SP3-15-10

SP3 Series Mini-SIP Passive Delay Modules Similar 3-pin SIP refer to SIL2 Series Fast Rise Time, Low DCR High Bandwidth 0.35 / tr Low Distortion LC Network Tight Delay Tolerance Standard Impedances: 50 to 200 Ω Stable Delay vs. Temperature: 100 ppm/OC Operating Temperature Range -55OC to +125OC Electrical Specifications at 25OC Delay (ns) Rise Time 20% - 80% max. (ns) DCR max. (Ohms) 50 Ohm Impedance P/N 55 Ohm Impedance P/N 75 Ohm Impedance P/N 100 Ohm Impedance P/N 200 Ohm Impedance P/N 2-tap 4-pin SIP refer to SL2T Series Operating Specifications - Passive Delay Lines Pulse Overshoot (Pos) .................................... 5% to 10%, typical Pulse Distortion (S) ...................................................... 3% typical Working Voltage ............................................. 25 VDC maximum Dielectric Strength .......................................... 100VDC minimum Insulation Resistance ......................... 1,000 MΩ min. @ 100VDC Temperature Coefficient ............................... 100 ppm/ OC, typical Bandwidth (fC) ....................................................... 0.35/tr approx. Operating Temperature Range ............................ -55O to +125OC Storage Temperature Range ............................... -65 O to +150OC 0.0 1 ± .20 1.5 ± .20 2 ± .20 2.5 ± .20 3 ± .20 4 ± .20 5 ± .25 6 ± .30 7 ± .30 8 ± .30 9 ± .30 10 ± .30 11 ± .40 12 ± .50 13 ± .60 14 ± .70 15 ± .70 16 ± .80 20 ± 1.0 −− 1.6 1.6 1.6 1.6 1.7 1.7 1.8 2.0 2.3 2.7 2.9 3.3 3.3 3.6 4.0 4.3 4.6 4.8 5.6 .10 .20 .30 .40 .50 .60 .70 .80 .85 .90 .95 1.10 1.20 1.40 1.50 1.60 1.60 1.70 1.80 2.00 SP3-0 SP3-1-50 SP3-1.5-50 SP3-2-50 SP3-2.5-50 SP3-3-50 SP3-4-50 SP3-5-50 SP3-6-50 SP3-7-50 SP3-8-50 SP3-9-50 SP3-10-50 SP3-11-50 SP3-12-50 SP3-13-50 SP3-14-50 SP3-15-50 SP3-16-50 SP3-20-50 SP3-0 SP3-1-55 SP3-1.5-55 SP3-2-55 SP3-2.5-55 SP3-3-55 SP3-4-55 SP3-5-55 SP3-6-55 SP3-7-55 SP3-8-55 SP3-9-55 SP3-10-55 SP3-11-55 SP3-12-55 SP3-13-55 SP3-14-55 SP3-15-55 SP3-16-55 SP3-20-55 SP3-0 SP3-1-75 SP3-1.5-75 SP3-2-75 SP3-2.5-75 SP3-3-75 SP3-4-75 SP3-5-75 SP3-6-75 SP3-7-75 SP3-8-75 SP3-9-75 SP3-10-75 SP3-11-75 SP3-12-75 SP3-13-75 SP3-14-75 SP3-15-75 SP3-16-75 SP3-20-75 SP3-0 SP3-1-10 SP3-1.5-10 SP3-2-10 SP3-2.5-10 SP3-3-10 SP3-4-10 SP3-5-10 SP3-6-10 SP3-7-10 SP3-8-10 SP3-9-10 SP3-10-10 SP3-11-10 SP3-12-10 SP3-13-10 SP3-14-10 SP3-15-10 SP3-16-10 SP3-20-10 SP3-0 SP3-1-20 SP3-1.5-20 SP3-2-20 SP3-2.5-20 SP3-3-20 SP3-4-20 SP3-5-20 SP3-6-20 SP3-7-20 SP3-8-20 SP3-9-20 SP3-10-20 SP3-11-20 SP3-12-20 SP3-13-20 SP3-14-20 SP3-15-20 SP3-16-20 SP3-20-20 1. Rise Times are measured from 20% to 80% points. 2. Delay Times measured at 50% points of leading edge. 3. Output terminated to ground through RL=ZO Dimensions in inches (mm) .490 (12.45) MAX. .120 (3.05) MAX. SP3 Style Schematic SP3 1 IN 2 COM 3 OUT .020 (0.51) TYP. .100 (2.54) Specifications subject to change without notice. .375 (9.53) MAX. .030 (0.76) TYP. .120 (3.05) MIN. .010 (0.25) TYP. .060 (1.52) TYP. For other values & Custom Designs, contact factory. SP3 9901 Rhombus Industries Inc. 15801 Chemical Lane, Huntington Beach, CA 92649-1595 Phone: (714) 898-0960 • FAX: (714) 896-0971 www.rhombus-ind.com • email: sales@rhombus-ind.com
