EDZV5.1B
Data sheet
Zener Diode
● Outline
PD
150
mW
● Feature
● Inner Circuit
High reliability
Small mold type
● Application
● Packaging Specification
Voltage regulation
Packing
Reel Size(mm)
Taping Width(mm)
Basic Ordering Unit(pcs)
Taping Code
Marking
● Structure
Silicon Epitaxial Planar
Embossed Tape
180
8
8000
T2R
A2
● Absolute Maximum Rating (Ta = 25℃)
Parameter
Power dissipation
Junction temperature
Storage temperature
www.rohm.com
© 2017 ROHM Co., Ltd. All rights reserved.
Symbol
Limits
Unit
PD
Tj
Tstg
150
150
-55 ～ 150
mW
1/6
℃
℃
2017/01/16_Rev.002
Data sheet
EDZV Series
● Characteristic (Ta = 25ºC)
Symbol
P/N
EDZV 2.0B
EDZV 2.2B
EDZV 2.4B
EDZV 2.7B
EDZV 3.0B
EDZV 3.3B
EDZV 3.6B
EDZV 3.9B
EDZV 4.3B
EDZV 4.7B
EDZV 5.1B
EDZV 5.6B
EDZV 6.2B
EDZV 6.8B
EDZV 7.5B
EDZV 8.2B
EDZV 9.1B
EDZV 10B
EDZV 11B
EDZV 12B
EDZV 13B
EDZV 15B
EDZV 16B
EDZV 18B
EDZV 20B
EDZV 22B
EDZV 24B
EDZV 27B
EDZV 30B
EDZV 33B
EDZV 36B
VZ test time is 40ms.
Zener Voltage:VZ(V)
Dynamic Impedance:ZZ(Ω) Zener Impedance:ZZK(Ω) Reverse Current:IR(μA)
MIN.
MAX.
Iz(mA)
MAX.
Iz(mA)
MAX.
Iz(mA)
MAX.
VR(V)
2.020
2.220
2.430
2.690
3.010
3.320
3.600
3.890
4.170
4.550
4.980
5.490
6.060
6.650
7.280
8.020
8.850
9.770
10.76
11.74
12.91
14.34
15.85
17.56
19.52
21.54
23.72
26.19
29.19
32.15
35.07
2.200
2.410
2.630
2.910
3.220
3.530
3.845
4.160
4.430
4.750
5.200
5.730
6.330
6.930
7.600
8.360
9.230
10.21
11.22
12.24
13.49
14.98
16.51
18.35
20.39
22.47
24.78
27.53
30.69
33.79
36.87
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
2.0
2.0
2.0
2.0
100
100
100
110
120
120
100
100
100
100
80
60
60
40
30
30
30
30
30
30
37
42
50
65
85
100
120
150
200
250
300
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
2.0
2.0
2.0
2.0
1000
1000
1000
1000
1000
1000
1000
1000
1000
800
500
200
100
60
60
60
60
60
60
80
80
80
80
80
100
100
120
150
200
250
300
0.5
0.5
0.5
0.5
0.5
0.5
1.0
1.0
1.0
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
120
120
120
100
50.0
20.0
10.0
5.0
5.0
2.0
2.0
1.0
1.0
0.5
0.5
0.5
0.5
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.5
0.7
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.5
2.5
3.0
3.5
4.0
5.0
6.0
7.0
8.0
9.0
10.0
11.0
12.0
13.0
15.0
17.0
19.0
21.0
23.0
25.0
27.0
● Marking
P/N
Marking
P/N
Marking
EDZV 2.0B
EDZV 2.2B
EDZV 2.4B
EDZV 2.7B
EDZV 3.0B
EDZV 3.3B
EDZV 3.6B
EDZV 3.9B
EDZV 4.3B
EDZV 4.7B
EDZV 5.1B
EDZV 5.6B
EDZV 6.2B
EDZV 6.8B
EDZV 7.5B
EDZV 8.2B
02
12
22
32
42
52
62
72
82
92
A2
C2
E2
F2
H2
J2
EDZV 9.1B
EDZV 10B
EDZV 11B
EDZV 12B
EDZV 13B
EDZV 15B
EDZV 16B
EDZV 18B
EDZV 20B
EDZV 22B
EDZV 24B
EDZV 27B
EDZV 30B
EDZV 33B
EDZV 36B
L2
05
15
25
35
45
55
65
75
85
95
A5
C5
E5
F5
www.rohm.com
© 2017 ROHM Co., Ltd. All rights reserved.
2/6
2017/01/16_Rev.002
EDZV Series
Data sheet
● Characteristic Curves
www.rohm.com
© 2017 ROHM Co., Ltd. All rights reserved.
3/6
2017/01/16_Rev.002
EDZV5.1B
Data sheet
● Characteristic Curves
www.rohm.com
© 2017 ROHM Co., Ltd. All rights reserved.
4/6
2017/01/16_Rev.002
EDZV5.1B
Data sheet
● Characteristic Curves
www.rohm.com
© 2017 ROHM Co., Ltd. All rights reserved.
5/6
2017/01/16_Rev.002
EDZV5.1B
Data sheet
● Dimension (EMD2 SOD-523 SC-79)
●Taping (Unit:mm)
www.rohm.com
6/6
© 2017 ROHM Co., Ltd. All rights reserved.
2017/01/16_Rev.002
