High efficiency, single-digit numeric displays
LA-501DN Series
The LA-501DN series were designed to meet the need for 13mm single-digit numeric displays. These LED numeric displays use GaAsP on GaP for the emitting material (with the exception of green) and are housed in an epoxy resin package. They are single-digit displays with a character height of 13.0mm. Features 1) Height of character: 13.0mm 2) Common anode and common cathode configurations are available for each color. 3) High-efficiency reflectors are used to achieve a bright, clear display. 4) The package surface is painted black and the segments are colored the display color. Dimensions (Unit : mm)
12.5 10°
1.25
1.25 7.4
φ1.25
(10.16)
3.5Min.
0.5 (2.54)
7.0
Tolerances are ±0.2 unless otherwise noted:
Selection guide
Emitting color Red Common Anode Cathode LA-501VD LA-501VN LA-501MD LA-501MN Green
Pin assignments
Pin No.
10 9 8 7 6
Function Segment "e" Segment "d" Common Segment "c" D.P Segment "b" Segment "a" Common Segment "f" Segment "g"
+++++
a f
g
b
e
d
c
+++++
Pin No. 1 2 3 4
D.P 5
1 2 3 4 5 6 7 8 9 10
www.rohm.com
c ○ 2011 ROHM Co., Ltd. All rights reserved.
0.25
1/3
2011.04 - Rev.B
(15.24)
13.0 17.5
LA-501DN Series
Internal circuit schematic (example of common cathode)
COM 3,8
Data Sheet
a b c d e f g D.P 7 6 4 2 1 9 10 5
Absolute maximum ratings (Ta = 25C)
Parameter Power dissipation Power dissipation Forward current Peak forward current Reverse voltage Operating temperature Storage temperature Symbol PD PD / seg IF IFP VR Topr Tstg Red Green Unit mW mW mA mA V °C °C LA-501VD / VN LA-501MD / MN 480 60 20 60∗ 5 −25~+75 −30~+85 480 60 20 60∗ 5
∗ Pulse width 1ms duty 1 / 5
Electrical and optical characteristics (Ta = 25C)
Parameter
Forward voltage Reverse current Peak wavelength Spectral line half width
Not designed for radiation resistance.
Symbol Conditions Min. VF IR IF = 10mA VR = 5V IF = 10mA IF = 10mA − − − −
Red Typ. Max. Min. 2.0 − 650 40 2.8 100 − − − − − −
Green Typ. Max. 2.1 − 563 40 2.8 100 − −
Unit V μA nm nm
λP
Δλ
Luminous intensity
Color Red λP 650 Type LA-501VD LA-501VN Green 563 LA-501MD LA-501MN
Note : Measured at IF = 10 mA
Min. 5.6
Typ. 16
Max. − −
Unit mcd
5.6
16
mcd
www.rohm.com
c ○ 2011 ROHM Co., Ltd. All rights reserved.
2/3
2011.04 - Rev.B
LA-501DN Series
Electrical and optical characteristic curves
100
Ta=25°C
Data Sheet
10
Relative Luminous Intensity
Forward Current:IF(mA)
LA-501MD LA-501MN LA-501VD LA-501VN
10.00
Ta=25°C
1.00
1
0.10
0.1
1
1.5
2
2.5
3
0.01
1
10 Forward Current:IF(mA)
100
Forward Voltage:VF(V)
Fig.1 Forward Current - Forward Voltage
Fig.2 Relative Luminous Intensity - Forward Current
)
IF=10mA
1.4
1.2 1 0.8 0.6 0.4 -25 -15 -5
IF peak Max. Ratio of Maximum Tolerable peak IF Max. Current to Maximum Forward Current
1.6
10
Relative Luminous Intensity
(
100kHz
300Hz
100Hz
30kHz
10kHz
1
5
15 25 35 45 55 65 75
1
300kHz
10
100
1000
30Hz
3kHz
1kHz
10000
100000
Case Temparature (°C)
Pulse Duration : tw(µs)
Fig.3 Relative Luminous Intensity - Case Temperature
Fig.4 Ratio of Maximum Tolerable Peak Current - Pulse Duration
120% 100% 80% 60% 40% 20% 0% -25 -15 -5
Forward Current (%)
5 15 25 35 45 55 65 75 85 Ambient Temperature(°C)
Fig.5 Derating
www.rohm.com
c ○ 2011 ROHM Co., Ltd. All rights reserved.
3/3
2011.04 - Rev.B
