TP-150

ELECTRONIC COMPONENTS RSG ■ RSG Electronic Components GmbH Sprendlinger Landstr. 115 D-63069 Offenbach/Germany Tel. +49 69 984047-0 Fax +49 69 984047-77 info@rsg-electronic.de www.rsg-electronic.de ■ ■ ■ ■ ■ Änderungen vorbehalten / subject to change without notice 150W Triple Output with PFC Function Features : TP-150 Universal AC input / Full range Built-in active PFC function, PF>0.94 Protections:Short circuit/Over load/Over voltage Forced air cooling by built-in DC fan Fixed switching frequency at 100KHz 3 years warranty series .. SPECIFICATION MODEL OUTPUT NUMBER DC VOLTAGE RATED CURRENT CURRENT RANGE RATED POWER OUTPUT VOLTAGE ADJ. RANGE VOLTAGE TOLERANCE Note.3 LINE REGULATION LOAD REGULATION SETUP, RISE TIME HOLD TIME (Typ.) VOLTAGE RANGE FREQUENCY RANGE POWER FACTOR (Typ.) INPUT EFFICIENCY (Typ.) AC CURRENT (Typ.) INRUSH CURRENT (Typ.) LEAKAGE CURRENT OVER LOAD PROTECTION OVER VOLTAGE TP-150A CH1 5V 15A 2 ~ 20A 150W CH1: 4.75 ~ 5.5V 3.0% 1.0% 3.0% 8.0% 1.0% 6.0% 6.0% 1.0% 4.0% 3.0% 1.0% 3.0% 8.0% 1.0% 6.0% 6.0% 1.0% 4.0% 3.0% 1.0% 3.0% +10,-6% 1.0% 6.0% 6.0% 1.0% 4.0% 3.0% 1.0% 3.0% 8.0% 1.0% 6.0% 6.0% 1.0% 4.0% CH2 12V 6A 0.4 ~ 7A CH3 -5V 0.6A 0 ~ 1A TP-150B CH1 5V 15A 2 ~ 20A 148.2W CH2 12V 5.5A 0.4 ~ 7A CH3 -12V 0.6A 0 ~ 1A TP-150C CH1 5V 15A 2 ~ 20A 151.5W CH2 15V 4.5A 0.4 ~ 6A CH3 -15V 0.6A 0 ~ 1A TP-150D CH1 5V 15A 2 ~ 20A 154.2W CH2 24V 3A 0.4 ~ 4A CH3 12V 0.6A 0 ~ 1A RIPPLE & NOISE (max.) Note.2 100mVp-p 120mVp-p 100mVp-p 100mVp-p 120mVp-p 100mVp-p 100mVp-p 150mVp-p 100mVp-p 100mVp-p 150mVp-p 100mVp-p 800ms, 60ms/230VAC 24ms/230VAC 90 ~ 264VAC 47 ~ 63Hz PF>0.94/230VAC 75% 2.5A/115VAC COLD START 800ms, 60ms/115VAC at full load 24ms/115VAC at full load 127 ~ 370VDC PF>0.98/115VAC at full load 77% 1.2A/230VAC 40A/230V 77% 78%
