SPS-450-6-E

Ordering number : ENN6349 SPS-450 Series SPS-450 Series Receiver Pre-amp Module for Infrared Remote Control Features • This is an unified module consisting of a PIN photodiode and receiver pre-amp IC. It is a compact type, not necessary to mount outer part, and provides low voltage and low power consumption. • It also puts a measure to inverter fluorescent lamp with a high frequency trap circuit for band-pass filter. • It has leads at the both sides, so it is easy to put it on PCB. Absolute Maximum Ratings at Ta=25°C (as per JIS C 7032) Parameter Line Voltage Power Dissipation Operating Temperature Storage Temperature Soldering Temperature Symbol VCC PD Topr Tstg Tsol Rating 0 to +6.3 100 - to +60 -10 - to +70 -20 +260 *1 Unit V mW °C °C °C Recommended Operating Condition at Ta=25°C Parameter Symbol Opr. Condition Unit Line Voltage VCC +4.7 to +5.3 V We recommend the signal format with leader code (for example ; NEC format or Home Electrical Appliances Society format in Japan) for the remote control transmitter. Electrical / Optical Characteristics at Ta=25°C, VCC=5.0V D.C. Parameter Consumption Current Symbol ICC Condition Non-signal input *2 On axis *2 form device Cone with its limit inclined at 30 deg to axis Cone with its limit inclined at 40 deg to axis 2 At the point of 30cm on axis * *2 At the point of 30cm on axis *2 Specified by TWL time interval of output at the point of 30cm and 7.5m on axis *2 Specified by TWH time interval of output at the point of 30cm and 7.5m on axis Min. 7.5 Typ. 1.4 10.0 Max. 2.2 -Unit mA m Controlling Distance L 5.0 3.0 4.5 300 610 --0.5 -900 m m V V µs Low-level Output Voltage High-level Output Voltage Low-level Pulse Width VL VH TWL High-level Pulse Width Carrier Wave Frequency *1 TWH fo 300 - 590 *3 900 -- µs kHz Soldering time : with in 3sec and clearance of 1mm from lead stopper. Detector face illuminance : Ee < 10 lx Carrier wave frequency (fo) differs every a type. Refer to the following list. *2 As shown in Fig.1, burst wave shall be transmitted by our transmitter in item 7. *3 SANYO Electric Co.,Ltd. Semiconductor Company TOKYO OFFICE Tokyo Bldg., 1-10, 1 Chome, Ueno, Taito-ku, TOKYO, 110-8534 JAPAN D2099 GI, (MI) No.6349 1/5 SPS-450 Series Type No. SPS-450-E SPS-450-1-E SPS-450-2-E SPS-450-3-E SPS-450-4-E SPS-450-6-E Carrier wave frequency (fo) 40 kHz 38 kHz 36.7 kHz 33.3 kHz 36 kHz 56.8 kHz Precautions of Use Precautions (1) Care must be taken to avoid bending leads. (2) Do not apply any force or mechanical stress onto the leads or plastic part during soldering. (3) Confirm reliability in terms of devices, because it sometimes acts be wrong by the ingredient of the ripple noise of the power supply lines. Please design the ripple voltage of the power supply line below 1mVp-p. Please attach the RC filter (R=100Ω, C=22µF) for the power supply lines. Pulse Waveform Leader pulse fo kHz Burst wavefom of transmitter 9ms 4.5ms 600µs 600µs 600µs Output waveform 50% 50% Fig.1 Pulse waveform TWL TWH TWL Transmitter The Transmitter shall be defined by adjusting the output of transmitter to make Vo=400mVp-p according to the burst wave shown in Fig. 1 and measurement condition shown in Fig.2. In addition infrared LED used in the transmitter is set to λ peak=945nm, ∆λ=45nm, and photodiode used in the receiver is set to 32nA / Ix (VR=5.0V). 20cm 10kΩ + Transmitter -100kΩ 12 ± 0.1V 10µF Oscilloscorpe Output 10kΩ GND Fig.2 The output adjustment of transmitter No.6349 2/5 SPS-450 Series Measurement Condition DUT L Controlling distance Transmitter DUT : Device Under Test Fig.3 Measurement Condition Block Diagram VCC RL Vout Waveform Amp. Limiter BPF + TRAP ABLC Shaper Detector GND Fig.4 Block Diagram Note 1. Vout : Active “Low” output 2. RL.=15kΩ to 51kΩ . 3. The power supply filter is not being attached. No.6349 3/5 SPS-450 Series SPS-450 Series Package Dimensions and Pinconnection (A side) 6.9 (3.8) Photo diode chip 10 1.65 φ5.4 (A side) 2.7 9.6 3 * 1.4 1.2 * * * * 0.8 * * * * * * * * * 3.6 ± 0.5 lead stopper part 0.5 *1 2.54 *1 2.54 *1 5.08 0.4 2.54 2.54 1 2 3 5-φ 0 (pun .83 ch h ole) 7.62 1 GND 2 Vout 3 VCC (4 GND) (5 GND) *1 7.62 ± 0.5 5.08 4 5 Tolerance : ±0.3 Unit : mm Note 1) 2) 3) 4) Pin4, Pin5 has been connected to Pin1 (GND) in a product. The photo diode ohip is located in 3.8mm distance from top of lense. *1 indicates root dimensions of leads. The width and the position of the leads of "*" marke may be changed. < Recommended mounting drawing from soldering side > No.6349 4/5 SPS-450 Series CAUTION 1. No products described or contained herein are intended for use in surgical implants, life-support systems, aerospace equipment, nuclear power control systems, vehicles, disaster / crime-prevention equipment or the like, and the failure of which may directly or indirectly cause injury, death or property loss. 2. Anyone purchasing any products described or contained herein for an above-mentioned use shall: 1) Accept full responsibility and indemnify and defend SANYO ELECTRIC CO.,LTD., it’s affiliates, subsidiaries and distributors or any of their officers and employees, jointly and severally, against any and all claims and litigation and all damages, costs and expenses associated with such use. 2) Not impose any responsibility for any fault or negligence which may be cited in any such claim or litigation on SANYO ELECTRIC CO., LTD., it’s affiliates, subsidiaries and distributors or any of their officers and employees jointly or severally. 3. Information (including circuit diagrams and circuit parameters) disclosed herein is for example only; it is not guaranteed for mass production, SANYO believes the information disclosed herein is accurate and reliable, but no guarantees are made or implied regarding it’s use or any infringements of intellectual property rights or other rights of third parties. Precautionary instructions in handling gallium arsenic products Special precautions must be taken in handling this product because it contains, gallium arsenic, which is designated as a toxic substance by law. Be sure to adhere strictly to all applicable laws and regulations enacted for this substance, particularly when it comes to disposal. Manufactured by ; Tottori SANYO Electric Co., Ltd. LED Division 5-318, Tachikawa-cho, Tottori City, 680-8634 Japan TEL: +81-857-21-2137 FAX: +81-857-21-2161 PS No.6349 5/5
