006-315

RF HAND HELD RF METER • • • • • • • • • • • • • Hand Held Signal Strength Meter Detects Carrier RF Activity 10 digit LED Display with Peak Hold Displays -108dBm to –40dBm Signal Strength Operates from Single PP3 Battery Battery Low Indication Auto Shutoff after 2min Requires no Radio License 315, 433, 868, 869 & 915 versions. Applications Detects Interference Assists Range Testing Radio Installation Performance Check Transmitter Check Description A miniature RF Meter which can be used to show the presence of a Radio Signal. Briefly press the power switch and the LED bargraph shows the RF activity within the local environment. The peak signal is held for 1 second. This can be invaluable when installing a Radio system to determine if other RF signals are present (interference) and also validate the signal strength of the radio transmitter to be installed. Green represents a strong RF signal and red represents a weak RF signal. Technical Specification Supply Voltage / Current Frequency Operating Temperature RF sensitivity Bandwidth Initial frequency accuracy Max R.F. input 3dB Bandwidth Dimensions 9V / 20mA (PP3 Battery supplied) Various, see below -0 to + 60 oC -110dBm (typ) 600KHz ±50KHz -20DBm +/-400KHz 110mm x 65mm x 24mm (not including Antenna) Part No 006-315 006-433 006-868 006-869 006-915 Description RF Meter 315MHz RF Meter 433.92MHz RF Meter 868.35MHz RF Meter 869.84MHz RF Meter 914.50MHz R F Solutions Ltd., Unit 21, Cliffe Industrial Estate, Lewes, E. Sussex. BN8 6JL. England. Email : sales@rfsolutions.co.uk http://www.rfsolutions.co.uk Tel +44 (0)1273 898 000 Fax +44 (0)1273 480 661 R F Solutions Ltd is a member of the Low Power Radio Association. DS066-4 April ‘05 ©2005 REG No 277 4001, ENGLAND. Page 1 Information contained in this document is believed to be accurate, however no representation or warranty is given and no liability is assumed by R.F. Solutions Ltd. with respect to the accuracy of such information. Use of R.F.Solutions as critical components in life support systems is not authorised except with express written approval from R.F.Solutions Ltd.
