MS-216 Cylindrical Magnet Sensor Standard Size, 6.0 mm Diameter x 25.4 mm, 30 W
Available with optional LED for closure indication All dimensions in mm
Does not require power for operation Omni-polar device; actuates with either pole of magnet Normally open (NO) contact, others available on request Three magnetic sensitivity bands Contact rating of up to 30W Lead (Pb) free and RoHS compliant Applications This magnet sensor is suitable for use in the following applications and many others: coffee machines, detergent level sensing in washing machines, dishwashers, fluid level sensing, anchor and rudder position sensing in boats, anemometers, treadmills, bicycles... Specification Contact Form Contact Rating (max) Switching Current (max) Carry Current (max) Switching Voltage (max) Breakdown Voltage (min) Initial Contact Resistance (max) Operating Temperature Shock Resistance (½Sin wave for 11ms) Vibration Resistance (10-2000Hz) Ordering Code MS-216-(Operate AT Code)-(Cable length in mm)-(Lead Code) OAT Code Lead Code 1 10 – 15 S 2 15 – 20 T 3 20 – 25 M
W / VA A A VDC VDC m °C g g
A 10 0.5 1.5 180 200 150 -40 to +70 50 20
Stripped to 5mm Stripped to 5mm and Tinned Molex Connector
Example MS-216-1-500-M denotes 10-15 Operate AT, with 500 mm cable length and Molex connectors.
Due to continual improvement, specifications are subject to change without notice
www.reed-sensor.com
15 March 2008
s
Reed Relays and Electronics India Limited info@reed-switch.com Tel 91-44-6528-4022
MS-216 Cylindrical Magnet Sensor Actuation Distances
Operate and release distances for the MS-216 cylindrical sensor, in two AT bands when actuated (as shown in the sketches) with NdFeB standard magnets is shown below. All distances given are in mm with tolerances of ±0.5mm. Although some of the AT band / magnet combinations will produce similar actuating distances, selecting the right AT band and magnet for an application is important and can be done by going through our AT band FAQ and our magnet selection guide. MS-216-1 (10-15 AT) Actuation Sketch
Magnet NDR-T NDC-T NDR-S NDC-S NDR-M NDC-M NDR-L NDC-L Magnet NDR-T NDC-T NDR-S NDC-S NDR-M NDC-M NDR-L NDC-L
Dimensions 4.0 x 1.5 x 1.5 Ø2.0 x 4.0 6.0 x 2.5 x 2.5 Ø3.0 x 7.0 8.0 x 3.0 x 3.0 Ø4.0 x 10.0 19.0 x 4.0 x 4.0 Ø8.0 x 15.0 Dimensions 4.0 x 1.5 x 1.5 Ø2.0 x 4.0 6.0 x 2.5 x 2.5 Ø3.0 x 7.0 8.0 x 3.0 x 3.0 Ø4.0 x 10.0 19.0 x 4.0 x 4.0 Ø8.0 x 15.0
Operate Distance 0.5 - 1.5 1.0 - 2.0 4.5 - 6.5 5.5 - 8.0 7.5 - 10.0 10.5 - 13.5 15.0 – 19.5 28.0 - 36.0 Operate Distance 0.5 - 2.5 1.5 - 3.5 6.0 - 8.5 7.5 - 9.5 9.5 - 11.5 13.0 - 16.5 18.0 - 22.0 28.0 - 34.0
Release Distance 1.5 - 2.5 1.5 - 3.0 6.0 - 8.0 7.5 – 9.5 10.0 - 11.0 13.0 - 15.0 18.5 - 21.5 33.0 – 39.0 Release Distance 1.5 - 3.5 2.5 - 4.5 8.0 - 9.5 9.5 - 10.5 11.0 - 13.0 15.0 - 18.5 21.0 - 24.0 32.0 - 37.0
Actuation Sketch
MS-216-2 (15-20 AT) Actuation Sketch
Magnet NDR-T NDC-T NDR-S NDC-S NDR-M NDC-M NDR-L NDC-L Magnet NDR-T NDC-T NDR-S NDC-S NDR-M NDC-M NDR-L NDC-L
Dimensions 4.0 x 1.5 x 1.5 Ø2.0 x 4.0 6.0 x 2.5 x 2.5 Ø3.0 x 7.0 8.0 x 3.0 x 3.0 Ø4.0 x 10.0 19.0 x 4.0 x 4.0 Ø8.0 x 15.0 Dimensions 4.0 x 1.5 x 1.5 Ø2.0 x 4.0 6.0 x 2.5 x 2.5 Ø3.0 x 7.0 8.0 x 3.0 x 3.0 Ø4.0 x 10.0 19.0 x 4.0 x 4.0 Ø8.0 x 15.0
Operate Distance N/A N/A 2.5 - 4.5 3.5 - 5.5 5.0 - 7.5 7.5 – 10.5 11.0 - 15.0 23.0 - 28.0 Operate Distance N/A 0.0 – 1.0 4.0 - 6.0 5.5 - 7.5 7.0 – 9.5 11.0 - 13.0 15.0 – 18.0 25.0 - 28.0
Release Distance N/A N/A 5.0 - 6.0 6.5 - 7.5 8.0 - 10.0 11.0 - 13.0 16.5 – 18.5 31.0 – 33.0 Release Distance N/A 0.5 - 2.0 7.0 - 8.0 8.5 – 9.5 10.0 - 11.0 13.5 - 15.0 20.0 - 21.0 31.0 - 32.0
Actuation Sketch
Due to continual improvement, specifications are subject to change without notice
www.reed-sensor.com
1 August 2008
s
Reed Relays and Electronics India Limited info@reed-switch.com Tel 91-44-6528-4022
