MM-1018-H

MM-1018 Micro-miniature Reed Switch Form A, Center Contact, Release AT Configurable All dimensions in mm This 10mm long, form A reed switch is designed for low power, high speed switching applications, and has a cost advantage over the UM-0018 Ultra-miniature series. The flattened lead outs are useful for orienting the internal blades to face one way while soldering, welding etc., for maximum in-group sensitivity, and the three different differential types available, cover a wide range of release specific applications. This reed switch is Lead (Pb) free and RoHS compliant. Formations Available Cropped SMD Welded Soldered Goal post L Formed Applications This reed switch is suitable for use in the following applications and many others: Microphones, reed relays, power showers, vibration sensors, sewing machines, automobile crash sensors, defective lamp detection, pressure gauges, vane sensors, fuel pumps, electric fishing reels, pedometers, board games... Electrical Sub code Operate Range Release Range Contact Rating (max) Switching Current (max) Carry Current (max) Switching Voltage (max) Switching Voltage (max) Breakdown Voltage Initial Contact Resistance (max) Insulation Resistance (min) Capacitance (min) Miscellaneous Operate Time (max) Bounce Time (max) Release Time (max) Resonance Frequency Operating Frequency Operating Temperature Test Coil Lead out plating Shock Resistance Vibration (10-2000Hz) AT AT W/ VA A A VDC VAC VDC m  pF L 10-40 4-20 10.0 0.5 0.75 100 70 200 100 10 9 0.2 M 10-40 6-25 10.0 0.5 0.75 100 70 200 120 10 9 0.2 H 10-40 7.5-30 10.0 0.5 0.75 100 70 200 150 10 9 0.2 ms ms ms Hz Hz °C g g 0.35 0.3 0.15 >2000 500 -40 to +120 717 102 003 Sn (Pb free) 30 20 Ordering Code MM-1018-(Sub Code)-(Start Operate AT)-(Finish Operate AT) Example MM-1018-M-10-14 Denotes 10-14 Operate AT band, with a minimum Release AT of 6. Other Configurations Available Dynamic contact resistance limit, Higher insulation resistance, Special release limits, Gold plates leads Please refer to our reed switch usage notes Due to continual improvement, specifications are subject to change without notice www.reed-sensor.com 10 May 2008 Reed Relays and Electronics India Limited  info@reed-switch.com  Tel 91-44-6528-4022
