HO-15

FULL SIZE CLOCK OSCILLATORS TTL/HCMOS COMPATIBLE HO-12&15 Series The HO-12 series oscillator is TTL/ HCMOS compatible HO-15 series is with 3.3V powersupply voltage. The metal package with pin #7 case ground acts as shielding to minimize EMI radiation. FEATURES TTL/HCMOS Output compatible 14 Pin Full Size Industry Standard Wide Frequency Range Low Cost Resistance Weld Package 3.3V available Electrical Specifications Parameter Frequency Range Frequency Stability* Operating Temperature Range Storage Temperature Range Power supply Voltage Aging(First Year) Supply Current Condition FO All Condition* TOPR TSTG VDD 25 3 0.5MHz to 23.999MHz 24.000MHz to 49.999MHz 50.000MHz to 69.999MHZ 70.000MHz to 125.000MHZ 1/2VDD 10%VDD~90%VDD 90%VDD~10%VDD HO-12 HO-15 0.5MHz~100.00MHz 0.5MHz~125.00MHz 25ppm, 50ppm, 100ppm 0 ~70 (-40 ~+85 option) -55 ~+125 5.0V+/-10% 3.3V+/-10% 5ppm 20mA Max 15mA Max 30mA Max 20mA Max 40mA Max 30mA Max 60mA Max 45mA Max 40/60%(45/55% Option) 10 nS Max 8 nS Max 10 nS Max 8 nS Max 90% VDD min 10% VDD max 1~10TTL 1~5TTL ~50M:50pF ~70M:30pF ~100M:15pF Ts 10mS Max ~50M:30pF ~125M:15pF Clock Oscillator IDD Output Symmetry Rise time Fall Time Output Voltage TTL Load Output load HCMOS Load Start-up Time *Include: 25 Sym Tr Tf VOH VOL tolerance, operating temperature range, input voltage change, aging, load change, shock and vibration Mechanical Dimensions(mm) A HCOMS Test Circuit Test Point #14 0.01mF #1 #8 #7 **CL=15pF 30pF or 50pF (See individual spec. sheet) 12.9 Max 7.62 0.13 #1 #7 MARKING AREA +5.0V +3.3V V #14 #8 15.24 20.4 Max **Includes stray and probe capacitance HOCMS Output Waveform Tr Tf 0.8 0.1 VOH 5.08 Max 90%VDD 0.45 0.1 6.80Max Pin #1 #7 #8 #14 Connection N.C. GND Output VDD 50%VDD VOL T1 T0=1/Fo 10%VDD GND T1 Symmetry= T0 100% 25 : 886-2-86875200 ■ ELECTRONIC COMPONENTS RSG ■ RSG Electronic Components GmbH Sprendlinger Landstr. 115 D-63069 Offenbach/Germany : : 886-2-26816456 Tel. +49 69 984047-0 Fax +49 69 984047-77 info@rsg-electronic.de www.rsg-electronic.de ■ ■ ■ ■ : Änderungen vorbehalten / subject to change without notice
