Infrared light emitting diode, top view type
SIR-341ST3F
The SIR-341ST3F is a GaAs infrared light emitting diode housed in clear plastic. This device has a high luminous efficiency and a 940nm peak wavelength suitable for silicon detectors. It is small and at the same time has a wide radiation angle, marking it ideal for compact optical control equipment.
Applications Optical control equipment Light source for remote control devices
Dimensions (Unit : mm)
φ3.8±0.3 φ3.5 φ3.1±0.2
5.2±0.3
Features 1) Compact (3.1mm). 2) High efficiency, high output PO8.4mW (IF50mA). 3) Wide radiation angle 1/216deg. 4) Peak wavelength well suited to silicon detectors (P940nm). 5) Good current-optical output linearity. 6) Long life, high reliability.
2−
0.5
Min.24
1
(2.5)
2.5±1
2
Max.1
4−0.6
1.1
Notes: 1. Unspecified tolerance shall be ±0.2. 2. Dimension in parenthesis are show for reference.
1 Anode
2 Cathode
Absolute maximum ratings (Ta = 25C)
Parameter Forward current Reverse voltage Power dissipation Pulse forward current Operating temperature Storage temperature
∗ Pulse width=0.1msec, duty ratio 1%
Symbol IF VR PD IFP∗ Topr Tstg
Limits 75 5 100 500 −25 to +85 −40 to +85
Unit mA V mW mA °C °C
Electrical and optical characteristics (Ta = 25C)
Parameter Optical output Emitting strength Forward voltage Reverse current Peak light emitting wavelength Spectral line half width Half-viewing angle Response time Cut-off frequency Symbol PO IE VF IR Min. − 5.6 − − − − − − − Typ. 8.4 18.1 1.3 − 940 40 ±16 1.0 1.0 Max. − − 1.5 10 − − − − − Unit mW mW/sr V μA nm nm deg μs MHz IF=50mA IF=50mA IF=50mA VR=3V IF=50mA IF=50mA IF=50mA IF=50mA IF=50mA Conditions
λP Δλ θ1 / 2 tr·tf
fC
www.rohm.com
c ○ 2010 ROHM Co., Ltd. All rights reserved.
1/2
2010.06 - Rev.B
SIR-341ST3F
Electrical and optical characteristic curves
100
FORWARD CURRENT : IF (mA)
50
Data Sheet
100
FORWARD CURRENT : IF (mA)
−25°C 0°C 25°C 50°C 75°C
80
RELATIVE OPTICAL OUTPUT : PO (%)
80
40
60
60
30
40
20
40
20
10 0 0
20
0 0
20
40
60
80
100
0
1 FORWARD VOLTAGE : VF (V) 2
900
920
940
960
980
AMBIENT TEMPERATURE : Ta (°C)
OPTICAL WAVELENGTH : λ (nm)
Fig.1 Forward current falloff
Fig.2 Forward current vs. forward voltage
Fig.3 Wavelength
RELATIVE EMITTING STRENGTH : IE (%)
50
EMITTING STRENGTH : IE (mW/sr)
200
40
100
30
50
20
10
20
0 0
20
40
60
80
100
10
−20
0
20
40
60
80
FORWARD CURRENT : IF (mA)
AMBIENT TEMPERATURE : Ta (°C)
Fig.4 Emitting strength vs. forward current
Fig.5 Relative emitting strength vs.ambient temperature
30° 40° 50° 60 60° 70° 80° 90° 100 40 80
20
80
60
40
20
0 10° 20° 30° 40° 50° 60° 70° 80° 90° ANGULAR DISPLACEMENT : θ (deg)
RELATIVE EMITTING STRENGTH (%)
Fig.6 Directional pattern
www.rohm.com
c ○ 2010 ROHM Co., Ltd. All rights reserved.
RELATIVE EMITTING STRENGTH (%)
20°
10°
0°
100
2/2
2010.06 - Rev.B
