LPS-75

ELECTRONIC COMPONENTS RSG ■ RSG Electronic Components GmbH Sprendlinger Landstr. 115 D-63069 Offenbach/Germany Tel. +49 69 984047-0 Fax +49 69 984047-77 info@rsg-electronic.de www.rsg-electronic.de ■ ■ ■ ■ ■ Änderungen vorbehalten / subject to change without notice 75W Single Output Switching Power Supply Features : LPS-75 series Universal AC input / Full range Protections:Short circuit/Over load/Over voltage Cooling by free air convection PWM control and regulated Small and compact size Built-in remote ON-OFF control LED indicator for power on 100% full load burn-in test 2 years warranty SPECIFICATION MODEL DC VOLTAGE RATED CURRENT CURRENT RANGE RATED POWER PEAK LOAD(10sec.) OUTPUT VOLTAGE ADJ. RANGE LINE REGULATION LOAD REGULATION SETUP, RISE TIME HOLD TIME (Typ.) VOLTAGE RANGE FREQUENCY RANGE INPUT EFFICIENCY(Typ.) AC CURRENT (Typ.) INRUSH CURRENT (Typ.) LEAKAGE CURRENT PROTECTION OVER LOAD OVER VOLTAGE FUNCTION REMOTE ON/OFF WORKING TEMP. WORKING HUMIDITY ENVIRONMENT STORAGE TEMP., HUMIDITY TEMP. COEFFICIENT VIBRATION SAFETY STANDARDS WITHSTAND VOLTAGE SAFETY & ISOLATION RESISTANCE EMC (Note 5) LPS-75-3.3 3.3V 15A 0 ~ 16.5A 49.5W Note.4 54.45W LPS-75-5 5V 15A 0 ~ 16.5A 75W 82.5W 80mVp-p 4.75 ~ 5.5V 3.0% 1.0% 3.0% LPS-75-12 12V 6.2A 0 ~ 6.8A 74.4W 81.6W 100mVp-p 11 ~ 13.5V 2.0% 1.0% 2.0% LPS-75-15 15V 5A 0 ~ 5.5A 75W 82.5W 100mVp-p 13.5 ~ 16.5V 2.0% 1.0% 2.0% LPS-75-24 24V 3.2A 0 ~ 3.5A 76.8W 84W 120mVp-p 22 ~ 27V 2.0% 1.0% 1.0% LPS-75-48 48V 1.56A 0 ~ 1.7A 75W 81.6W 120mVp-p 45 ~ 54V 2.0% 1.0% 1.0% RIPPLE & NOISE (max.) Note.2 80mVp-p 3 ~3.5V VOLTAGE TOLERANCE Note.3 3.0% 1.0% 3.0% 100ms, 35ms/230VAC 60ms/230VAC 90 ~ 264VAC 47 ~ 63Hz 69% 77% 100ms, 35ms/115VAC at full load 12ms/115VAC at full load 127 ~ 370VDC 80% 81% 83% 83% 1.9A/115VAC 1.1A/230VAC COLD START 18A/115VAC 36A/230VAC
