TP-75

ELECTRONIC COMPONENTS RSG ■ RSG Electronic Components GmbH Sprendlinger Landstr. 115 D-63069 Offenbach/Germany Tel. +49 69 984047-0 Fax +49 69 984047-77 info@rsg-electronic.de www.rsg-electronic.de ■ ■ ■ ■ ■ Änderungen vorbehalten / subject to change without notice 75W Triple Output with PFC Function Features : TP-75 series Universal AC input / Full range Built-in active PFC function, PF>0.95 Protections:Short circuit/Over load/Over voltage Low profile: 33mm thickness LED indicator for power on Cooling by free air convection Fixed switching frequency at PFC:67KHz PWM:134KHz 3 years warranty SPECIFICATION MODEL OUTPUT NUMBER DC VOLTAGE RATED CURRENT CURRENT RANGE RATED POWER OUTPUT VOLTAGE ADJ. RANGE VOLTAGE TOLERANCE Note.3 LINE REGULATION LOAD REGULATION SETUP, RISE TIME HOLD TIME (Typ.) VOLTAGE RANGE FREQUENCY RANGE POWER FACTOR (Typ.) INPUT EFFICIENCY (Typ.) AC CURRENT (Typ.) INRUSH CURRENT (Typ.) LEAKAGE CURRENT OVER LOAD PROTECTION OVER VOLTAGE WORKING TEMP. WORKING HUMIDITY ENVIRONMENT STORAGE TEMP., HUMIDITY TEMP. COEFFICIENT VIBRATION SAFETY STANDARDS WITHSTAND VOLTAGE SAFETY & ISOLATION RESISTANCE EMC (Note 4) TP-75A CH1 5V 7A 1.5 ~ 10A 74W 120mVp-p 4.0% 1.0% 4.0% 100mVp-p 8.0% 1.0% 8.0% CH1: 4.75 ~ 5.5V 3.0% 1.0% 3.0% CH2 12V 3A 0.2 ~ 4A CH3 -5V 0.6A 0 ~ 0.6A TP-75B CH1 5V 7A 1.5 ~ 10A 75.8W 100mVp-p 3.0% 1.0% 3.0% 120mVp-p 4.0% 1.0% 4.0% 120mVp-p 8.0% 1.0% 8.0% CH2 12V 3A 0.2 ~ 4A CH3 -12V 0.4A 0 ~ 0.6A TP-75C CH1 5V 6A 1.5 ~ 10A 75W 100mVp-p 3.0% 1.0% 3.0% 120mVp-p 4.0% 1.0% 4.0% 120mVp-p 8.0% 1.0% 8.0% CH2 15V 2.5A 0.2 ~ 3A CH3 -15V 0.5A 0 ~ 0.6A RIPPLE & NOISE (max.) Note.2 100mVp-p 800ms, 60ms at full load 36ms at full load Note.5 90 ~ 264VAC 127 ~ 370VDC PF>0.98/115VAC at full load 47 ~ 63Hz PF>0.95/230VAC 70% 1.5A/115VAC 0.8A/115VAC COLD START 20A/230VAC
