MS-228-4

MS-228 Cylindrical Proximity Sensor M8 threaded, Nickel plated Brass housing, 30 W, Line Voltage All dimensions in mm Does not require power for operation Omni-polar device; actuates with either pole of magnet Normally open (NO) contact Three magnetic sensitivity bands 0.75 mm pitch threaded barrel for fine adjustment Contact rating of up to 60W Lead (Pb) free and RoHS compliant Applications This magnet sensor is suitable for use in the following applications and many others: satellite television dish positioning, automobile ABS, heavy vehicles, digital speedometers… Specification Contact Form Contact Rating (max) Switching Current (max) Carry Current (max) Switching Voltage (max) Breakdown Voltage (min) Initial Contact Resistance (max) Operating Temperature Shock Resistance (½Sin wave for 11ms) Vibration Resistance (10-2000Hz) Ordering Code MS-228-(Operate AT Code)-(Cable length in mm)-(Lead Code) OAT Code Lead Code 3 20 – 25 S 4 25 – 30 T 5 30 - 35 M W / VA A A VDC / AC VDC m °C g g A 30 0.5 2.5 230 350 200 -40 to +70 50 20 Stripped to 5mm Stripped to 5mm and Tinned Molex Connector Example MS-228-1-500-M denotes 10-15 Operate AT, with 500 mm cable length and Molex connectors. Due to continual improvement, specifications are subject to change without notice www.reed-sensor.com 25 December 2007 s Reed Relays and Electronics India Limited  info@reed-switch.com  Tel 91-44-6528-4022 MS-228 Cylindrical Proximity Sensor Actuation Distances Operate and release distances for the MS-228 M8 threaded proximity sensor, in two AT bands when actuated (as shown in the sketches) with NdFeB standard magnets is shown below. All distances given are in mm with tolerances of ±0.5mm. Although some of the AT band / magnet combinations will produce similar actuating distances, selecting the right AT band and magnet for an application is important and can be done by going through our AT band FAQ and our magnet selection guide. MS-228-3 (20-25 AT) Actuation Sketch Magnet NDR-T NDC-T NDR-S NDC-S NDR-M NDC-M NDR-L NDC-L Magnet NDR-T NDC-T NDR-S NDC-S NDR-M NDC-M NDR-L NDC-L Dimensions 4.0 x 1.5 x 1.5 Ø2.0 x 4.0 6.0 x 2.5 x 2.5 Ø3.0 x 7.0 8.0 x 3.0 x 3.0 Ø4.0 x 10.0 19.0 x 4.0 x 4.0 Ø8.0 x 15.0 Dimensions 4.0 x 1.5 x 1.5 Ø2.0 x 4.0 6.0 x 2.5 x 2.5 Ø3.0 x 7.0 8.0 x 3.0 x 3.0 Ø4.0 x 10.0 19.0 x 4.0 x 4.0 Ø8.0 x 15.0 Operate Distance N/A N/A N/A N/A 1.0 – 3.5 5.0 – 7.0 8.0 – 11.0 19.0 – 22.0 Operate Distance N/A N/A 2.5 – 4.0 4.5 – 5.0 6.5 – 8.0 10.0 – 11.0 15.0 – 16.5 22.0 – 25.0 Release Distance N/A N/A N/A N/A 7.0 – 9.0 11.0 – 13.0 16.0 – 19.0 30.0 – 33.0 Release Distance N/A N/A 7.0 – 8.0 8.0 – 10.0 11.0 – 13.0 16.0 – 17.0 22.0 – 25.0 31.0 – 34.0 Actuation Sketch MS-228-4 (25-30 AT) Actuation Sketch Magnet NDR-T NDC-T NDR-S NDC-S NDR-M NDC-M NDR-L NDC-L Magnet NDR-T NDC-T NDR-S NDC-S NDR-M NDC-M NDR-L NDC-L Dimensions 4.0 x 1.5 x 1.5 Ø2.0 x 4.0 6.0 x 2.5 x 2.5 Ø3.0 x 7.0 8.0 x 3.0 x 3.0 Ø4.0 x 10.0 19.0 x 4.0 x 4.0 Ø8.0 x 15.0 Dimensions 4.0 x 1.5 x 1.5 Ø2.0 x 4.0 6.0 x 2.5 x 2.5 Ø3.0 x 7.0 8.0 x 3.0 x 3.0 Ø4.0 x 10.0 19.0 x 4.0 x 4.0 Ø8.0 x 15.0 Operate Distance N/A N/A N/A N/A 0.5 – 1.5 2.0 – 5.0 5.0 – 8.0 16.0 – 19.0 Operate Distance N/A N/A 1.5 – 2.5 3.5 – 4.5 5.0 – 6.5 8.5 – 10.0 12.5 – 15.0 21.0 – 22.0 Release Distance N/A N/A N/A N/A 7.0 – 8.0 10.0 – 11.0 15.0 – 16.0 29.0 – 30.0 Release Distance N/A N/A 6.5 – 7.5 8.0 – 8.5 10.0 – 11.0 15.0 – 16.0 21.0 – 22.0 31.0 – 32.0 Actuation Sketch Due to continual improvement, specifications are subject to change without notice www.reed-sensor.com 20 January 2009 s Reed Relays and Electronics India Limited  info@reed-switch.com  Tel 91-44-6528-4022
