RS-25

ELECTRONIC COMPONENTS RSG ■ RSG Electronic Components GmbH Sprendlinger Landstr. 115 D-63069 Offenbach/Germany Tel. +49 69 984047-0 Fax +49 69 984047-77 info@rsg-electronic.de www.rsg-electronic.de ■ ■ ■ ■ ■ Änderungen vorbehalten / subject to change without notice 25W Single Output Switching Power Supply Features : RS-25 series Universal AC input / Full range Protections:Short circuit/Over load/Over voltage Cooling by free air convection LED indicator for power on 100% full load burn-in test All using 105 long life electrolytic capacitors Withstand 300VAC surge input for 5 second High operating temperature up to 70 Withstand 5G vibration test High efficiency, long life and high reliability 3 years warranty SPECIFICATION MODEL DC VOLTAGE RATED CURRENT CURRENT RANGE RATED POWER OUTPUT VOLTAGE ADJ. RANGE RS-25-3.3 3.3V 6A 0 ~ 6A 19.8W RS-25-5 5V 5A 0 ~ 5A 25W 80mVp-p 4.75 ~ 5.5V 2.0% 0.5% 1.0% RS-25-12 12V 2.1A 0 ~ 2.1A 25.2W 120mVp-p 10.8 ~ 13.2V 1.0% 0.5% 0.5% 2200ms, 30ms/115VAC at full load RS-25-15 15V 1.7A 0 ~ 1.7A 25.5W 120mVp-p 13.5 ~ 16.5V 1.0% 0.5% 0.5% RS-25-24 24V 1.1A 0 ~ 1.1A 26.4W 120mVp-p 22 ~ 27.6V 1.0% 0.5% 0.5% RS-25-48 48V 0.57A 0 ~ 0.57A 27.36W 200mVp-p 42 ~ 54V 1.0% 0.5% 0.5% RIPPLE & NOISE (max.) Note.2 80mVp-p 2.85 ~ 3.6V VOLTAGE TOLERANCE Note.3 3.0% LINE REGULATION LOAD REGULATION SETUP, RISE TIME HOLD TIME (Typ.) VOLTAGE RANGE FREQUENCY RANGE INPUT EFFICIENCY(Typ.) AC CURRENT (Typ.) INRUSH CURRENT (Typ.) LEAKAGE CURRENT OVER LOAD PROTECTION OVER VOLTAGE WORKING TEMP. WORKING HUMIDITY ENVIRONMENT STORAGE TEMP., HUMIDITY TEMP. COEFFICIENT VIBRATION SAFETY STANDARDS WITHSTAND VOLTAGE Note.4 Note.5 0.5% 2.0% 80ms/230VAC 88 ~ 264VAC 47 ~ 63Hz 72% 1200ms, 23ms/230VAC 14ms/115VAC at full load 125 ~ 373VDC (Withstand 300VAC surge for 5sec. Without damage) 77% 79% 82% 84% 85% 0.7A/115VAC 0.4A/230VAC COLD START 30A/230VAC
