PACKAGE INFORMATION
PE-SOT-23-6-0611
•
SOT-23-6 (SC-74)
Unit: mm
PACKAGE DIMENSIONS
2.9±0.2 1.9±0.2 (0.95) (0.95) +0.2 1.1 −0.1 0.8±0.1 4
6
5
+0.2 1.6 −0.1
2.8±0.3
0 to 0.1
1
2
0.2 Min.
+0.1 0.4−0.2
+0.1 0.15 −0.05
TAPING SPECIFICATION
0.3±0.1 +0.1 φ1.5 0 4.0±0.1 2.0±0.05
1 2.0Max.
2
3 4.0±0.1
3.3
∅1.1±0.1
TR User Direction of Feed
TAPING REEL DIMENSIONS
(1reel=3000pcs)
REUSE REEL (EIAJ-RRM-08Bc)
11.4±1.0 9.0±0.3
21±0.8
0 180 −1.5
2±0.5
13±0.2
+1 60 0
3.2
8.0±0.3
6
5
4
3.5±0.05
1.75±0.1
PACKAGE INFORMATION
PE-SOT-23-6-0611
POWER DISSIPATION (SOT-23-6)
This specification is at mounted on board. Power Dissipation (PD) depends on conditions of mounting on board. This specification is based on the measurement at the condition below: Measurement Conditions Standard Land Pattern Environment Board Material Board Dimensions Copper Ratio Through-hole Measurement Result
(Topt=25°C,Tjmax=125°C)
Mounting on Board (Wind velocity=0m/s) Glass cloth epoxy plactic (Double sided) 40mm × 40mm × 1.6mm Top side : Approx. 50% , Back side : Approx. 50% φ0.5mm × 44pcs
Standard Land Pattern Power Dissipation Thermal Resistance
600
Free Air 250mW 400°C/W
420mW θja=(125−25°C)/0.42W=263°C/W
Power Dissipation PD(mW)
500 420 400 300
On Board
40
100 0 0 25 50 75 85 100 Ambient Temperature (°C) 125 150
Power Dissipation
40
200
Measurement Board Pattern IC Mount Area Unit : mm
RECOMMENDED LAND PATTERN
0.7 MAX.
1.0
0.95 0.95 1.9
2.4
(Unit: mm)
