SIM-012SB_10

High power Chip IR LED, side view type SIM-012SB The SIM-012SB is ultra small size and high power ohip sensor. Original technology, original structure and original Optical design enable to use Automatic moantinig machine, Reflow, ultra smallsize, High power. Applications Optical control equipment Light source for remote control devices Features 1) High power by 2 lenze. 2) Emitting pore can have 7time high power then substruk type with parabola structure. 3) Ultra -compact surface mount package. (3mmx3mmx2mm) 4) It is possible to do Reflow. Dimensions (Unit : mm) Note) 1.Unspecified tolerance shall be + 0.2. − 2.Dimension in parenthesis are show for reference. 0.25 2-0.4 1 2 3 0.8 R1 (1.15) 2 3 2 Internal connection diagram 2 1 Absolute maximum ratings (Ta=25C) Parameter Forward current Reverse voltage Power dissipation Pulse forward current Operating temperature Storage temperature ∗ Pulse width=0.1msec, duty ratio 1% Symbol IF VR PD IFP∗ Topr Tstg Limits 40 5 60 0.5 −30~+85 −40~+100 Unit mA V mW A °C °C Electrical and optical characteristics (Ta=25C) Parameter Optical output Emitting strength Forward voltage Reverse current Peak light emitting wavelength Spectral line half width Half-viewing angle Pesponse time Cut-off frequency Symbol PO IE VF IR Min. − 0.9 − − − − − − − Typ. 3.5 − 1.2 − 950 40 ±12 1.0 1.0 Max. − 7.1 1.5 10 − − − − − Unit mW mW/sr V μA nm nm deg μs MHz IF=20mA IF=20mA IF=20mA VR=3V IF=20mA IF=20mA IF=20mA IF=20mA IF=20mA Conditions λP Δλ θ1 / 2 tr·tf fC www.rohm.com c ○ 2010 ROHM Co., Ltd. All rights reserved. 1/2 2010.12 - Rev.B SIM-012SB Electrical and optical characteristic curves 8 50 Data Sheet 40 −25°C 0°C 25°C 50°C 75°C EMITTING STRENGTH : IE (mW/sr) 50 FORWARD CURRENT : IF (mA) FORWARD CURRENT : IF (mA) 6 40 30 20 10 0 −20 30 4 20 2 10 0 0 0 20 40 60 80 100 1 FORWARD VOLTAGE : VF (V) 2 0 0 10 20 30 40 AMBIENT TEMPERATURE : Ta (°C) FORWARD CURRENT : IF (mA) Fig.1 Forward current faloff Fig.2 Forward current vs. forward voltage Fig.3 Emitting strength vs. forward current RELATIVE EMITTING STRENGTH : IE (%) 1000 RELATIVE OPTICAL OUTPUT : PO (%) 100 80 60 100 40 20 10 −50 −25 0 25 50 75 100 0 900 920 940 960 980 1000 AMBIENT TEMPERATURE : Ta (°C) OPTICAL WAVELENGTH : λ (nm) Fig.4 Relative emitting strength vs.ambient temperature Fig.5 Wavelength 100 RELATIVE EMITTING STRENGTH (%) RELATIVE EMITTING STRENGTH (%) 90 80 70 60 50 40 30 20 10 0 −90 −60 −30 0 30 − 0 100 + 90 80 70 60 50 40 30 20 10 0 −90 −60 −30 0 30 −0 + 60 90 60 90 ANGULAR DISPLACEMENT : θ (deg) ANGULAR DISPLACEMENT : θ (deg) Fig.6 Directional pattern(1) Fig.7 Directional pattern(2) www.rohm.com c ○ 2010 ROHM Co., Ltd. All rights reserved. 2/2 2010.12 - Rev.B Notice Notes No copying or reproduction of this document, in part or in whole, is permitted without the consent of ROHM Co.,Ltd. The content specified herein is subject to change for improvement without notice. The content specified herein is for the purpose of introducing ROHM's products (hereinafter "Products"). If you wish to use any such Product, please be sure to refer to the specifications, which can be obtained from ROHM upon request. Examples of application circuits, circuit constants and any other information contained herein illustrate the standard usage and operations of the Products. The peripheral conditions must be taken into account when designing circuits for mass production. Great care was taken in ensuring the accuracy of the information specified in this document. However, should you incur any damage arising from any inaccuracy or misprint of such information, ROHM shall bear no responsibility for such damage. The technical information specified herein is intended only to show the typical functions of and examples of application circuits for the Products. ROHM does not grant you, explicitly or implicitly, any license to use or exercise intellectual property or other rights held by ROHM and other parties. ROHM shall bear no responsibility whatsoever for any dispute arising from the use of such technical information. The Products specified in this document are intended to be used with general-use electronic equipment or devices (such as audio visual equipment, office-automation equipment, communication devices, electronic appliances and amusement devices). The Products specified in this document are not designed to be radiation tolerant. While ROHM always makes efforts to enhance the quality and reliability of its Products, a Product may fail or malfunction for a variety of reasons. Please be sure to implement in your equipment using the Products safety measures to guard against the possibility of physical injury, fire or any other damage caused in the event of the failure of any Product, such as derating, redundancy, fire control and fail-safe designs. ROHM shall bear no responsibility whatsoever for your use of any Product outside of the prescribed scope or not in accordance with the instruction manual. The Products are not designed or manufactured to be used with any equipment, device or system which requires an extremely high level of reliability the failure or malfunction of which may result in a direct threat to human life or create a risk of human injury (such as a medical instrument, transportation equipment, aerospace machinery, nuclear-reactor controller, fuelcontroller or other safety device). ROHM shall bear no responsibility in any way for use of any of the Products for the above special purposes. If a Product is intended to be used for any such special purpose, please contact a ROHM sales representative before purchasing. If you intend to export or ship overseas any Product or technology specified herein that may be controlled under the Foreign Exchange and the Foreign Trade Law, you will be required to obtain a license or permit under the Law. Thank you for your accessing to ROHM product informations. More detail product informations and catalogs are available, please contact us. ROHM Customer Support System http://www.rohm.com/contact/ www.rohm.com © 2010 ROHM Co., Ltd. All rights reserved. R1010A
