TF Series High Performance 20 Section 10-Tap Delay Lines Fast Rise Time ( td / tr 10 ) High Bandwidth 0.35 / tr Low Distortion LC Network 10 Equal Delay Taps Standard Impedances: 50 - 75 - 100 Ω Stable Delay vs. Temperature: 100 ppm/OC Operating Temperature Range -55OC to +125OC Electrical Specifications at 25OC Delay Tolerances Total (ns) Tap-to-Tap (ns) 50 Ohm Part Number 1, 2, 3 COM 28 27 26 25 24 TF Schematic Diagram 23 22 21 20 19 18 17 16 COM 15 1 IN 2 3 4 5 6 7 8 9 10 11 12 13 14 10% 20% 30% 40% 50% 60% 70% 80% 90% 100% Rise Time (ns) DCR max. (Ohms) 75 Ohm Part Number Rise Time (ns) DCR max. (Ohms) 100 Ohm Part Number Rise Time (ns) DCR max. (Ohms) 50 ± 2.5 75 ± 3.7 80 ± 4.0 100 ± 5.0 120 ± 6.0 150 ± 15.0 200 ± 10.0 250 ± 12.5 300 ± 15.0 400 ± 20.0 500 ± 25.0 5.0 ± 1.0 7.5 ± 2.0 8.0 ± 2.0 10.0 ± 2.0 12.0 ± 2.0 15.0 ± 2.5 20.0 ± 3.0 25.0 ± 3.0 30.0 ± 3.5 40.0 ± 4.0 50.0 ± 5.0 TF50-5 TF75-5 TF80-5 TF100-5 TF120-5 TF150-5 TF200-5 TF250-5 TF300-5 TF400-5 TF500-5 6.2 9.2 9.5 11.2 13.4 15.7 21.3 27.2 31.1 41.0 50.8 1.9 2.1 2.2 2.3 2.3 2.4 2.5 2.6 2.7 2.8 2.9 TF50-7 TF75-7 TF80-7 TF100-7 TF120-7 TF150-7 TF200-7 TF250-7 TF300-7 TF400-7 TF500-7 6.2 9.2 9.6 11.7 13.7 16.1 21.5 27.3 31.4 41.3 53.1 2.0 2.2 2.3 2.5 2.7 3.1 3.3 3.5 3.6 3.7 3.9 1.450 (36.83) MAX. TF50-10 TF75-10 TF80-10 TF100-10 TF120-10 TF150-10 TF200-10 TF250-10 TF300-10 TF400-10 TF500-10 6.4 9.4 9.9 12.5 13.8 16.4 21.6 27.5 32.3 41.7 54.2 2.2 2.3 2.4 2.7 3.1 3.5 3.8 4.3 4.6 4.8 5.1 1. Rise Times are measured from 10% to 90% points. 2. Delay Times measured at 50% points of leading edge. 3. Output (100% Tap) terminated through ZO to ground. .320 (8.13) .290 (7.37) .300 (7.62) MAX. Dimensions in Inches (mm) .030 .275 (0.76) (6.99) TYP. MAX. .120 (3.05) MIN. .010 (0.25) TYP. .350 (8.89) .310 (7.87) .050 (1.27) TYP. .020 (0.51) TYP. .100 (2.54) TYP. SP3 Series 3-Pin Mini-SIP Passive Delays Refer to SIL2 Series .490 (12.45) MAX. .120 (3.05) MAX. Electrical Specifications at 25OC SP3 Style Schematic Delay (ns) Rise Time 20% - 80% max. (ns) DCR max. (Ohms) Part Number Zo: XX= 50, 55, 75, 93, 10 or 20 1 IN 2 COM 3 OUT 63  .020 (0.51) TYP. .100 (2.54) .375 (9.53) MAX. .030 (0.76) TYP. .120 (3.05) MIN. .010 (0.25) TYP. .060 (1.52) TYP. Part Number Examples: SP3-2-50 = 2 ns 50 Ω SP3-2.5-93 = 2.5 ns 93 Ω SP3-5-10 = 5 ns 100 Ω SP3-10-20 = 10 ns 200 Ω 1.0 ± .20 1.5 ± .20 2.0 ± .20 2.5 ± .20 3.0 ± .20 3.5 ± .20 4.0 ± .20 4.5 ± .20 5.0 ± .25 6.0 ± .30 7.0 ± .30 7.5 ± .30 8.0 ± .30 10 ± .30 1.6 1.6 1.6 1.6 1.7 1.7 1.7 1.7 1.8 2.0 2.2 2.4 2.4 2.8 .20 .30 .40 .50 .60 .60 .70 .70 .80 .85 .90 .95 .95 1.20 SP3-1 - XX SP3-1.5 - XX SP3-2 - XX SP3-2.5 - XX SP3-3 - XX SP3-3.5 - XX SP3-4 - XX SP3-4.5 - XX SP3-5 - XX SP3-6 - XX SP3-7 - XX SP3-7.5 - XX SP3-8 - XX SP3-10 - XX 1. Rise Times are measured from 20% to 80% points. 2. Delay Times measured at 50% points of leading edge. 3. Output (100% Tap) terminated through ZO to ground. 6SHFLILFDWLRQV VXEMHFW WR FKDQJH ZLWKRXW QRWLFH www.rhombus-ind.com UKRPEXV LQGXVWULHV LQF )RU RWKHU YDOXHV &XVWRP 'HVLJQV FRQWDFW IDFWRU\ sales@rhombus-ind.com 11 TEL: (714) 898-0960 FAX: (714) 896-0971 TF-SP3 2001-01
