TP-100

ELECTRONIC COMPONENTS RSG ■ RSG Electronic Components GmbH Sprendlinger Landstr. 115 D-63069 Offenbach/Germany Tel. +49 69 984047-0 Fax +49 69 984047-77 info@rsg-electronic.de www.rsg-electronic.de ■ ■ ■ ■ ■ Änderungen vorbehalten / subject to change without notice 100W Triple Output with PFC Function Features : TP-100 Universal AC input / Full range Built-in active PFC function, PF>0.94 Protections:Short circuit/Over load/Over voltage Free air cooling convection Fixed switching frequency at 100KHz 3 years warranty series .. SPECIFICATION MODEL OUTPUT NUMBER DC VOLTAGE RATED CURRENT CURRENT RANGE RATED POWER (max.) OUTPUT VOLTAGE ADJ. RANGE VOLTAGE TOLERANCE Note.3 LINE REGULATION LOAD REGULATION SETUP, RISE TIME HOLD TIME (Typ.) VOLTAGE RANGE FREQUENCY RANGE POWER FACTOR (Typ.) INPUT EFFICIENCY (Typ.) AC CURRENT (Typ.) INRUSH CURRENT (Typ.) LEAKAGE CURRENT OVER LOAD PROTECTION OVER VOLTAGE OVER TEMPERATURE(OPTION) WORKING TEMP. WORKING HUMIDITY ENVIRONMENT STORAGE TEMP., HUMIDITY TEMP. COEFFICIENT VIBRATION SAFETY STANDARDS WITHSTAND VOLTAGE TP-100A CH1 5V 10A 3 ~ 15A 101W CH1: 4.75 ~ 5.5V 3.0% 1.0% 3.0% 7.0% 1.0% 6.0% 6.0% 1.0% 4.0% 3.0% 1.0% 3.0% 6.0% 1.0% 6.0% 6.0% 1.0% 4.0% 3.0% 1.0% 3.0% +10,-6% 1.0% 6.0% 6.0% 1.0% 4.0% 3.0% 1.0% 3.0% 8.0% 1.0% 6.0% 6.0% 1.0% 4.0% CH2 12V 4A 0.4 ~ 5A CH3 -5V 0.6A 0 ~ 1A TP-100B CH1 5V 10A 3 ~ 15A 105.2W CH2 12V 4A 0.4 ~ 5A CH3 -12V 0.6A 0 ~ 1A TP-100C CH1 5V 10A 3 ~ 15A 104W CH2 15V 3A 0.4 ~ 4A CH3 -15V 0.6A 0 ~ 1A TP-100D CH1 5V 10A 3 ~ 15A 105.2W CH2 24V 2A 0.4 ~ 3A CH3 12V 0.6A 0 ~ 1A RIPPLE & NOISE (max.) Note.2 100mVp-p 120mVp-p 100mVp-p 100mVp-p 120mVp-p 100mVp-p 100mVp-p 150mVp-p 100mVp-p 100mVp-p 150mVp-p 100mVp-p 800ms, 60ms/230VAC 24ms/230VAC Note.5 90 ~ 264VAC 800ms, 60ms/115VAC at full load 24ms/115VAC at full load 127 ~ 370VDC PF>0.98/115VAC at full load 78% 0.75A/230VAC 40A/230V 77% 78% 47 ~ 63Hz PF>0.94/230VAC 75% 1.5A/115VAC COLD START
