HO-11

FULL SIZE CLOCK OSCILLATORS TTL COMPATIBLE HO-11 Series The HO-11 series oscillator is TTL compatibleand features fast rise/fall times with highreliability at low cost. The metal package with pin#7 case ground acts as shielding to minimize EMI radiation. FEATURES 10TTL output Load 14 Pin Full Size Industry Standard Wide Frequency Range Low Cost Resistance Weld Package Electrical Specifications Parameter Frequency Range Frequency Stability* Operating Temperature Range Storage Temperature Range Power supply Voltage Aging(First Year) Supply Current Output Symmetry Rise time Fall Time Output Voltage Output load Start-up Time *Include: 25 Condition FO All Condition* TOPR TSTG VDD 25 3 0.5MHz to 23.999MHz 24.000MHz to 69.999MHz 70.000MHz to 100.000MHZ At 1.4V 0.4V~2.4V 2.4V~0.4V IDD Sym Tr Tf VOH VOL TTL Load Ts HO-11 0.5MHz~100.00MHz 25ppm, 50ppm, 100ppm 0 ~70 (-40 ~+85 option) -55 ~+125 5.0V+/-10% 5ppm 15mA Max 30mA Max 60mA Max 40/60%(45/55% Option) 5 nS Max 5 nS Max 2.4 Vmin 0.4 Vmax 1~10TTL 10mS Max Clock Oscillator tolerance, operating temperature range, input voltage change, aging, load change, shock and vibration Mechanical Dimensions(mm) 12.9 Max 7.62 0.13 #1 #7 A MARKING AREA TTL Test Circuit Test Point +5.0V RL=400 0.01mF #14 #1 #8 #7 15pF** V #14 #8 15.24 20.4 Max **Includes stray and probe capacitance 5.08 Max 0.8 0.1 TTL Output Waveform 6.80Max Pin #1 #7 #8 #14 Connection N.C. GND Output VDD Tr VOH Tf 2.4V 1.4V VOL 0.4V GND T1 T0=1/Fo T1 Symmetry= T0 100% 0.45 0.1 23 ELECTRONIC COMPONENTS RSG ■ RSG Electronic Components GmbH Sprendlinger Landstr. 115 D-63069 Offenbach/Germany : : 886-2-26816456 Tel. +49 69 984047-0 Fax +49 69 984047-77 info@rsg-electronic.de www.rsg-electronic.de ■ ■ ■ ■ ■ : 886-2-86875200 : Änderungen vorbehalten / subject to change without notice
