SP-320-24

ELECTRONIC COMPONENTS RSG ■ RSG Electronic Components GmbH Sprendlinger Landstr. 115 D-63069 Offenbach/Germany Tel. +49 69 984047-0 Fax +49 69 984047-77 info@rsg-electronic.de www.rsg-electronic.de ■ ■ ■ ■ ■ Änderungen vorbehalten / subject to change without notice 320W Single Output with PFC Function Features : SP-320 series Universal AC input / Full range Built-in active PFC function, PF>0.95 Protections:Short circuit/Over load/Over voltage/Over temperature Forced air cooling by built-in DC Fan Built-in fan speed control Fixed switching frequency at 100KHz 3 years warranty SPECIFICATION MODEL DC VOLTAGE RATED CURRENT CURRENT RANGE RATED POWER OUTPUT VOLTAGE ADJ. RANGE VOLTAGE TOLERANCE Note.3 LINE REGULATION LOAD REGULATION SETUP, RISE TIME HOLD TIME (Typ.) SP-320-3.3 SP-320-5 3.3V 55A 0 ~ 60A 181.5W 5V 55A 0 ~ 55A 275W 150mVp-p SP-320-7.5 SP-320-12 7.5V 40A 0 ~ 40A 300W 150mVp-p 6 ~ 9V 2.0% 0.5% 1.0% 12V 25A 0 ~ 25A 300W 150mVp-p SP-320-13.5 SP-320-15 SP-320-24 SP-320-27 SP-320-36 SP-320-48 13.5V 22A 0 ~ 22A 297W 150mVp-p 15V 20A 0 ~ 20A 300W 150mVp-p 24V 13A 0 ~ 13A 312W 150mVp-p 27V 11.7A 0 ~ 11.7A 315.9W 200mVp-p 36V 8.8A 0 ~ 8.8A 316.8W 220mVp-p 48V 6.7A 0 ~ 6.7A 321.6W 240mVp-p RIPPLE & NOISE (max.) Note.2 150mVp-p 3.14 ~ 3.63V 4.5 ~ 5.5V 1.0% 2.0% 0.5% 1.5% 0.5% 1.0% 10 ~ 13.2V 12 ~ 15V 1.0% 1.0% 0.3% 0.5% 0.3% 0.5% 13.5 ~ 18V 20 ~ 26.4V 26 ~ 31.5V 32.4 ~ 39.6V 41 ~ 56V 1.0% 1.0% 1.0% 1.0% 1.0% 0.3% 0.5% 0.2% 0.5% 0.2% 0.5% 0.2% 0.5% 0.2% 0.5% 800ms, 50ms/230VAC 16ms/230VAC 2500ms, 50ms/115VAC at full load 16ms/115VAC at full load 124 ~ 370VDC PF>0.98/115VAC at full load 83% 86% 86% 86% 87% 88% 87% 89% VOLTAGE RANGE Note.5 88 ~ 264VAC 47 ~ 63Hz FREQUENCY RANGE POWER FACTOR (Typ.) INPUT EFFICIENCY (Typ.) 230VAC INRUSH CURRENT (Typ.) LEAKAGE CURRENT OVER LOAD PROTECTION OVER VOLTAGE OVER TEMPERATURE WORKING TEMP. AC CURRENT (Typ.) 115VAC PF>0.95/230VAC 74% 2.5A 79% 5A 2.5A 1.5A 20A/115VAC 40A/230VAC
