SP-200

ELECTRONIC COMPONENTS RSG ■ RSG Electronic Components GmbH Sprendlinger Landstr. 115 D-63069 Offenbach/Germany Tel. +49 69 984047-0 Fax +49 69 984047-77 info@rsg-electronic.de www.rsg-electronic.de ■ ■ ■ ■ ■ Änderungen vorbehalten / subject to change without notice 200W Single Output with PFC Function Features : SP-200 series Universal AC input / full range Built-in active PFC function, PF>0.93 Protections:Short circuit/Over load/Over voltage/Over temperature Built-in cooling fan speed control Built-in constant current limiting circuit Built-in fan speed control Remote ON-OFF control(Optional) LED indicator for power on 100% full load burn-in test Fixed switching frequency at PFC:67KHz PWM:134KHz 3 years warranty SPECIFICATION MODEL DC VOLTAGE RATED CURRENT CURRENT RANGE RATED POWER OUTPUT VOLTAGE ADJ. RANGE VOLTAGE TOLERANCE Note.3 LINE REGULATION LOAD REGULATION SETUP, RISE TIME HOLD TIME (Typ.) VOLTAGE RANGE FREQUENCY RANGE POWER FACTOR (Typ.) INPUT EFFICIENCY (Typ.) AC CURRENT (Typ.) INRUSH CURRENT (Typ.) LEAKAGE CURRENT OVER LOAD PROTECTION OVER VOLTAGE OVER TEMPERATURE FUNCTION SP-200-3.3 3.3V 40A 0 ~ 40A 132W SP-200-5 5V 40A 0 ~ 40A 200W 100mVp-p 2.0% 0.5% 1.0% SP-200-7.5 7.5V 26.7A 0 ~ 26.7A 200.2W 100mVp-p 2.0% 0.5% 1.0% SP-200-12 12V 16.7A 0 ~ 16.7A 200.4W 100mVp-p 2.0% 0.5% 0.5% SP-200-13.5 SP-200-15 13.5V 14.9A 0 ~ 14.9A 201.1W 100mVp-p 2.0% 0.5% 0.5% 15V 13.4A 0 ~ 13.4A 201W 100mVp-p 2.0% 0.5% 0.5% R SP-200-24 24V 8.4A 0 ~ 8.4A 201.6W 150mVp-p 1.0% 0.5% 0.5% SP-200-27 27V 7.5A 0 ~ 7.5A 202.5W 150mVp-p 1.0% 0.5% 0.5% SP-200-48 48V 4.2A 0 ~ 4.2A 201.6W 250mVp-p 1.0% 0.5% 0.5% RIPPLE & NOISE (max.) Note.2 100mVp-p 2.0% 0.5% 1.0% 3.14 ~ 3.63V 4.75 ~ 5.5V 7.13 ~ 8.25V 11.4 ~ 13.2V 12.8 ~ 14.9V 14.3 ~ 16.5V 22.8 ~ 26.4V 25.7 ~ 29.7V 45.6 ~ 52.8V 600ms, 30ms at full load 20ms at full load 85 ~ 264VAC 47 ~ 63Hz PF>0.93/230VAC 65% 71% PF>0.98/115VAC at full load 76% 79% 80% 81% 83% 83% 84% 120 ~ 370VDC 3.5A/115VAC 1.7A/230VAC COLD START 40A/230VAC
