SP-500

ELECTRONIC COMPONENTS RSG ■ RSG Electronic Components GmbH Sprendlinger Landstr. 115 D-63069 Offenbach/Germany Tel. +49 69 984047-0 Fax +49 69 984047-77 info@rsg-electronic.de www.rsg-electronic.de ■ ■ ■ ■ ■ Änderungen vorbehalten / subject to change without notice 500W Single Output with PFC Function Features : SP-500 series Universal AC input / Full range Built-in active PFC function, PF>0.95 Protections:Short circuit/Over load/Over voltage/Over temperature Forced air cooling by built-in DC fan Built-in cooling Fan ON-OFF control Built-in remote ON-OFF control Built-in remote sense function Fixed switching frequency at 110KHz 3 years warranty SPECIFICATION MODEL DC VOLTAGE RATED CURRENT CURRENT RANGE RATED POWER OUTPUT VOLTAGE ADJ. RANGE SP-500-12 12V 40A 0 ~ 40A 480W SP-500-13.5 13.5V 36A 0 ~ 36A 486W 240mVp-p 12 ~ 15V 1.0% 0.5% 0.5% SP-500-15 15V 32A 0 ~ 32A 480W 240mVp-p 13.5 ~ 18V 1.0% 0.5% 0.5% SP-500-24 24V 20A 0 ~ 20A 480W 240mVp-p 20 ~ 26.4V 1.0% 0.5% 0.5% SP-500-27 27V 18A 0 ~ 18A 486W 200mVp-p 24 ~ 30V 1.0% 0.5% 0.5% SP-500-48 48V 10A 0 ~ 10A 480W 300mVp-p 41 ~ 56V 1.0% 0.5% 0.5% RIPPLE & NOISE (max.) Note.2 240mVp-p 10 ~ 13.2V VOLTAGE TOLERANCE Note.3 1.0% LINE REGULATION LOAD REGULATION SETUP, RISE TIME HOLD TIME (Typ.) VOLTAGE RANGE FREQUENCY RANGE POWER FACTOR (Typ.) INPUT EFFICIENCY(Typ.) AC CURRENT (Typ.) INRUSH CURRENT (Typ.) LEAKAGE CURRENT OVER LOAD PROTECTION OVER VOLTAGE FAN CONTROL, O.T.P. FUNCTION REMOTE CONTROL WORKING TEMP. WORKING HUMIDITY ENVIRONMENT STORAGE TEMP., HUMIDITY TEMP. COEFFICIENT VIBRATION SAFETY STANDARDS WITHSTAND VOLTAGE 0.5% 0.5% 24ms at full load Note.5 88 ~ 264VAC 1500ms, 50ms at full load 124 ~ 370VDC PF>0.95/115VAC at full load 84% 3.5A/230VAC 36A/230VAC 83% 85.5% 86.5% 87% 47 ~ 63Hz PF>0.95/230VAC 84% 7A/115VAC 18A/115VAC
