TQFN-16

TQFN-16/33 Package 16-Terminal Ceramic Surface-Mount Case 3.0 X 3.0 mm Nominal Footprint Case Dimensions mm Nom 3.0 3.0 0.75 0.50 1.50 0.50 0.23 0.50 0.23 0.40 0.40 Inches Nom 0.118 0.118 0.029 0.019 0.059 0.019 0.009 0.019 0.009 0.015 0.015 Dimension A B C D E F G H I J K Min 2.87 2.87 Max 3.13 3.13 Min 0.113 0.113 Max 0.123 0.123 TOP VIEW SEATING PLANE SIDE VIEW 0.0~0.05 D F BOTTOM VIEW G B PIN 1 Indicator PIN # 1 H A E I J 0.25 C E K RF Monolithics, Inc. Phone: (972) 233-2903 Fax: (972) 387-8148 RFM Europe Phone: 44 1963 251383 Fax: 44 1963 251510 ©1999 by RF Monolithics, Inc. The stylized RFM logo are registered trademarks of RF Monolithics, Inc. E-mail: info@rfm.com http://www.rfm.com 3x3-TQFN-021606 Page 1 of 3 TQFN-16/33 Package Dimensions Carrier Tape Dimensions Ao Bo Ko F Pitch (P1) W 3.30 ± 0.10 3.30 ± 0.10 1.00 ± 0.10 5.50 ± 0.10 8.00 ± 0.10 12.00 ± 0.30 4.0 mm ±0.1 1.55 mm ±0.05 PIN #1 2.0 mm ±0.1 1.75 mm ±0.1 W (CARRIER TAPE SIZE) F BO 1.5 MIN AO USER DIRECTION OF FEED COVER TAPE SIZE P1 (PITCH) 0.30 mm ±0.05 KO COVER TAPE RF Monolithics, Inc. Phone: (972) 233-2903 Fax: (972) 387-8148 RFM Europe Phone: 44 1963 251383 Fax: 44 1963 251510 ©1999 by RF Monolithics, Inc. The stylized RFM logo are registered trademarks of RF Monolithics, Inc. E-mail: info@rfm.com http://www.rfm.com 3x3-TQFN-021606 Page 2 of 3 TQFN-16/33 Package “B “ Nominal Size 100 REF. "B" REF. Quantity Per Reel 2000 Inches 13 millimeters 330 Tape and Reel Standard Per ANSI / EIA 481 See Detail "A" 12.0 0 13. 20 .2 2.0 RF Monolithics, Inc. Phone: (972) 233-2903 Fax: (972) 387-8148 RFM Europe Phone: 44 1963 251383 Fax: 44 1963 251510 ©1999 by RF Monolithics, Inc. The stylized RFM logo are registered trademarks of RF Monolithics, Inc. E-mail: info@rfm.com http://www.rfm.com 3x3-TQFN-021606 Page 3 of 3
