCLUDE TRIM OFFSET. bp b1 37 24 E HE c1 *2 c Reference Symbol Dimension in Millimeters Terminal cross section 48 ZE 13 1 ZD Index mark 12 A2 F A1 L L1 D E A2 HD HE A A1 bp b1 c c1 e x y ZD ZE L L1 Min 6.9 6.9 8.8 8.8 0 0.17 0.09 0° y e *3 bp Detail F x 0.35 Nom Max 7.0 7.1 7.0 7.1 1.4 9.0 9.2 9.0 9.2 1.7 0.1 0.2 0.22 0.27 0.20 0.145 0.20 0.125 8° 0.5 0.08 0.10 0.75 0.75 0.5 0.65 1.0 A Rev.2.00 Aug 27, 2008 REJ03B0120-0200 Page 41 of 41 c REVISION HISTORY Rev. 0.10 0.20 Date Mar 08, 2005 Sep 29, 2005 R8C/20 Group, R8C/21 Group Datasheet Description Page − − First Edition issued Summary Words standardized - Clock synchronous serial interface → Clock synchronous serial I/O - Chip-select clock synchronous interface(SSU) → Clock synchronous serial I/O with chip select - I2C bus interface(IIC) → I2C bus interface Table1.1 R8C/20 Group Performance, Table1.2 R8C/21 Group Performance Serial Interface revised: - Clock Synchronous Serial Interface: 1 channel I2C bus Interface (3), Clock synchronous serial I/O with chip select - Power-On Reset Circuit added - Power Consumption value determined Table 1.3 Product Information of R8C/20 Group, Table 1.4 Product Information of R8C/21 Group Date revised. Figure 1.4 Pin Assignment Pin name revised: - P3_5/SSCK(/SCL) → P3_5/ SCL/SSCK - P3_4/SCS(/SDA) → P3_4/ SDA /SCS - VSS → VSS/AVSS - VCC → VCC/AVCC - P1_5/RXD0/(TRAIO/INT1) → P1_5/RXD0/(TRAIO)/(INT1) - P6_6/INT2/(TXD1) → P6_6/INT2/TXD1 - P6_7/INT3/(RXD1) → P6_7/INT3/RXD1 - NOTE2 added Table 1.5 Pin Description - Analog Power Supply Input: line added - I2C Bus Interface (IIC) → I2C Bus Interface - SSU → Clock Synchronous Serial I/O with Chip Select Table 1.6 Pin Name Information by Pin Number revised - Pin Number 1: (SCL) → SCL - Pin Number 2: (SDA) → SDA - Pin Number 9: VSS → VSS/AVSS - Pin Number 11: VCC → VCC/AVCC - Pin Number 26: (TXD1) → TXD1 - Pin Number 27: (RXD1) → RXD1 Table 4.1 SFR Information (1) revised - 0013h: XXXXXX00b → 00h Table 4.3 SFR Information (3) revised - 00BCh: 0000X000b → 00h/0000X000b Table 4.4 SFR Information (4) revised - 00D6h: 00000XXXb → 00h - 00F5h: UART1 Function Select Register added Table 4.5 SFR Information (5) revised - 0104h: TRATR → TRA 2, 3 5, 6 7 8 9 15 17 18 19 A-1 REVISION HISTORY Rev. 0.20 Date Sep 29, 2005 R8C/20 Group, R8C/21 Group Datasheet Description Page 20 Summary Table 4.6 SFR Information (6) revised - 0145h: POCR0 → TRDPOCR0 - 0146h, 0147h: TRDCNT0 → TRD0 - 0148h, 0149h: GRA0 → TRDGRA0 - 014Ah, 014Bh: GRB0 → TRDGRB0 - 014Ch, 014Dh: GRC0 → TRDGRC0 - 014Eh, 014Fh: GRD0 → TRDGRD0 - 0155h: POCR1 -> TRDPOCR1 - 0156h, 0157h: TRDCNT1 → TRD1 - 0158h, 0159h: GRA1 → TRDGRA1 - 015Ah, 015Bh: GRB1 → TRDGRB1 - 015Ch, 015Dh: GRC1 → TRDGRC1 - 015Eh, 015Fh: GRD1 → TRDGRD1 5. Electrical Characteristics added Table 1.1 Functions and Specifications for R8C/20 Group revised. NOTE1 deleted. Table 1.2 Functions and Specifications for R8C/21 Group revised. NOTE1 deleted. Table 1.3 Product Information for R8C/20 Group; “R5F2120AJFP (D)”, “R5F2120CJFP (D)”, “R5F2120AKFP (D)”, “R5F2120CKFP (D)”, and NOTE added. Figure 1.2 Type Number, Memory Size, and Package of R8C/20 Group; “A: 96 KB” and “C: 128 KB” added. Table 1.4 Product Information for R8C/21 Group; “R5F2121AJFP (D)”, “R5F2121CJFP (D)”, “R5F2121AKFP (D)”, “R5F2121CKFP (D)”, and NOTE added. Figure 1.3 Type Number, Memory Size, and Package of R8C/21 Group; “A: 96 KB” and “C: 128 KB” added. Figure 3.1 Memory Map of R8C/20 Group revised. Figure 3.2 Memory Map of R8C/21 Group revised. Table 4.1 SFR Information (1)(1); NOTE8; “The CSPROINI bit in the OFS register is set to 0.” → “The CSPROINI bit in the OFS register is 0.” revised. Table 5.1 Absolute Maximum Ratings; Power dissipation revised. Table 5.2 Recommended Operating Conditions; System clock revised. Table 5.8 Voltage Monitor 1 Reset Circuit Electrical Characteristics → Table 5.8 Power-on Reset Circuit, Voltage Monitor 1 Reset Circuit Electrical Characteristics(1) replaced. Table 5.8 revised. NOTE3 added. Table 5.9 Power-on Reset Circuit Electrical Characteristics deleted. Figure 5.3 Power-on Reset Circuit Electrical Characteristics revised. Table 5.10 High-Speed On-Chip Oscillator Circuit Electrical Characteristics → Table 5.9 High-Speed On-Chip Oscillator Circuit Electrical Characteristics revised. A-2 22 1.00 Nov 15, 2006 2 3 5 All pages “Preliminary” and “Under development” deleted 6 13 14 15 21 26 27 REVISION HISTORY Rev. 1.00 Date Nov 15, 2006 R8C/20 Group, R8C/21 Group Datasheet Description Page 33 Summary Table 5.15 Electrical Characteristics (1) [VCC = 5 V] → Table 5.14 Electrical Characteristics (1) [VCC = 5 V] revised. RAM Hold Voltage, Min.; “1.8” → “2.0” corrected. Table 5.16 Electrical Characteristics (2) [Vcc = 5 V] → Table 5.15 Electrical Characteristics (2) [Vcc = 5 V] revised. Wait mode revised. Table 5.21 Electrical Characteristics (3) [VCC = 3 V → Table 5.20 Electrical Characteristics (3) [VCC = 3 V] revised. RAM hold voltage, Min.;“1.8” → “2.0” corrected. Table 5.22 Electrical Characteristics (4) [Vcc = 3 V] → Table 5.21 Electrical Characteristics (4) [Vcc = 3 V] revised. Wait mode revised. “RENESAS TECHNICAL UPDATE” reflected: TN-16C-A172A/E Table 1.3, Table 1.4 revised Figure 1.2, Figure 1.3; ROM number “XXX” added Figure 3.1, Figure 3.2; “Expanding area” deleted Table 5.2; NOTE2 revised Table 5.4; NOTE2 and NOTE4 revised Table 5.5; NOTE2 and NOTE5 revised Table 5.6; “td(Vdet1-A)” added, NOTE5 added Table 5.7; “td(Vdet2-A)” and NOTE2 revised, NOTE5 added Table 5.8; “trth” and NOTE2 revised Figure 5.3 revised 34 37 38 2.00 Aug 27, 2008 − 5, 6 13, 14 21 23 24 25 26 All trademarks and registered trademarks are the property of their respective owners. A-3 Sales Strategic Planning Div. Nippon Bldg., 2-6-2, Ohte-machi, Chiyoda-ku, Tokyo 100-0004, Japan Notes: 1. This document is provided for reference purposes only so that Renesas customers may select the appropriate Renesas products for their use. Renesas neither makes warranties or representations with respect to the accuracy or completeness of the information contained in this document nor grants any license to any intellectual property rights or any other rights of Renesas or any third party with respect to the information in this document. 2. Renesas shall have no liability for damages or infringement of any intellectual property or other rights arising out of the use of any information in this document, including, but not limited to, product data, diagrams, charts, programs, algorithms, and application circuit examples. 3. You should not use the products or the technology described in this document for the purpose of military applications such as the development of weapons of mass destruction or for the purpose of any other military use. When exporting the products or technology described herein, you should follow the applicable export control laws and regulations, and procedures required by such laws and regulations. 4. All information included in this document such as product data, diagrams, charts, programs, algorithms, and application circuit examples, is current as of the date this document is issued. Such information, however, is subject to change without any prior notice. Before purchasing or using any Renesas products listed in this document, please confirm the latest product information with a Renesas sales office. Also, please pay regular and careful attention to additional and different information to be disclosed by Renesas such as that disclosed through our website. (http://www.renesas.com ) 5. Renesas has used reasonable care in compiling the information included in this document, but Renesas assumes no liability whatsoever for any damages incurred as a result of errors or omissions in the information included in this document. 6. When using or otherwise relying on the information in this document, you should evaluate the information in light of the total system before deciding about the applicability of such information to the intended application. Renesas makes no representations, warranties or guaranties regarding the suitability of its products for any particular application and specifically disclaims any liability arising out of the application and use of the information in this document or Renesas products. 7. With the exception of products specified by Renesas as suitable for automobile applications, Renesas products are not designed, manufactured or tested for applications or otherwise in systems the failure or malfunction of which may cause a direct threat to human life or create a risk of human injury or which require especially high quality and reliability such as safety systems, or equipment or systems for transportation and traffic, healthcare, combustion control, aerospace and aeronautics, nuclear power, or undersea communication transmission. If you are considering the use of our products for such purposes, please contact a Renesas sales office beforehand. Renesas shall have no liability for damages arising out of the uses set forth above. 8. Notwithstanding the preceding paragraph, you should not use Renesas products for the purposes listed below: (1) artificial life support devices or systems (2) surgical implantations (3) healthcare intervention (e.g., excision, administration of medication, etc.) (4) any other purposes that pose a direct threat to human life Renesas shall have no liability for damages arising out of the uses set forth in the above and purchasers who elect to use Renesas products in any of the foregoing applications shall indemnify and hold harmless Renesas Technology Corp., its affiliated companies and their officers, directors, and employees against any and all damages arising out of such applications. 9. You should use the products described herein within the range specified by Renesas, especially with respect to the maximum rating, operating supply voltage range, movement power voltage range, heat radiation characteristics, installation and other product characteristics. Renesas shall have no liability for malfunctions or damages arising out of the use of Renesas products beyond such specified ranges. 10. Although Renesas endeavors to improve the quality and reliability of its products, IC products have specific characteristics such as the occurrence of failure at a certain rate and malfunctions under certain use conditions. Please be sure to implement safety measures to guard against the possibility of physical injury, and injury or damage caused by fire in the event of the failure of a Renesas product, such as safety design for hardware and software including but not limited to redundancy, fire control and malfunction prevention, appropriate treatment for aging degradation or any other applicable measures. Among others, since the evaluation of microcomputer software alone is very difficult, please evaluate the safety of the final products or system manufactured by you. 11. In case Renesas products listed in this document are detached from the products to which the Renesas products are attached or affixed, the risk of accident such as swallowing by infants and small children is very high. You should implement safety measures so that Renesas products may not be easily detached from your products. Renesas shall have no liability for damages arising out of such detachment. 12. This document may not be reproduced or duplicated, in any form, in whole or in part, without prior written approval from Renesas. 13. Please contact a Renesas sales office if you have any questions regarding the information contained in this document, Renesas semiconductor products, or if you have any other inquiries. RENESAS SALES OFFICES Refer to "http://www.renesas.com/en/network" for the latest and detailed information. Renesas Technology America, Inc. 450 Holger Way, San Jose, CA 95134-1368, U.S.A Tel: (408) 382-7500, Fax: (408) 382-7501 Renesas Technology Europe Limited Dukes Meadow, Millboard Road, Bourne End, Buckinghamshire, SL8 5FH, U.K. Tel: (1628) 585-100, Fax: (1628) 585-900 Renesas Technology (Shanghai) Co., Ltd. Unit 204, 205, AZIACenter, No.1233 Lujiazui Ring Rd, Pudong District, Shanghai, China 200120 Tel: (21) 5877-1818, Fax: (21) 6887-7858/7898 Renesas Technology Hong Kong Ltd. 7th Floor, North Tower, World Finance Centre, Harbour City, Canton Road, Tsimshatsui, Kowloon, Hong Kong Tel: 2265-6688, Fax: 2377-3473 Renesas Technology Taiwan Co., Ltd. 10th Floor, No.99, Fushing North Road, Taipei, Taiwan Tel: (2) 2715-2888, Fax: (2) 3518-3399 Renesas Technology Singapore Pte. Ltd. 1 Harbour Front Avenue, #06-10, Keppel Bay Tower, Singapore 098632 Tel: 6213-0200, Fax: 6278-8001 Renesas Technology Korea Co., Ltd. Kukje Center Bldg. 18th Fl., 191, 2-ka, Hangang-ro, Yongsan-ku, Seoul 140-702, Korea Tel: (2) 796-3115, Fax: (2) 796-2145 http://www.renesas.com Renesas Technology Malaysia Sdn. Bhd Unit 906, Block B, Menara Amcorp, Amcorp Trade Centre, No.18, Jln Persiaran Barat, 46050 Petaling Jaya, Selangor Darul Ehsan, Malaysia Tel: 7955-9390, Fax: 7955-9510 © 2008. Renesas Technology Corp., All rights reserved. Printed in Japan. Colophon .7.2
