2SB1188

Transistors Medium Power Transistor (32V, 2A) 2SD1766 / 2SD1758 / 2SD1862 / 2SD1055 / 2SD1919 / 2SD1227M FFeatures 1) Low VCE(sat). VCE(sat) = 0.5V (Typ.) (IC / IB = 2A / 0.2A) 2) Complements the 2SB1188 / 2SB1182 / 2SB1240 / 2SB891F / 2SB822 / 2SB1277 / 2SB911M FStructure Epitaxial planar type NPN silicon transistor FExternal dimensions (Units: mm) (96-217-B24) 256 Transistors FAbsolute maximum ratings (Ta = 25_C) 2SD1766 / 2SD1758 / 2SD1862 / 2SD1055 / 2SD1919 / 2SD1227M FElectrical characteristics (Ta = 25_C) 257 Transistors FPackaging specifications and hFE 2SD1766 / 2SD1758 / 2SD1862 / 2SD1055 / 2SD1919 / 2SD1227M hFE values are classified as follows : FElectrical characteristic curves 258 Transistors 2SD1766 / 2SD1758 / 2SD1862 / 2SD1055 / 2SD1919 / 2SD1227M 259
